Models: R5A1-10W-27K-BZ | R5A2-10W-27K-BZ | R5A3-10W-27K-BZ
WARNING – To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before replacing lamp.
• Lamp gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the hot lens, guard, or enclosure.
• Keep lamp away from materials that could burn.
• Do not touch the lamp at any time. Use a soft cloth. The oils from skin could damage lamp.
• Do not operate the fixture with a missing or damaged shield.
WARNING – Risk of Electric Shock:
• Install all luminaires at least 10 feet (3.05 m) from a pool, spa, fountain, etc.
• A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.
Lumien Lighting | Website:
INSTRUCTION MANUAL
(INTEGRATED LED)
R5A1-10W-30K-BZ | R5A2-10W-30K-BZ | R5A3-10W-30K-BZ
www.lumienlighting.com
Wattage
10W
Voltage
10-15V
Range
Lumen
500 Lumens
Output
Color Temp
2700K (Standard),
Options: 4000K
Beam
10-70⁰
Angle
CRI
80+
Lifespan
50,000 Hrs.
Finishes
Bronze (Standard),
Options: Black, White
Housing
Aerospace Grade
Material
Aluminum
Wet Rated?
Yes
Light
Integrated LED
Source
| E-mail: sales@lumienlighting.com
Advertisement
Related Manuals for LUMIEN R5A1-10W-27K-BZ
Summary of Contents for LUMIEN R5A1-10W-27K-BZ
- Page 1 INSTRUCTION MANUAL (INTEGRATED LED) Models: R5A1-10W-27K-BZ | R5A2-10W-27K-BZ | R5A3-10W-27K-BZ R5A1-10W-30K-BZ | R5A2-10W-30K-BZ | R5A3-10W-30K-BZ Wattage Voltage 10-15V Range Lumen 500 Lumens Output Color Temp 2700K (Standard), Options: 4000K Beam 10-70⁰ Angle Lifespan 50,000 Hrs. Finishes Bronze (Standard), Options: Black, White...
- Page 2 • For maximum light output, adjust lighting circuits to provide between 10-15 volts. • Voltage can be regulated by adjusting circuit load/run. • To determine circuit voltage, use a digital voltmeter. PARTS Lumien Lighting | Website: www.lumienlighting.com | E-mail: sales@lumienlighting.com...
- Page 3 When installing and maintaining the fixtures, be sure to remove leaves, pine needles, grass clippings, mulch, or any debris that has accumulated on the light bulb, lens, or body of the fixture. Lumien Lighting | Website: www.lumienlighting.com | E-mail: sales@lumienlighting.com...
- Page 4 The manufacturer specifically disclaims any liability and shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product. Lumien Lighting | Website: www.lumienlighting.com | E-mail: sales@lumienlighting.com...
