LUMIEN N4B2 Instruction Manual

MODELS
WARNING – To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before handling; making any adjustments or repairs or replacing the
integrated light module.
• Integrated light module gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the lens, guard, or enclosure when hot.
• Keep integrated light module away from materials that could ignite/ combust/ burn.
• Do not touch the integrated light module chip at any time. Use a soft cloth. The oils from skin could damage LED.
● Install in accordance with all local codes and ordinances.
● A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.
TRANSFORMER
● Install in accordance with all local codes and ordinances.
● Only use a UL1838 transformer for safety reasons and to ensure full lifespan of the fixture.
● Ensure that the transformer is plugged in to a GFCI protected circuit.
FIXTURE
(DO NOT EXCEED 15 VOLTS INPUT)
•
Install in accordance with all local codes and ordinances.
•
This fixture functions best when the incoming voltage is between 10–15 volts. Voltages outside of this range
could damage the fixture, shorten the life, and cause unsatisfactory performance. The use of improper voltage
voids the product warranty.
Lumien Lighting | Website:
INSTRUCTION MANUAL
(INTEGRATED LED)
WARNING – Risk of Electric Shock:
IMPORTANT
www.lumienlighting.com
N4B2
Wattage 2W
Voltage 10-15V
Range
Lumen 186 Lumens
Output
Color Temp 2700K/3000K
CRI 80+
Lifespan 50,000 Hrs.
Finishes Antique
Housing Brass
Material
Wet Rated? IP68
Light Source LED Module
| E-mail: orders@lumienlighting.com
