Using The User Naming Area; Figure 1-4 Enterprise 3500 Server Access Areas - Top View - Sun Microsystems Enterprise 3500 System Installation Manual

6 inches
on each side
FIGURE 1-4
1.6

Using the User Naming Area

To display the name of the server, IP address, owner, or other important information
on the front of the machine:
1. Remove the front bezel.
Refer to Chapter 12 "Preparing for Service," in the Sun Enterprise 3500 System
Reference Manual (Section 12.3.1 "Front Bezel").
2. Snap out the narrow transparent window.
From the rear side of the bezel, gently squeeze the top and bottom edges together as
you simultaneously push the transparent window out through the front of the bezel.
3. Choose the information that will appear on the label.
Common items include the name of the server, IP address, name and contact
information for the system administrator, and the group of users that the machine
services.
4. Use the colored paper provided with the system to make a label.
The available area for the paper label is 0.5 in x 5.9 in (12 mm x 150 mm). Print or
write the desired information in an area this size and cut the label to fit the
transparent window.
5. Place the paper label inside the window, and snap the window back in place from
the front side of the bezel.
1.5 feet access at rear
Enterprise
3500
system
1.5 feet access at front
Enterprise 3500 Server Access Areas — Top View
Chapter 1 Preparing for Installation 1-7
