AV4
CONTROL UNIT FOR MANUAL CONTROL UP TO 4 TUBULAR MOTORS
CONTROL UNIT FOR MANUAL CONTROL UP TO 4 TUBULAR MOTORS
Installation AND USE MANUAL
6-1621227 - rev. 2 - 12/12/2022
ENGLISH - Translated from the original language
Advertisement
Table of Contents
Related Manuals for Allmatic AV4
Summary of Contents for Allmatic AV4
- Page 1 CONTROL UNIT FOR MANUAL CONTROL UP TO 4 TUBULAR MOTORS CONTROL UNIT FOR MANUAL CONTROL UP TO 4 TUBULAR MOTORS INSTALLATION AND USE MANUAL 6-1621227 - rev. 2 - 12/12/2022 ENGLISH - Translated from the original language...
- Page 2 PRODUCT VIEW Overall dimensions: 140.50 x 182.00 x 80.60 mm Dimensions of the mounting holes: 114.00 x 156.00 mm INSTALLATION 1. Connect the 230vac power supply as shown. 2. If an engine operates in the wrong direction reverse the appropriate Black and Brown cables. ATTENTION •...
- Page 3 WIRING FOR GROUP CONTROL Master Keyswitch: Allows all connected motors to operate simultaneously. ATTENTION • The maximum total load allowed for group control is 6.3 A. WIRING FOR INDIVIDUAL CONTROL Individual Keyswitches: It allows the individual operation of the tubular motors through their corresponding selector. ATTENTION •...
- Page 4 The liability of the manufacturer for damage caused to anyone by accidents of any nature caused by our defective products, are only those that derive from the Italian law. ALLMATIC S.r.l 32026 Borgo Valbelluna - Belluno – Italy Via dell’Artigiano, n°1 – Z.A. Tel. 0437 751175 – 751163 r.a. Fax 0437 751065 www.allmatic.com - E-mail: info@allmatic.com...
