Royal garden GFM00747A Use And Care Manual

7.8 x 9.8 ft. 3 sided wall mounted gazebo
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model #GFM00747A
USE AND CARE GUIDE
7.8 X 9.8 FT. 3 SIDED WALL MOUNTED GAZEBO
Questions, problems, missing parts? Before returning to the store
call Royal Garden Customer Service.
6 a.m. - 9 p.m., EST, 9 a.m. - 5 p.m., PST, Monday - Friday
(866) 988-3300
WWW.ROYALGARDEN.COM
THANK YOU
ally createqual-
ity products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Royal Garden!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GFM00747A and is the answer not in the manual?

Questions and answers

Related Manuals for Royal garden GFM00747A

Summary of Contents for Royal garden GFM00747A

  • Page 1 6 a.m. - 9 p.m., EST, 9 a.m. - 5 p.m., PST, Monday - Friday (866) 988-3300 WWW.ROYALGARDEN.COM THANK YOU ally createqual- ity products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Royal Garden!

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............Product Caution ..............2 Packaging Contents..............4 Safety Warnings ..............2 Assembly ................6 Warranty ................ 2 Care and Cleaning ............20 What is Covered ..............

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...

  • Page 4: Packaging Contents

    Pre-Assembly (continued) PACKAGE CONTENTS 2PCS 2PCS...
  • Page 5 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Front left leg pillar Front right leg pillar Rear left leg pillar Rear right leg pillar Side beam Front left beam Front right beam Rear left beam Rear right beam Left top bar Right top bar Middle top bar Side card slot pillar...

  • Page 6: Assembly

    Assembly ASSEMBLING THE PILLARS Insert the front left & right pillar (A&A1) through the front pillar base cap (L), then attach the front left & right pillar (A&A1) to the front pillar base plate (K) using M6x20 combination bolts (AA). Insert the rear left &...
  • Page 7 Assembly (continued) ATTACH THE BEAM LINERS TO THE FRONT LEG PILLARS Attach beam liner (P) to front left & right leg pillar (A&A1) using M6x20 combination bolts (AA) and spring washers (DD). NOTE: Fully tighten all bolts using the hex wrench (FF). A&A1 DD 8 M6x20...
  • Page 8 Assembly (continued) ATTACH THE BEAM LINERS TO THE REAR LEG PILLARS Attach beam liner (P) to rear left & right leg pillar (B&B1) using M6x20 combination bolts (AA) and spring washers (DD). NOTE: Fully tighten all bolts using the hex wrench (FF). B&B1 B&B1 DD 8...
  • Page 9 Assembly (continued) ATTACH THE LEFT BEAM TO THE RIGHT BEAM Attaching the front left beam (D) to the front right beam (D1) using M6x20 combination bolts (AA). Attaching the rear left beam (E) to the rear right beam (E1) using M6x20 combination bolts (AA). NOTE: Fully tighten all bolts using the hex wrench (FF).
  • Page 10 Assembly (continued) ATTACH THE REAR LEG PILLARS TO THE REAR BEAMS Attach the rear left leg pillar (B) to the rear left beam (E) using M6x20 combination bolts (AA) outside, and using M6x20 combination bolts (AA) through the corner brace (J) inside. Attach the rear right leg pillar (B1) to the rear right beam (E1) using M6x20 combination bolts (AA) outside, and using M6x20 combination bolts (AA) through the corner brace (J) inside.
  • Page 11 Assembly (continued) ATTACH THE FRONT PILLARS TO THE FRONT BEAMS Attach the front left leg pillar (A) to the front left beam (D) using M6x20 combination bolts (AA) outside, and using M6x20 combination bolts (AA) through the corner brace (J) inside. Attach the front right leg pillar (A1) to the front right beam (D1) using M6x20 combination bolts (AA) outside, and using M6x20 combination bolts (AA) through the corner brace (J) inside.
  • Page 12 Assembly (continued) ATTACH THE SIDE BEAMS TO THE REAR LEG PILLARS Attach the side beams (C) to the rear left & right leg pillars (B&B1) using M6x20 combination bolts (AA) through the corner brac e (J). NOTE: Fully tighten all bolts using the hex wrench (FF). M6x 20...
  • Page 13 Assembly (continued) ATTACH THE SIDE CARD SLOT PILLAR TO THE REAR LEG PILLAR Attach the side card slot pillar (H) to the rear left & right leg pillars (B&B1) only using M6x20 combination bolts (AA) (See Fig . 1). and use M6x20 combination (AA) through corner brace (J) (See Fig. 2). NOTE: Fully tighten all bolts using the hex wrench (FF).
  • Page 14 Assembly (continued) INSERT LEFT AND RIGHT SUN BOARD INTO SIDE CARD SLOT PILLAR Insert left and right sun board (R&S) into side card slot pillar (H). R&S...
  • Page 15 Assembly (continued) ATTACH THE TOP BARS TO THE LEG PILLARS Attach the left top bar (F) to the rear left leg pillar (B) and front left leg pillar (A) using M6x20 combination bolts (AA). Attach the right top bar (F1) to the rear right leg pillar (B1) and front right leg pillar (A1) using M6x20 combination bolts (AA). NOTE: Do not fully tighten all bolts using the hex wrench (FF).
  • Page 16 Assembly (continued) ATTACH THE MIDDLE TOP BARS TO THE BEAMS Insert M6x35 combination bolts (BB) through the middle top bar (G) and spring washers (CC). NOTE: Do not fully tighten all bolts using the wrench (EE) and hex wrench (FF). BB 8 M6x 3 5 EE 1...
  • Page 17 Assembly (continued) INSERT TOP SUN BOARDS INTO THE MIDDLE TOP BARS Insert top sun boards (T) into the middle top bars(G) WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 18 Assembly (continued) PLACE THE CORNER CAPS ON THE FRONT BEAMS Insert the M6x20 combination bolt (AA) through the left corner cap (M), side bar (H1), front left beam (D) and left top bar (F). Attach the M6x20 combination bolt (AA) to the right corner cap (M1), side bar (H1), front right beam (D1) and right top bar (F1). Attach the M6x20 combination bolts (AA) to the middle corner caps (N), side bar (H1), front left &...
  • Page 19 Assembly (continued) PLACE CORNER CAPS ON THE REAR BEAMS Insert the M6x12 combination bolt (HH) through the left corner cap (M), side bar (H1) rear right beam (E1) and right top bar (F1). Insert the M6x12 combination bolt (HH) through the right corner cap (M1), side bar (H1) rear left beam (E) and left top bar (F). Attach the M6x12 combination bolts (HH) to the middle corner caps (N), side bar (H1), rear left &...

  • Page 20: Care And Cleaning

    Assembly (continued) INSTALL THE GROUND SPIKES AND SIDEWALLS Hammer in the ground spikes (GG) through the holes of base plate (K&K1) on pillars (A,A1, B and B1) until the ground spike (GG) secures the base plate (K&K1) to the ground. Put up the two side walls (U&U1) on the side bars and beams (H1,D,D1,E and E1).
  • Page 21 Questions, problems, missing parts? Before returning to the store call Royal Garden Customer Service. 6 a.m. - 9 p.m., EST, 9 a.m. - 5 p.m., PST, Monday - Friday (866) 988-3300 WWW.ROYALGARDEN.COM Retain this manual for future use.
