32 SC5312A & SC5313A Hardware Manual
[2] SPI
[3] RS232
[7:4] Undefined
Revision Information
The first 4 bytes represent the hardware revision and the last 4 bytes represent the firmware revision of
the device. These 4 bytes encompass a 32-bit floating point number so the data needs to be type casted
from an unsigned 32-bit value to float value.
Date Information
The first 4 bytes represent the manufactured date and the last 4 bytes represent the last calibration date.
The date format is outlined in the following table.
Bit Type
[0]
[1]
[4:3] U16
Rev 2.1 | SC5312A & SC5313A
Description
U8 Day
U8 Month
Year (i.e. 2016)
