DS-K5604A-3XF Series
Face Recognition Terminal
Quick Start Guide
UD19290B-F
© 2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
This Manual is the property of Hangzhou Hikvision Digital Technology Co., Ltd. or its affiliates (hereina�er
referred to as "Hikvision"), and it cannot be reproduced, changed, translated, or distributed, par�ally or
wholly, by any means, without the prior wri�en permission of Hikvision. Unless otherwise expressly stated
herein, Hikvision does not make any warran�es, guarantees or representa�ons, express or implied,
regarding to the Manual, any informa�on contained herein.
About this Manual
The Manual includes instruc�ons for using and managing the Product. Pictures, charts, images and all other
informa�on hereina�er are for descrip�on and explana�on only. The informa�on contained in the Manual is
subject to change, without no�ce, due to firmware updates or other reasons. Please find the latest version
of this Manual at the Hikvision website (h�ps://www.hikvision.com/).
Please use this Manual with the guidance and assistance of professionals trained in suppor�ng the Product.
Trademarks Acknowledgement
and other Hikvision's trademarks and logos are the proper�es of Hikvision in various
jurisdic�ons.
Other trademarks and logos men�oned are the proper�es of their respec�ve owners.
LEGAL DISCLAIMER
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT DESCRIBED,
WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH ALL FAULTS AND
ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE
PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS
OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY RISKS, AND
HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR
OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER
INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE SOLELY
RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. ESPECIALLY, YOU ARE
RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF
THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS,
OR DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY
PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS
DESTRUCTION, THE DEVELOPMENT OR PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY
ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN
SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS.
Data Protec�on
During the use of device, personal data will be collected, stored and processed. To protect data, the
development of Hikvision devices incorporates privacy by design principles. For example, for device with
facial recogni�on features, biometrics data is stored in your device with encryp�on method; for fingerprint
device, only fingerprint template will be saved, which is impossible to reconstruct a fingerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with the
applicable data protec�on laws and regula�ons, including without limita�on, conduc�ng security controls to
safeguard personal data, such as, implemen�ng reasonable administra�ve and physical security controls,
conduct periodic reviews and assessments of the effec�veness of your security controls.
Scan the QR code to get the user manual for detailed informa�on.
Note that mobile data charges may apply if Wi-Fi is unavailable.
Use only power supplies listed in the user instruc�ons:
Model
Manufacturer
Standard
C2000IC12.0-24P-DE
MOSO Power Supply Technology Co., Ltd. CEE
C2000IC12.0-24P-GB
MOSO Power Supply Technology Co., Ltd. BS
ADS-24S-12 1224GPG Shenzhen Honor Electronic Co., Ltd.
CEE
1
Appearance
37 mm
144.71 mm
165 mm
185.91 mm
172 mm
250.71 mm
Device Wiring (Normal)
Power
Power
Door Lock
Switch
Interface
Interface
USB Interface
Network
Interface
(Reserved)
69.96 mm
Thermographic
Module
White Light
IR Light
IR Light
Camera
Touch Screen
The figures are for reference only.
RS-485
Interface
The wiring diagram of RS-485 and Door Lock on the left is shown below:
BTN
Network
Interface
2
Installation
Installa�on Environment:
Temperature Measurement Environment:
Avoid backlight, direct sunlight, and indirect sunlight.
Sunlight, wind, hot/cool air from air condi�oner and other external factors,
For be�er recogni�on, there should be light source in or near
which may affect surface temperature, will create the devia�on of the
the installa�on environment.
temperature measurement. In order to get an accurate result, make sure
the device is applied indoors and windlessly (where is rela�vely isolated
from the outdoors). The working temperature should keep between 10 °C
and 35 °C. If there are no suitable environments for temperature measure-
ment (the area faces the indoor and connects the outdoor, the area at the
door of the indoor environment, etc.), building a temporary temperature
measurement environment is suggested.
Influence Factors of Temperature Measurement:
Wind: The wind will take the heat away, which may affect the measurement
result.
Backlight
Direct Sunlight
Sweat: The sweat will take the heat away, which may affect the measure-
ment result.
Air Condi�oner (Cool Air): If the indoor temperature is low, the surface
Close to Light
temperature may also lower than the actual temperature, which may affect
the measurement result.
Air Condi�oner (Heat) or Hea�ng: If the indoor temperature is high, the
surface temperature may also higher than the actual temperature, which
may affect the measurement result.
Indirect Sunlight
Direct Sunlight
In order to make the device work properly, you should wait for 90 min a�er
the device is powered on.
through Window
through Window
The actual device
appearance varies
according to
different models.
M6×65 Expension Bolt
Bracket
2
3
1
Bottom Cover
Bottom Screw
Ground
(NC)
(COM)
(NO)
Door Contact
Before you start: Make sure the ground surface has drilled
holes for device installation.
Steps:
1. Remove the two bottom screws (2-SC-KM3×5B-JMF) on
both sides of the bottom cover. And remove the bottom
cover.
2. Align the device with the drilled holes on the ground and
insert 3 supplied expension bolts (M6×65). Make sure the
expension bolts are higher than the ground.
3. Secure the expension bolts with nuts。
4. Install the bottom cover back on the device with 2 bottom
screws.
5. After installation, for the proper use of the device (outdoor
use), stick the protection film (parts of models supplied) on
the screen.
The device should be installed on the concrete surface or other
non-flammable surfaces.
The device supports plug & play. You can put the device on the
ground and start operation after powering on.
When connecting door contact and exit button, the device and
the RS-485 card reader should use the common ground
connection.
The suggested external power supply for door lock is 12 V, 1A.
