Assembly and
Instruction Manual

Charcoal Grill

Model 9945-700
For Outdoor use only
IMPORTANT
Read this manual carefully before assembling,
U. S. patents pending
using or servicing this unit. Keep this manual for
future reference. If you have questions about
assembly, operation, servicing or repair, please
call Coleman at 1-800-835-3278 or TDD:
316-832-8707. In Canada call 1-800-387-6161.

Advertisement

Table of Contents
loading

Related Manuals for Coleman 9945-700

Summary of Contents for Coleman 9945-700

  • Page 1: Charcoal Grill

    Read this manual carefully before assembling, U. S. patents pending using or servicing this unit. Keep this manual for future reference. If you have questions about assembly, operation, servicing or repair, please call Coleman at 1-800-835-3278 or TDD: 316-832-8707. In Canada call 1-800-387-6161.

  • Page 2: Table Of Contents

    • Dispose of cold ashes properly. • Do not modify in any way or use with parts not expressly approved by Coleman. Contact local authorities regarding possible burn restrictions before using product. WARNING •...

  • Page 3: Assembly

    Assembly (cont) RIGHT LEG ASSEMBLY ■ Tap one L-7 onto Wheel Axle. (Step 4) See Blister Pack for Step 4 hardware identification. Wheel Axle ■ Install Axle and hardware as shown. (Step 5) See Blister Pack for hardware identification. Step 5 Detail 5a Clip Wheel...

  • Page 4: Instructions For Use

    Assembly (cont) ■ Align Grate Pins Step 10 with holes in Base as shown. (Step 10) Instructions For Use GRILL SET-UP IMPORTANT: Step 1 ■ Side Shelf must be attached before grill set-up. Shelf ■ Push Clip down to release Step 2 Legs from stored position.
  • Page 5 Instructions For Use (cont) SIDE SHELF REMOVAL ■ Pull back tab to release shelf and lift to remove. CHARCOAL ASH COLLECTION SYSTEM IMPORTANT: Be sure Ash Pan Lid is off before lighting charcoal and throughout cooking process. ■ When finished cooking, press Charcoal Grate Lever down and slide to the right.

  • Page 6: Notes

    Accessories Carry Bag 9945-100 Grill Cover 9945-102 Griddle 9945-3171 Visit us at www.coleman.com Call us at 1-800-835-3278 Notes...

  • Page 7: Replacement Parts

    Replacement Parts Parts List Qty. Description Part No. Lid Assembly 9945-1061 Handle 9945-1281 Cooking Grate Assembly 9945-3161 Charcoal Grate Assembly 9945-3151 Base Assembly 9945-2331 Left Leg Assembly 9945-2341 Ash Pan Assembly 9945-2321 Ash Pan Lid Assembly 9945-2311 Side Shelf Assembly 9945-2361 Right Leg Assembly 9945-2351...

  • Page 8: Warranty

    The Coleman Company, Inc. (“Coleman”) warrants that for a period of five years from the date of pur- chase, this product will be free from defects in material and workmanship. Coleman, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period.
