LUMIEN M4B5-5.5W-27K-R Instruction Manual

WARNING – To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before replacing lamp.
• Lamp gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the hot lens, guard, or enclosure.
• Keep lamp away from materials that could burn.
• Do not touch the lamp at any time. Use a soft cloth. The oils from skin could damage lamp.
• Do not operate the fixture with a missing or damaged shield.
WARNING – Risk of Electric Shock:
• Install all luminaires at least 10 feet (3.05 m) from a pool, spa, fountain, etc.
• A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.
•
Use only in ponds and small decorative fountains where persons will immerse no more than their hands and lower
arms while the product is energized.
• DO NOT use in water intended for swimming, wading, immersion, or bathing.
• All installer completed cable connections must be located outside of pond or fountain.
• Low voltage circuit must be supplied by a power unit marked as suitable for supplying submersible luminaires.
• Power unit must be supplied by a circuit protected by a ground fault circuit interrupter (GFCI).
• "Maximum depth: 118 in (3m)_"
IMPORTANT:
DO NOT EXCEED 15 VOLTS IN THIS FIXTURE!
This fixture functions best when the incoming voltage is between 10–15 volts. Voltages outside of this range could
damage the fixture, shorten the life, and cause unsatisfactory performance. The use of improper voltage voids the
product warranty.
Lumien Lighting | Website:
INSTRUCTION MANUAL
(INTEGRATED LED)
|
M4B5-5.5W-27K-R M4B6-5.5W-27K-R
|
M4B5-5.5W-30K-R M4B6-5.5W-30K-R
www.lumienlighting.com
Models:
|
M4B9-5.5W-27K-R
|
M4B9-5.5W-30K-R
Wattage 5.5W
Voltage 10-15V
Range
Lumen 346 Lumens
Output
Color Temp 3000K, 2700K
CRI 80+
Lifespan 50,000 Hrs.
Finishes Antique
Housing Brass
Material
Wet Rated? Yes
Light Modular LED
Source
