Stainless Steel 2-Burner Propane Grill
Use, Care & Assembly Manual
Read all instructions and keep in a safe place for future reference.
INSTASTART™
Electronic Ignition
Propane cylinder not included.
Master Mariner
With Lighting Instructions
Model 9972 Series
ASSEMBLER/INSTALLER:
Leave these instructions with the consumer.
CONSUMER/USER:
IMPORTANT
CONSUMER/USER: This instruction manual
contains important information necessary for the
proper assembly and safe use of the appliance.
Read and follow all warnings and instructions
before assembling and using the appliance.
Follow all warnings and instructions when using the
appliance. Keep this manual for future reference.
If you have questions about assembly, operation, servicing or repair of
these grills, please call Coleman at 1-800-835-3278 or TDD: 316-832-8707.
In Canada call 1-800-387-6161.
TM
For Outdoor Use Only
www.coleman.com
Advertisement
Table of Contents
Related Manuals for Coleman 9972 Series
Summary of Contents for Coleman 9972 Series
- Page 1 Follow all warnings and instructions when using the appliance. Keep this manual for future reference. If you have questions about assembly, operation, servicing or repair of these grills, please call Coleman at 1-800-835-3278 or TDD: 316-832-8707. In Canada call 1-800-387-6161. Master Mariner...
-
Page 2: Table Of Contents
Contents Technical Characteristics ......... . 2 General Safety Information . - Page 3 • This appliance is not intended to be installed in or on recreational vehicles. • This appliance is not intended to be installed in or on boats unless mounted by a Coleman® rail or rod mount kit (sold separately). • This appliance is not intended for commercial use.
-
Page 4: Portable L.p. Gas Barbecue Cylinders
Coleman for service or repairs. • Use as a cooking appliance only. Never alter in any way or use with any device or part not expressly approved by Coleman. • Clean grill frequently to avoid grease accumulation and possible grease fires. -
Page 5: Maintenance
• About stainless steel - Stainless steel exposed to prolonged periods of high heat will change color and texture. Coleman grills require little preheating. Texture and color change is normal on interior components and will not affect the operation or performance of the product. - Page 6 Grill Assembly IMPORTANT: Remove all protective plastic film from stainless steel parts and any packing materials from grill prior to assembly/use. This film or packing materials are installed at the factory to prevent damage that could occur during shipment and handling. With lid latched, lift up on handle and set grill so it is resting on the back of the case.
- Page 7 Grill Assembly continued Install grease tray onto tracks at bottom front of grill. (Fig. 6) Insert tab on heat tent into slot on bracket at back of grill. (Fig. 7) Push down on tab at front of heat tent to lock into slot on grill bracket.
- Page 8 Grill Assembly continued Push down on grate to lock into tabs on right side of grill. (Fig. 11) Insert remaining grill grate under tab at back of grill, then push down on grate to lock into tabs on left side of grill. (Fig. 12) Place warming rack on tabs at left side of grill and push down to lock.
-
Page 9: Leak Check
Fig. 16 Fig. 17 Fig. 18 Note: Use Coleman 16.4 oz. disposable propane cylinders. The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specifications for LP- gas cylinders of the U.S. -
Page 10: Operation
Operation DANGER • CARBON MONOXIDE HAZARD • For outdoor use only. • Never use inside house, camper, tent, vehicle or other unven- tilated or enclosed areas. This grill consumes air (oxygen). Do not use in unventilated or enclosed areas to avoid endangering your life. -
Page 11: To Adjust Igniter
To Adjust Igniter NOTE: A gap of 1/8” should be maintained between the end of the wire on the electrode and the burner tube for proper ignition spark. (Fig. 21) Set on sturdy, flat surface. Grasp end of wire with a needle nose pliers and carefully bend to adjust to proper spacing from burner tube (Fig. -
Page 12: To Clean
To Clean Make sure grill is cool. Always detach the propane cylinder outdoors, away from flame (including pilot lights) and other ignition sources. The fitting on the regulator has a sliding collar that secures the regulator to the grill fuel line. Slide the collar away from the stove and then pull the regulator off the grill fuel line. -
Page 13: To Store
To Store DANGER • EXPLOSION - FIRE HAZARD • Never store propane near high heat, open flames, pilot lights, direct sunlight, other ignition sources or where temperatures exceed 120 degrees F (49°C). • The cylinder must be disconnected when the grill is in storage. •... -
Page 14: Trouble Shooting Guide
Obstructed gas flow Possible Solution Clean igniter electrode Adjust electrode until proper spark appears (see page 11) Call Coleman for service Call Coleman for service Call Coleman for service Check fuel level or replace fuel cylinder Call Coleman for service... -
Page 15: Replacement Parts List
Heat Tent (1 pk.) Thermometer Assembly Regulator Leg Kit (1 pk.) Grease Tray Crumb Tray Igniter/Piezo/Wire Assembly (2 pk.) 5010000080 Accessory items (sold separately) — 9972 Series Description Dual Rail Mounting Kit Adjustable Rod Holder Mounting Kit Grill Cover Padded Grill Case www.coleman.com Replacement Parts List —... -
Page 16: Warranty
Warranty The Coleman Company, Inc. (“Coleman”) warrants that for a period of one year from the date of original retail purchase, this product will be free from defects in material and workmanship. Coleman, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period.
