- Page 1 DME 180 Tyxal+ Outdoor motion detector * Up to 10 years valid under the conditions of use specified in the installation instructions and the General Conditions of Sale...
- Page 2 This motion detector aims to protect the outside of a building by detecting intrusions prior to penetration into the premises. As soon as a presence is detected, it raises the alarm. TYXAL+ DME 180 has an automatic system to protect it against being opened or ripped from its mount.
- Page 3 4. Mounting 5. Activation Wall-mounted On a post Use screws and dowels that are compatible You can mount it onto a post with the mount. using clamps (not provided). ❶ Plug the battery cable into the card connector. ❷ Reposition the sensor/electronic Set the (Tyxal+) alarm control panel to ‘pending card on the base pairing’, then press the pairing button on the card.
- Page 4 6. Detection zone settings 7. Detector range settings for each side Principle: The detection zones from a to n can be easily The high beam always remains parallel to the ground. The low beam can be adjusted as shown below. masked by turning the masking shutter.
- Page 5 8. Detector range settings Low mounting High mounting (17) (30) (30) If the detector is installed at a height of 2 m. Right side (17) In this case, the detection distance is limited to max. 9 m. 2.5 m (8 ft.) 10.0 12.0 (17)
-
Page 6: Troubleshooting
9. Function settings 11. Battery replacement Detection sensitivity settings The LED flashes continuously, the battery is dead. IMPORTANT: Before opening the unit, the alarm control unit must be in Maintenance mode (refer to system installation guide). The sensitivity can be independently adjusted for each side, (L) left and (r) right, to 3 positions: •... - Page 7 Caractéristiques techniques / Technical characteristics / Technische Daten Caratteristiche tecniche / Características técnicas / Technische kenmerken 2xLS 14500 - 3.6 V / 5.2 Ah - Lithium Consumption stand-by : 19 µA Consumption : 4 mA max / 3,6 Vcc [868 - 868.6] MHz and [868.7 - 869.2] MHz 100 m ->...
