6 Calibration

Calibration EEPROM Map

Table 9 represents the EEPROM map of the device calibration values. All values are stored as little-endian
4-byte floating point numbers. Every point is 4-bytes long. Access to the data is possible through the
CAL_EEPROM_READ register, which reads 8 bytes starting at the address pointed to by the register input.
Offset
Points
address
0x00 664
0x298 1
0x29B 2
0x2B8 3x8
0x338 22
0x390 22
0x3E8 22
0x5CC 30
0x644 30
0x6CC 1
0x6D0 1
0x6D4 30
0x7D8 1
0x7DC 1
0x7E8 17
0x82C 17
0x870 17x30
Rev 2.1 | SC5312A & SC5313A
Table 9. Calibration EEPROM Map
Length
Data Type
(Bytes)
664 U_8
4 Float_32
8 Float_32
96 Float_32
88 Float_32
88 Float_32
88 Float_32
120 Float_32
120 Float_32
4 Float_32
4 Float_32
120 Float_32
4 Float_32
4 Float_32
68 Float_32
68 Float_32
2040 Float_32
User Manual
Description
Factory Reserved
Calibration Temperature
Temp coeff C1, C2
IF response cal frequencies
25, 50, 75, ..., 550 in MHz
IF3_response, relative gain to 225 MHz at each
calibration frequency for IF3_filter1 500 MHz filter
IF3_response, relative gain to 225 MHz at each
calibration frequency for IF3_filter1 250 MHz filter
Relative If3_atten#1, 1-30 dB, 1 dB step
Relative If3_atten#2, 1-30 dB, 1 dB step
Relative Bypass IF3 gain, dB
Relative Bypass IF3 1.25 GHz BPF gain
Relative Bypass IF3_atten#2, 1-30 dB, 1 dB step
Relative IF3_invert gain
Relative IF2_Low BW gain
Bypass Conv frequencies (start 50 MHz, 50 MHz
steps to 850 MHz, 17 points) in MHz
Bypass Conversion Absolute gain at each freq
Bypass Relative IF3#2 atten at each freq.
a1_f0, a1_f1,...,a1_fN
a2_f0, a2_f1,...,a2_fN
a30_f0, a30_f1,...,a30_fN
