1 General The accessory KVR 10 is used to safely lead away most of the condensation water from the air/water heat pump to a frost free collection point. The accessory is suitable to following products from NIBE: ■ ■ F2016 F2120 ■...
KVR 10 available in three lengths KVR 10 is available in three lengths. Here you can see an ex- ample of the installation length. Installationslängd Installation length Hose length 1 metres Installation length 1 m without water seal. Product Part No.
■ depth or indoors (subject to local rules and regula- tions). The drain from KVR 10 must be able to receive up to ■ 100 litres of condensation water per day. The installation must be equipped with a water seal ■...
The condensation water pipe must have a water seal ■ to prevent air circulation in the pipe. The installation length can be adjusted by the size of ■ the water seal. Condensation water pipe KVR 10 Chapter 2 | Pipe connections...
518 900* T500mA/250V 718 086 *Fitted at the factory. Electrical connection Connect external heating cable (EB14) to terminal block X3:1 and 4 as illustrated below: KVR 10 F2016/F2026 Heating cable EB14 Chapter 3 | Electrical connection Condensation water pipe KVR 10...
Page 9
14. Reinstall the condensation water trough and cover. NOTE Ensure that the marking on the cable is edge to Marking edge with the drain (see image). NOTE Do not cut the heating cable! Condensation water pipe KVR 10 Chapter 3 | Electrical connection...
X3:4 and 7 as illustrated below: F2030/F2300 KVR 10 Heating cable EB14 Fuse Length Fuse (F3) NIBE Part no. T100mA/250V 718 085 T250mA/250V 518 900* T500mA/250V 718 086 *Fitted at the factory. Fuse location F2300 Chapter 3 | Electrical connection Condensation water pipe KVR 10...
Page 11
2,600 mm. 13. Connect the cable according to the "Electrical con- nection" image. (Check fuse according to table. See Fuse page 10.) 14. Reinstall side panel. Marking Condensation water pipe KVR 10 Chapter 3 | Electrical connection...
Fuse F2040 Length Fuse (F3) NIBE Part no. KVR 10 is connected to the communication board AA23- X1:4-6 in F2040. Communication board (AA23) is fitted with a 250 mA fuse. T100mA/250V 718 085 Främre el T250mA/250V 518 900* Fuse location...
Page 13
1/2 3/4 1/2 3/4 230V 2 AC 230V 2 AC 1/2 N 1/2 N 230V 230V 2/1 N 2/1 N 1/2 3/4 1/2 3/4 Condensation water pipe KVR 10 Chapter 3 | Electrical connection 230V 2 AC 230V 2 A...
Page 14
230V 230V 230V 2 AC 230V 2 AC 2/1 N 2/1 N 1/2 3/4 1/2 3/4 1/2 N 230V 2 AC 230V 2 AC 230V 230V 2/1 N Chapter 3 | Electrical connection Condensation water pipe KVR 10 1/2 3/4...
Page 15
230V 2 AC 2/1 N 2/1 N 1/2 3/4 1/2 3/4 1/2 N 1/2 N 230V 2 AC 230V 2 AC 230V 230V 2/1 N 2/1 N Condensation water pipe KVR 10 Chapter 3 | Electrical connection 1/2 3/4 1/2 3/4...
Page 16
1/2 3/4 230V 230V 230V 2 AC 230V 2 AC 2/1 N 2/1 N 1/2 3/4 1/2 3/4 1/2 N 230V 2 AC 230V 2 AC 230V 2/1 N Chapter 3 | Electrical connection Condensation water pipe KVR 10 1/2 3/4...
Page 17
6. Route the heating cable through the drain pipe on the connection plate, see image. 7. Pull the insulation down slightly, connect the hose to the drain pipe and tighten the hose clamp, as il- lustrated. Condensation water pipe KVR 10 Chapter 3 | Electrical connection...
Page 18
13. Connect the cable according to the "Electrical con- nection" image, see page 12. (Check the fuse accord- ing to the table, see page 12.) 14. Reinstall the cover, front and side panels. Chapter 3 | Electrical connection Condensation water pipe KVR 10...
Connecting automatic protection F2120 Replace miniature circuit breaker (FC1) with automatic KVR 10 is connected to the base board (TCB) AA2-X9 i protection (FB1) if installing KVR 10. Automatic protec- F2120. The connection is fused with 250 mA via fuse tion (FB1) is available as enclosed component for KVR 10.
Page 20
3. Route the heating cable through the condensation water pipe. 4. Route the heating cable through the drain pipe on the reverse of KVR 10. Press the insulation down slightly. 5. Connect the hose to the drain pipe and tighten the L E K hose clamps.
Page 21
10. Connect the cable as illustrated by "Electrical connec- tion", see page 19. (Check the fuse according to the table, see page 19. 11. Reinstall the side and top panels. Condensation water pipe KVR 10 Chapter 3 | Electrical connection...
(see table). Connect external heating cable (EB14) to terminal block AA23-X1:4–6 according to following image: KVR 10 HBS 05 AA23 External heat cable EB14 Chapter 3 | Electrical connection Condensation water pipe KVR 10...
Page 23
7. Stretch the heating cable and ensure that the marking on the heating cable is as close to the drain pipe as possible. Condensation water pipe KVR 10 Chapter 3 | Electrical connection...
Page 24
AMS 10-16 AMS 10-12 AMS 10-16 9. Install plugs on the underside of AMS 10. (See image of relevant AMS 10 model.) AMS 10-8 Chapter 3 | Electrical connection Condensation water pipe KVR 10...
Page 25
11. Route the heating cable to the connection box and connect it to the cable from the electrical connection HBS 05, as illustrated in "Electrical connection". The figure shows the connection in HBS 05. Condensation water pipe KVR 10 Chapter 3 | Electrical connection...
