- Page 1 Assembly Instructions Model No. 205364064 7pc High Dining Set - Chair Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday Retain this manual for future use.
-
Page 2: Table Of Contents
Contents Safety Instructions Parts List Assembly Cleaning & Maintenance Warranty IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. 205364064... -
Page 3: Safety Instructions
WARNING Do not locate the product near any heat source. WARNING Warning: Weight limit for the chairs is 250lbs (113.39Kg) for each set. WARNING This dining set unit is heavy, and may require two adults for safe assembly. 205364064... -
Page 4: Parts List
M8x35 Combination Hex Bolt - 24+1 Chair Connector - 6 M8 Washer 24+1 Chair Base - 6 M8 Spring Washer - 24+1 Pillow - 6 M8 Nut - 24+1 Seat Cushion - 6 Hex Wrench - 2 Wrench - 2 205364064... -
Page 5: Assembly
Attaching The Right And Left Arms To The Chair Back Attach the right arm (A) and the left arm (B) to the chair back (C) using M6x35 combination bolts (AA). NOTE: Loosely tighten all the bolts using the hex wrench (HH). 205364064... - Page 6 Requires: BB, A, B, D Attaching The Chair Seat To The Chair Arms Attach the chair seat (D) to the right and left arms (A & B) using M6x30 combination bolts (BB). NOTE: Tighten all the bolts using the hex wrench (HH). 205364064...
- Page 7 Attach the bottom of the chair seat (D) to the chair base (F) by inserting M8x35 combination hex bolts (DD) through the chair seat (D), the chair connector (E), M8 washers (EE), M8 spring washers (FF), and into M8 nuts (GG), as shown below. NOTE: Tighten all the bolts using the wrench (II). 205364064...
- Page 8 Assembly STEP 4 Tightening The Bolts Once all bolts are in place, fully tighten all the bolts. Turn the chair right side up. Check and ensure the chair is tightly assembly and stable before use. 205364064...
- Page 9 Assembly STEP 5 Requires: G, H Place The Seat Cushion And Pillow Place the seat cushion (H) and the pillow (G) to finish the assembly of the chair. 205364064...
-
Page 10: Cleaning & Maintenance
• Do not clean with abrasive materials, bleach, or solvents. • Store the seating set in a dry, sheltered place when not in use. • Keep the seating set away from fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind. 205364064... -
Page 11: Warranty
After cleaning cushions tip on end and allow to drip dry. (Never use a commercial or home dryer to tumble dry fabric goods). Do not use bleach or solvents to clean any product! This will void the warranty. 205364064... - Page 12 TO BE DEFECTIVE UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. 205364064...
- Page 13 Assembly Instructions Model No. 205364064 7pc High Dining Set - Table Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday Retain this manual for future use.
- Page 14 Contents Safety Instructions Parts List Assembly Cleaning & Maintenance Warranty IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. 205364064...
-
Page 15: Safety Instructions
Never use this product as support. Do not shake, lean, or climb on the product at any time. WARNING When not in use, secure the product in a cool and covered location. WARNING Do not locate the product near any heat source. 205364064... -
Page 16: Parts List
M6x25 Combination Bolt - 8+1 Lid - 1 M8x35 Combination Hex Bolt - 24+1 Ice Bucket - 1 M8 Washer 24+1 Ice Pack - 1 M8 Spring Washer - 24+1 M8 Nut - 24+1 Hex Wrench - 2 Wrench - 2 205364064... -
Page 17: Assembly
Connecting The Table Legs Place the table top (I) upside down on a soft surface. Attach the table legs (J) to the table top (I) using M6x30 combination bolts (BB). NOTE: Loosely tighten all the bolts using the hex wrench (HH). 205364064... - Page 18 STEP 2 Requires: CC, J, K Attaching The Leg Connector To The Table Legs Attach the leg connector (K) to the table legs (J) using M6x25 combination bolts (CC). NOTE: Loosely tighten all the bolts using the hex wrench (HH). 205364064...
- Page 19 Ensure that all connections are secure. Carefully place the ice bucket (M) into the table top (I), and put the ice pack (N) into the ice bucket (M), then put the lid (L) over the ice bucket (M) and ice pack (N). 205364064...
-
Page 20: Cleaning & Maintenance
• Store furniture in an upright position to prevent water building up in frames, as this will cause corrosion and freeze damage in cold climates. • Consider covering your furniture when not in use for long periods of time (and during bouts of inclement weather). 205364064... -
Page 21: Warranty
After cleaning cushions tip on end and allow to drip dry. (Never use a commercial or home dryer to tumble dry fabric goods). Do not use bleach or solvents to clean any product! This will void the warranty. 205364064... - Page 22 TO BE DEFECTIVE UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. 205364064...
