LUMIEN W3A1-2.5W-27K-BZ Instruction Manual

WARNING – To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before replacing lamp.
• Lamp gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the hot lens, guard, or enclosure.
• Keep lamp away from materials that could burn.
• Do not touch the lamp at any time. Use a soft cloth. The oils from skin could damage lamp.
• Do not operate the fixture with a missing or damaged shield.
WARNING – Risk of Electric Shock:
• Install all luminaires at least 10 feet (3.05 m) from a pool, spa, fountain, etc.
• A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.

IMPORTANT:

DO NOT EXCEED 15 VOLTS IN THIS FIXTURE!
This fixture functions best when the incoming voltage is between 10–15 volts. Voltages outside of this range could
damage the fixture, shorten the life, and cause unsatisfactory performance. The use of improper voltage voids the
product warranty.

TRANSFORMERS

• Only use a UL1838 transformer for safety reasons and to ensure full lifespan of the fixture.
• When using ONE transformer, it is very important to center the transformer on the wattage load to minimize cable
runs.
• When using MULTIPLE transformers, it is very important to position the transformers as close to the fixtures as
possible to minimize cable runs.
Lumien Lighting | Website:
INSTRUCTION MANUAL
Integrated LED
(
Models: W3A1-2.5W-27K-BZ W3A1-2.5W-30K-BZ
W3A1-2.5W-27K-BK W3A1-2.5W-30K-BK
www.lumienlighting.com
)
Wattage 2.5W
Voltage Range 10-15V
Lumen Output 180 Lumens
Color Temp 3000K (Standard),2700K
CRI 80+
Lifespan 50,000 Hrs.
Finishes Bronze (Standard),
Options: Black
Housing Aluminum
Material
Wet Rated? Yes
Light Source Integrated LED
|E-mail: orders@lumienlighting.com
