Model #FCS70438RSTRGDS
USE AND CARE GUIDE
7-PIECE STEEL SLING PADDED DINING SET - CHAIR
Questions, problems, missing parts? Before returning to the store
call Royal Garden Customer Service.
6 a.m. - 9 p.m., EST, 9 a.m. - 5p.m., PST Monday - Friday
(866) 988-3300
WWW.ROYALGARDEN.COM
THANK YOU
We appreciate the trust and con dence you have placed in Royal Garden through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Royal Garden!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCS70438RSTRGDS and is the answer not in the manual?

Questions and answers

Related Manuals for Royal garden FCS70438RSTRGDS

Summary of Contents for Royal garden FCS70438RSTRGDS

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in Royal Garden through the purchase of this chair. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 Package Contents ..............4 Assembly ..............5 Warranty ................ 2 Care and Cleaning ............

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. NOTE: Hardware not shown to actual size.

  • Page 4: Package Contents

    Pre-Assembly PACKAGE CONTENTS Part Description Quantity Chair bucket Left arm Right arm Support bar Left leg Right leg Connection bar...

  • Page 5: Assembly

    Assembly Connecting the right arm to the chair bucket Attach the right arm (C) to the chair bucket (A) using M6x30 combination bolts (AA). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (EE). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 6 Assembly (continued) Connecting the left arm to the chair bucket Attach the left arm (B) to the chair bucket (A) using M6x30 combination bolts (AA). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (EE).
  • Page 7 Assembly (continued) Connecting the support bar to the chair bucket Attach the support bar (D) to the chair bucket (A) using M8x20 combination hex bolts (DD). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the wrench (FF). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 8 Assembly (continued) Connecting the left leg to the support bar Attach the left leg (E) to the support bar (D) using M8x28 combination hex bolts (CC). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the wrench (FF).
  • Page 9 Assembly (continued) Connecting the right leg to the support bar Attach the right leg (F) to the support bar (D) using M8x28 combination hex bolts (CC). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the wrench (FF). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 10 Assembly (continued) Connecting the connection bar Attach the connection bar (G) to the front of the left leg (E) and the right leg (F) using M6x15 combination bolts (BB). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (EE).
  • Page 11 Assembly (continued) Connecting the connection bar Attach the connection bar (G) to the rear of the left leg (E) and the right leg (F) using M6x15 combination bolts (BB). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (EE). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.

  • Page 12: Care And Cleaning

    Assembly (continued) Checking the chair Once all of the bolts are in place, fully tighten the bolts. Turn the assembled chair right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
  • Page 13 Questions, problems, missing parts? Before returning to the store call Royal Garden Customer Service. 6 a.m. - 9 p.m., EST, 9 a.m. - 5p.m., PST Monday - Friday (866) 988-3300 WWW.ROYALGARDEN.COM Retain this manual for future use.
  • Page 14 THANK YOU We appreciate the trust and con dence you have placed in Royal Garden through the purchase of this chair. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 15: Safety Information

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............Product Caution ..............2 Package Contents ..............Safety Warnings ..............2 Assembly ................ 5 Warranty ................ 2 Care and Cleaning ............

  • Page 16: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...

  • Page 17: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table rim Leg connector Table leg Support tube Long tile Middle tile Short tile Stamped metal...

  • Page 18: Assembly

    Assembly ATTACHING THE TABLE LEGS AND THE SUPPORT TUBES TO THE TABLE RIM Place the table rim (A) upside down on a soft surface. Attach the table legs (C) and the support tubes (D) to the table top (A) using M6x30 combination bolts (AA). Do not fully tighten the bolts at this step.
  • Page 19 Assembly (continued) ATTACHING THE LEG CONNECTOR TO THE TABLE LEGS AND THE SUPPORT TUBES Attach the Leg connector (B) to the table legs (C) and the support tubes (D) using M6x25 combination bolts (BB). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (CC).
  • Page 20 Assembly (continued) PLACING THE TILES Once all of the bolts are in place, fully tighten the bolts. Turn the table right side up. Carefully place the long tiles (E), the middle tiles (F), the short tiles (G) and the stamped metal (H) onto the table rim (A). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.

  • Page 21: Care And Cleaning

    Table Assembly (continued) CHECKING THE TABLE Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrasive materials, bleach, or solvents.
  • Page 22 Questions, problems, missing parts? Before returning to the store call Royal Garden Customer Service. 6 a.m. - 9 p.m., EST, 9 a.m. - 5p.m., PST Monday - Friday (866) 988-3300 WWW.ROYALGARDEN.COM Retain this manual for future use.
