- Page 1 DME 90 Tyxal+ Outdoor motion detector * Up to 10 years valid under the conditions of use specified in the installation instructions and the General Conditions of Sale...
- Page 2 3. Location 1. Contents Instructions N°2 Install the motion detector vertically, with its high detection zones parallel to the ground. Important Product If the detector is installed at an angle, Informations detection reliability may be compromised. N°3 2. Presentation Install the motion detector vertically, with both high and low detection zones parallel TYXAL+ DME 90 is a passive infrared motion detector, designed to detect the infrared to the wall.
- Page 3 4. Mounting 5. Commissioning / Detection test ❶ Plug the battery cable into the card ❶ Unlatch the top cover. connector. Set the (Tyxal+) alarm control panel to ‘pending pairing’, then press the pairing ❷ Remove the top cover. button on the card. ❷...
- Page 4 6. Detection zone settings 7. Detector range settings Principle: Because the protection zone can be disrupted by various elements (leaves, Principle: reflective surface...), you have the ability to select its orientation. The high beam always remains parallel to the ground. The low beam can be adjusted as shown below.
- Page 5 7. Detector range settings 8. Special detection zone Select the desired position (1,2,3,4 or 5). The low beam can be adjusted to control the range, as per the table below. Put the top cover in its place to perform an automatic detection test. The LED flashes with each detection.
-
Page 6: Troubleshooting
9. Function settings 11. Battery replacement The LED flashes continuously, the battery is dead. Detection sensitivity settings Before opening the unit, the alarm control unit must be in "Maintenance" mode (refer to system installation guide). The sensitivity can be set to 3 different positions: •... - Page 7 Caractéristiques techniques / Technical characteristics / Technische Daten Caratteristiche tecniche / Características técnicas / Technische kenmerken 2xLS 14500 - 3.6 V / 5.2 Ah - Lithium Consumption stand-by : 9 µA Consumption : 4 mA max / 3 Vcc [868 - 868.6] MHz and [868.7 - 869.2] MHz 100 m Ý...
