  • Page 1 Installer manual Condensation water pipe KVR 10 IHB EN 2216-4 431740...

  • Page 3: Table Of Contents

    Different versions of KVR 10 3 Pipe connections General Drain indoors Stone caisson Gutter drainage 4 Electrical connection F2016 / F2026 F2030 / F2300 F2040 F2050 NIBE SPLIT HBS 05 / HBS 20 Contact information KVR 10 Table of Contents...

  • Page 4: Important Information

    Cleaning and user maintenance shall not be made by children without supervision. This is an original manual. It may not be translated without the approval of NIBE. Rights to make any design or technical modifications are reserved. ©NIBE 2022.

  • Page 5: General

    Read the entire Installer Manual together with the main product’s Installer Manual! Different versions of KVR 10 KVR 10 is available in three lengths. Here you can see an example of the installation length. Installationslängd Installation length KVR 10...
  • Page 6 F2016, F2026, F2030, F2040, F2050, F2300, NIBE SPLIT HBS 05 / HBS 20 KVR 10 KVR 10 2x230V Part No. Part No. Hose length 1 metre (installation length 1 m without water seal) 067 614 067 615 Hose length 3 metres (installation length 1-2.2 m with water seal)

  • Page 7: Pipe Connections

    The drain from KVR 10 must be positioned at frost free depth or indoors (subject to local rules and regulations). • The drain from KVR 10 must be able to receive up to 100 litres of condensation water per day. The condensation water is lead to an indoor drain (subject to local rules and regulations).

  • Page 8: Stone Caisson

    Route the pipe downward from the air/water heat pump. • The condensation water pipe must have a water seal to prevent air circulation in the pipe. • The installation length can be adjusted by the size of the water seal. Chapter 3 | Pipe connections KVR 10...

  • Page 9: Electrical Connection

    The connection is fitted with a 250 mA fuse EB14 at the factory. FUSE LOCATION Fuse Length, Fuse (F3) Part No. heating cable (m) T100mA/250V 718 085 T250mA/250V 518 900* T500mA/250V 718 086 *Fitted at the factory. KVR 10 Chapter 4 | Electrical connection...
  • Page 10 11.) 14. Reinstall the condensation water trough and cover. NOTE Ensure that the marking on the cable is edge to edge with the drain (see image). NOTE Do not cut the heating cable! Chapter 4 | Electrical connection KVR 10...

  • Page 11: F2030 / F2300

    Part No. heating cable (m) T100mA/250V 718 085 T250mA/250V 518 900* T500mA/250V 718 086 *Fitted at the factory. ELECTRICAL CONNECTION Connect external heating cable (EB14) to terminal block X3:4 and 7 as illustrated below: KVR 10 Chapter 4 | Electrical connection...
  • Page 12 2,600 mm. Marking 13. Connect the cable according to the "Electrical connec- tion" image. (Check fuse according to table. See Fuse page 11.) 14. Reinstall side panel. Chapter 4 | Electrical connection KVR 10...

