Summary of Contents for Monoprice 43394
- Page 1 1x2 VGA Splitter with Audio P/N 43394 User's Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. •... - Page 3 INTRODUCTION This 1x2 VGA Splitter with Audio allows you to connect two VGA displays to a single VGA source. It supports resolutions up to 1900x1200 and features up to 500MHz video bandwidth. It features audio support using a single 3.5mm audio input and two 3.5mm audio outputs.
-
Page 4: Customer Service
If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com or via email at... -
Page 5: Product Overview
PRODUCT OVERVIEW SAMPLE CONNECTION DIAGRAM... - Page 6 CONNECTION Perform the following steps to connect the splitter to your system. Ensure that all devices to be connected are powered off and disconnected from their power sources. Using a VGA cable (available separately), plug one end into the VGA input on your first display, then plug the other end into the VGA 1 OUT port on the splitter.
-
Page 7: Specifications
Plug in and power on all connected equipment. Verify that you can see video on each display. If you connected audio, verify that you can hear audio on each display. SPECIFICATIONS 43394 Input 1x VGA + 3.5mm audio Outputs 2x VGA + 3.5mm audio... -
Page 8: Technical Support
TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting, or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates. - Page 9 for Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 10 Notice for Industry Canada This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB- 003 du Canada. Monoprice™ and all Monoprice logos are trademarks of Monoprice Inc.
