Model #FCS70439RSTRGDS
USE AND CARE GUIDE
4-PIECE STEEL PADDED SLING CHAT SET
Questions, problems, missing parts? Before returning to the store
call Royal Garden Customer Service.
6 a.m. - 9 p.m., EST, 9 a.m. - 5p.m., PST Monday - Friday
(866) 988-3300
WWW.ROYALGARDEN.COM
THANK YOU
lly create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Royal Garden!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCS70439RSTRGDS and is the answer not in the manual?

Questions and answers

Related Manuals for Royal garden FCS70439RSTRGDS

Summary of Contents for Royal garden FCS70439RSTRGDS

  • Page 1 6 a.m. - 9 p.m., EST, 9 a.m. - 5p.m., PST Monday - Friday (866) 988-3300 WWW.ROYALGARDEN.COM THANK YOU lly create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Royal Garden!

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............Product Caution ..............2 Club Chair Package Contents ..........Safety Warnings ..............2 Loveseat Package Contents ..........Warranty ................

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...

  • Page 4: Club Chair Package Contents

    Pre-Assembly (continued) CLUB CHAIR PACKAGE CONTENTS Part Description Quantity Chair bucket Left arm Right arm Support bar Left leg Right leg Connection bar...

  • Page 5: Loveseat Package Contents

    Pre-Assembly (continued) LOVESEAT PACKAGE CONTENTS Part Description Quantity Loveseat chair bucket Loveseat left arm Loveseat right arm Loveseat connection bar Glider base WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.

  • Page 6: Coffee Table Package Contents

    Pre-Assembly (continued) COFFEE TABLE PACKAGE CONTENTS Part Description Quantity Table top Table leg Leg connector...

  • Page 7: Club Chair Assembly

    Club Chair Assembly CONNECTING THE RIGHT ARM TO THE CHAIR BUCKET Attach the right arm (C) to the chair bucket (A) using M6x30 combination bolts (AA) Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (HH). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 8 Club Chair Assembly (continued) CONNECTING THE LEFT ARM TO THE CHAIR BUCKET Attach the left arm (B) to the chair bucket (A) using M6x30 combination bolts (AA). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (HH).
  • Page 9 Club Chair Assembly (continued) CONNECTING THE SUPPORT BAR TO THE CHAIR BUCKET Attach the support bar (D) to the chair bucket (A) using M8x20 combination hex bolts (EE). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the wrench (II) . WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 10 Club Chair Assembly (continued) CONNECTING THE LEFT LEG TO THE SUPPORT BAR Attach the left leg (E) to the support bar (D) using M8x28 combination hex bolts (DD). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the wrench (II).
  • Page 11 Club Chair Assembly (continued) CONNECTING THE RIGHT LEG TO THE SUPPORT BAR Attach the right leg (F) to the support bar (D) using M8x28 combination hex bolts (DD). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the wrench (II). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 12 Club Chair Assembly (continued) CONNECTING THE CONNECTION BAR Attach the connection bar (G) to the front of the left leg (E) and the right leg (F) using M6x15 combination bolts (CC). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (HH).
  • Page 13 Club Chair Assembly (continued) CONNECTING THE CONNECTION BAR Attach the connection bar (G) to the rear of the left leg (E) and the right leg (F) using M6x15 combination bolts (CC). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (HH).
  • Page 14 Club Chair Assembly (continued) CHECKING THE CHAIR Once all of the bolts are in place, fully tighten the bolts. Turn the club chair right side up. Ensure all connections are secure before use.

  • Page 15: Loveseat Assembly

    Loveseat Assembly CONNECTING THE LOVESEAT RIGHT ARM TO THE LOVESEAT CHAIR BUCKET Attach the loveseat right arm (J) to the back of the loveseat chair bucket (H) using M6x30 combination bolts (AA). Attach the loveseat right arm (J) to the seat of the loveseat chair bucket (H) using M6x15 combination bolt (CC). Attach the loveseat connection bar (K) to the loveseat right arm (J) using M6x15 combination bolts (CC).
  • Page 16 Loveseat Assembly (continued) CONNECTING THE LOVESEAT LEFT ARM TO THE CHAIR BUCKET Attach the loveseat left arm (I) to the back of the loveseat chair bucket (H) using M6x30 combination bolts (AA). Attach the loveseat left arm (I) to the seat of the loveseat chair bucket (H) using M6x15 combination bolt (CC). Attach the loveseat connection bar (K) to the loveseat left arm (I) using M6x15 combination bolts (CC).
  • Page 17 Loveseat Assembly (continued) CONNECTING THE GLIDER BASE TO THE LOVESEAT CHAIR ARMS Attach the glider base (L) to the loveseat left arm (I) and the loveseat right arms (J) using M6x18 countersunk bolts (FF) and plastic washers (GG). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (HH).
  • Page 18 Loveseat Assembly (continued) CHECKING THE LOVESEAT Once all of the bolts are in place, fully tighten the bolts. Turn the loveseat right side up Ensure all connections are secure before use.

  • Page 19: Coffee Table Assembly

    Coffee Table Assembly ATTACHING THE TABLE LEGS TO THE TABLE TOP Place the table top (M) upside down on a soft surface. Attach the table legs (N) to the table top (M) using M6x15 combination bolts (CC). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (HH).
  • Page 20 Coffee Table Assembly (continued) ATTACHING THE LEG CONNECTOR TO THE TABLE LEGS Attach the leg connector (O) to the table legs (N) using M6x25 combination bolts (BB). Do not fully tighten the bolts at this step. NOTE: Loosely tighten the bolts using the hex wrench (HH).

  • Page 21: Care And Cleaning

    Coffee Table Assembly (continued) CHECKING THE COFFEE TABLE Once all of the bolts are in place, fully tighten the bolts. Turn the coffee table right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
  • Page 22 Questions, problems, missing parts? Before returning to the store call Royal Garden Customer Service. 6 a.m. - 9 p.m., EST, 9 a.m. - 5p.m., PST Monday - Friday (866) 988-3300 WWW.ROYALGARDEN.COM Retain this manual for future use.
