Leak Testing

Use the following procedure to leak test an endoscope. Leak test adaptors are available for PENTAX
FUJIFILM and KARL STROZ
TM
Note: This automated test is not a substitute for the endoscope manufacturer's manual leak
test. Follow the manufacturer's instructions when performing a manual test.
1. Install the waterproof caps and leak tester adaptors on the endoscope following the endoscope manufacturer's
instructions.
2. Load the endoscope into the reprocessor.
- Connect the leak tester hookup between the endoscope and the basin outlet.
3. Select the desired disinfection cycle. Press the START button on the reprocessor control panel.
4. The endoscope inflates for 20 seconds to 160mmHg (3psi). Endoscope pressure is monitored for another 20
seconds. -If the pressure decreases below the 50mmHg (1psi) reading within this period, the warning LED on the
reprocessor control panel blinks, the system activates an alarm and the message "Sheath Fail" is displayed. Press
the STOP button to end the cycle. The cycle is aborted.
- If no leak is detected, the disinfection cycle starts as normal. No indication is shown.
5. Pressure is maintained during the disinfection cycle to detect small leaks and prevent fluid ingression. If a small
leak is detected, the reprocessor will continue the cycle then alert the operator of any detected leaks at the end of
the cycle.
- Press the STOP button to acknowledge the warning.
6. The endoscope automatically deflates at the end of the cycle.
7. The log printout indicates if the leak tester option is disabled, or indicates any leak test failure.
Caution! The leak test adaptor must be disconnected and removed from
!
the basin when not in use to avoid potential fluid ingression.
endoscopes.
®
, OLYMPUS ,
® ®
