24 SC5312A & SC5313A Hardware Manual
Bytes read 1
Bits Type Name
[7:0] W Unused
[7:0] R Read back byte

Register 0x1E USER_EEPROM_WRITE

This register writes a byte to the onboard EEPROM.
Bytes written 2
Bytes read 1
Bits Type Name
[7:0] W Data
[23:8] W Address
[7:0] R Read back byte

Register 0x1F FREQ_PLAN_PARAM

This register sets up the frequency plan parameters and stores them as the default values.
Bytes written 8
Bytes read 1
Bits Type Name
[47:0] W Data
[50:48] W Parameter
[55:51] W Unused
[7:0] R Read back byte
Rev 2.1 | SC5312A & SC5313A
Width Description
8 Set to zeros
8 Read 1 byte back is required for PXIe and RS232
Width Description
8 Byte to be written to the address
16 EEPROM address
8 Read 1 byte back is required for PXIe and RS232
Width Description
48 Data for the parameter
0 = RF frequency
1 = IF1 frequency
3
2 = IF2 frequency
3 = IF3 frequency
5 Set to zeros
8 Read 1 byte back is required for PXIe and RS232
