• Turn off/unplug the fixture and allow to cool before handling; making any adjustments or repairs or replacing the
integrated light module.
• Integrated light module gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the lens, guard, or enclosure when hot.
• Keep integrated light module away from materials that could ignite/ combust/ burn.
• Do not touch the integrated light module chip at any time. Use a soft cloth. The oils from skin could damage LED.
● Install in accordance with all local codes and ordinances.
●
A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.
TRANSFORMER
●
Install in accordance with all local codes and ordinances.
●
Only use a UL1838 transformer for safety reasons and to ensure full lifespan of the fixture.
●
Ensure that the transformer is plugged in to a GFCI protected circuit.
Lumien Lighting | Website:
INSTRUCTION MANUAL
(MODULAR LED)
Wattage
Voltage Range
Lumen Output
Color Temp
CRI
Lifespan
Finishes
Housing
Material
Wet Rated?
Light Source
WARNING – To reduce the risk of FIRE OR INJURY TO PERSON:
WARNING – Risk of Electric Shock:
IMPORTANT
www.lumienlighting.com
Z4B1
Z7B1
Z9B1
CORE
PRO
10 Watts
WW: 10 Watts
RGBWW: 10 Watts
10-15V
10-15V
800 Lumens
WW: 610 Lumens
RGBWW: 445 Lumens
2700K/3000K
WW/RGBWW
80+
80+
50,000 Hrs.
50,000 Hrs.
Antique
Antique
Brass
Brass
Yes
Yes
LED Module
LED Module
| E-mail: orders@lumienlighting.com
