WARNING – To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before handling; making any adjustments or repairs or replacing the
integrated light module.
• Integrated light module gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the lens, guard, or enclosure when hot.
• Keep integrated light module away from materials that could ignite/ combust/ burn.
• Do not touch the integrated light module chip at any time. Use a soft cloth. The oils from skin could damage LED.
Lumien Lighting | Website:
INSTRUCTION MANUAL
(INTEGRATED LED)
Wattage
Voltage Range
Lumen Output
Color Temp
CRI
Lifespan
Finishes
Housing
Material
Wet Rated?
Light Source
www.lumienlighting.com
N4B3
N7B3
N8B3
CORE
3W
WW: 3W
RGBW: 3W
10-15V
10-15V
15°: 175 Lumens
WW: 110 Lumens
30°: 275 Lumens
RGBW: 40 Lumens
2700K/3000K
WW/RGBW
80+
80+
50,000 Hrs.
50,000 Hrs.
Antique
Antique
Brass
Brass
IP68
IP68
Integrated LED
Integrated LED
| E-mail: orders@lumienlighting.com
PRO
Advertisement
Table of Contents
Related Manuals for LUMIEN N4B3
Summary of Contents for LUMIEN N4B3
- Page 1 • Keep integrated light module away from materials that could ignite/ combust/ burn. • Do not touch the integrated light module chip at any time. Use a soft cloth. The oils from skin could damage LED. Lumien Lighting | Website: www.lumienlighting.com...
- Page 2 • For maximum light output, adjust lighting circuits to provide between 10-15 volts. • Voltage can be regulated by adjusting circuit load/run. • To determine circuit voltage, use a digital voltmeter at the fixture. Lumien Lighting | Website: www.lumienlighting.com | E-mail: orders@lumienlighting.com...
- Page 3 Using Standard Spike – LAP-002 Using Quick Connect Spike Surface Mount (Using J-Box) Recessed A - Shroud B – Module/Knuckle C- O-Ring D - Female Connector E- Set Screw F-Lock Nut J- Spike I-Waterproof Wire Nuts Lumien Lighting | Website: www.lumienlighting.com | E-mail: orders@lumienlighting.com...
- Page 4 The manufacturer specifically disclaims any liability and shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product. Lumien Lighting | Website: www.lumienlighting.com | E-mail: orders@lumienlighting.com...
