Item # 000 000
Model # FCA80324HS-ST-1
USE AND CARE GUIDE
7 PIECE CAST ALUMINUM SLING HIGH DINING SET
Questions, problems, missing parts? Before returning to the store
call Royal Garden Customer Service.
6 a.m. - 9 p.m., EST, 9 a.m. - 5 p.m., PST, Monday - Friday
(866) 988-3300
WWW.ROYALGARDEN.COM
THANK YOU
We appreciate the trust and con dence you have placed in Royal Garden through the purchase of this dining set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Royal Garden!
Advertisement
Table of Contents
Related Manuals for Royal garden FCA80324HS-ST-1
Summary of Contents for Royal garden FCA80324HS-ST-1
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Royal Garden through the purchase of this dining set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............Product Caution ..............2 Chair Package Contents ............Safety Warnings ..............2 Table Package Contents ............Warranty ................ -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 4: Chair Package Contents
Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Chair frame Chair connector Chair base... - Page 5 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Table top Table leg Leg connector Umbrella connector Umbrella cover WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
-
Page 6: Chair Assembly
Chair Assembly ATTACHING THE CHAIR CONNECTOR TO THE CHAIR FRAME Place the chair frame (A) upside down on a soft surface. Attach the chair connector (B) to the chair frame (A) using M8x40 combination hex bolts (BB). Once all of the bolts are in place, fully tighten the bolts using the wrench (DD). - Page 7 Chair Assembly (continued) INSERTING THE CHAIR CONNECTOR TO THE CHAIR BASE Insert the chair connector (B) to the chair base (C). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
- Page 8 Table Assembly CONNECTING THE TABLE LEGS Place the table top (D) upside down on a soft surface. Attach the table legs (E) to the table top (D) using M6x30 combination bolts (AA). Do not fully tighten all the bolts at this step.
- Page 9 Table Assembly (continued) ATTACHING THE LEG CONNECTOR AND THE UMBRELLA CONNECTOR TO THE TABLE LEGS Attach the leg connector (F) and the umbrella connector (G) to the table legs (E) using M6x30 combination bolts (AA). Do not fully tighten all the bolts at this step. WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
-
Page 10: Care And Cleaning
Table Assembly (continued) ADDING THE UMRENLLA COVER TO THE TABLE TOP Once all of the bolts are in place, fully tighten all the bolts by using the hex wrench (CC). Turn the table right side up and ensure all connections are secure. Carefully place the umbrella cover (H) to the table top (D). - Page 11 Questions, problems, missing parts? Before returning to the store call Royal Garden Customer Service. 6 a.m. - 9 p.m., EST, 9 a.m. - 5 p.m., PST, Monday - Friday (866) 988-3300 WWW.ROYALGARDEN.COM Retain this manual for future use.