  • Page 13: F2040

    F2040 Fuse KVR 10 is connected to the communication board AA23- Length, Fuse (F3) Part No. heating X1:4-6 in F2040. Communication board (AA23) is fitted with cable (m) a 250 mA fuse. T100mA/250V 718 085 Främre el FUSE LOCATION T250mA/250V...
  • Page 14 Connection of residual current device RCD (FB1) between control board (PWB1) and communication board (AA23-X1:1-3). 230V/230V 2 AC 230V 1/2 N 230V AA23-X1 AA23-X1 2/1 N 230V 2AC 1/2 3/4 230V 2 AC Chapter 4 | Electrical connection KVR 10...
  • Page 15 2/1 N 2/1 N 1/2 3/4 1/2 3/4 1/2 N 1/2 N 230V 2 AC 230V 2 AC 230V 2/1 N 2/1 N 1/2 3/4 1/2 3/ V 2 AC 230V 2 AC KVR 10 Chapter 4 | Electrical connection...
  • Page 16 2/1 N 2/1 N 1/2 3/4 1/2 3/4 1/2 N 1/2 N 230V 2 AC 230V 2 AC 230V 2/1 N 2/1 N 1/2 3/4 1/2 3/4 V 2 AC 230V 2 AC Chapter 4 | Electrical connection KVR 10...
  • Page 17 230V 230V 2 AC 230V 2 AC 2/1 N 2/1 N 1/2 3/4 1/2 3/4 1/2 N 230V 2 AC 230V 2 AC 230V 2/1 N 1/2 3/4 2 AC 230V 2 AC KVR 10 Chapter 4 | Electrical connection...
  • Page 18 6. Route the heating cable through the condensation water connection on the connection plate, as illustrated. Pull the insulation down slightly, connect the hose to the condensation water connection and tighten the hose clamp, as illustrated. Chapter 4 | Electrical connection KVR 10...
  • Page 19 10. Lay the heating cable and ensure that the marking on the heating cable is as close to the condensation water connection as possible. 11. Route the heating cable to the electrical connection. KVR 10 Chapter 4 | Electrical connection...
  • Page 20 15. Install plugs, see image. F2040-6 F2040-8, F2040-12, F2040-16 Chapter 4 | Electrical connection KVR 10...

  • Page 21: F2050

    F2050 Fuse KVR 10 connects to the communication board (AA23-X1:4- Length, Fuse (F3) Part No. heating 6) in F2050. Communication board (AA23) is fitted with a cable (m) 250 mA fuse. T100mA/250V 718 085 Främre el FUSE LOCATION T250mA/250V 518 900*...
  • Page 22 Connection of residual current device RCD (FB1) between control board (PWB1) and communication board (AA23-X1:1-3). 230V/230V 2 AC 230V 1/2 N 230V AA23-X1 AA23-X1 2/1 N 230V 2AC 1/2 3/4 230V 2 AC Chapter 4 | Electrical connection KVR 10...
  • Page 23 6. Route the heating cable through the condensation water connection on the connection plate, as illustrated. Pull the insulation down slightly, connect the hose to the condensation water connection and tighten the hose clamp, as illustrated. KVR 10 Chapter 4 | Electrical connection...
  • Page 24 10. Lay the heating cable and ensure that the marking on the heating cable is as close to the condensation water connection as possible. 11. Route the heating cable to the electrical connection. Chapter 4 | Electrical connection KVR 10...

  • Page 25: Nibe Split Hbs 05 / Hbs 20

    AA23-X1:2 must be connected to FB1:N. Strip 11 mm from cores that are to be connected to the automatic protection. NIBE SPLIT HBS 05 / HBS 20 FUSE LOCATION, HBS 05 / HBS 20 KVR 10 Chapter 4 | Electrical connection...
  • Page 26 6. Push the insulation up towards the trough and secure it using cable ties, see image. Lay the heating cable and ensure that the marking on the heating cable is as close to the condensation water connection as possible. Chapter 4 | Electrical connection KVR 10...
  • Page 27 AMS 20-6 AMS 10-12 AMS 10-16 AMS 10-8, AMS 20-10 KVR 10 Chapter 4 | Electrical connection...
  • Page 28 9. Install plugs on the underside of AMS 10 / AMS 20. (See image of relevant model.) AMS 10-6 AMS 10-16 AMS 20-6 AMS 10-8, AMS 20-10 10. Mount the junction box on the wall close to AMS 10 / AMS 20. Chapter 4 | Electrical connection KVR 10...
  • Page 29 11. Route the heating cable to the connection box and connect it to the cable from the electrical connection HBS 05 / HBS 20, as illustrated in "Electrical connection". The figure shows the connection in HBS 05 / HBS 20. KVR 10 Chapter 4 | Electrical connection...

  • Page 31: Contact Information

    Tel: +48 (0)85 66 28 490 Hannabadsvägen 5, 285 21 Markaryd Tel. +41 (0)58 252 21 00 biawar.com.pl Tel: +46 (0)433-27 30 00 info@nibe.ch info@nibe.se nibe.ch nibe.se For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information.
  • Page 32 WS release date: 2022-04-12 07:36 Publish date: 2022-06-07 07:53 This is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this publication.
