LUMIEN A3A3 Instruction Manual

RGBWW PRO
WARNING – To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before replacing lamp.
• Lamp gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the hot lens, guard, or enclosure.
• Keep lamp away from materials that could burn.
• Do not touch the lamp at any time. Use a soft cloth. The oils from skin could damage lamp.
• Do not operate the fixture with a missing or damaged shield.
WARNING – Risk of Electric Shock:
• Install all luminaires at least 10 feet (3.05 m) from a pool, spa, fountain, etc.
• A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.
IMPORTANT:
DO NOT EXCEED 15 VOLTS IN THIS FIXTURE!
This fixture functions best when the incoming voltage is between 10–15 volts. Voltages outside of this range could
damage the fixture, shorten the life, and cause unsatisfactory performance. The use of improper voltage voids the
product warranty.
Lumien Lighting | Website:
INSTRUCTION MANUAL
(INTEGRATED LED)
MODELS
CORE
www.lumienlighting.com
A3A3
A9A3

Wattage

6W

Voltage

10-15V
Range
Lumen A3A3: 450 Lumens
Output A9A3: XXX Lumens
Color Temp 2700K 3000K RGBWW

CRI

80+

Lifespan

50,000 Hrs.

Finishes

Bronze Black
Housing Aluminum
Material
Light Integrated LED
Source
| E-mail: orders@lumienlighting.com
