MURELLE HE 35 R ErP
ENSURE THAT THESE
USER, INSTALLATION AND SERVICING INSTRUCTIONS
INSTRUCTIONS
ARE
LEFT FOR THE USER
AFTER
COMPLETION
OF
THE
BENCHMARK
SECTION PLEASE READ
THE IMPORTANT NOTICE
WITHIN
THIS
GUIDE
REGARDING
YOUR
BOILER WARRANTY
EN
199839
Cod. 6330953 - 01/2021 - R2
Fonderie SIME S.p.A
ORIGINAL INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the MURELLE HE 35 R ErP and is the answer not in the manual?

Questions and answers

Related Manuals for Sime MURELLE HE 35 R ErP

Summary of Contents for Sime MURELLE HE 35 R ErP

  • Page 1 MURELLE HE 35 R ErP ENSURE THAT THESE USER, INSTALLATION AND SERVICING INSTRUCTIONS INSTRUCTIONS LEFT FOR THE USER AFTER COMPLETION BENCHMARK SECTION PLEASE READ THE IMPORTANT NOTICE WITHIN THIS GUIDE REGARDING YOUR BOILER WARRANTY 199839 Cod. 6330953 - 01/2021 - R2 Fonderie SIME S.p.A...
  • Page 2 As you would expect from Sime Ltd, it is our aim to provide our valued customers with the best in after sales and service. To take advantage of any extended warranty offered, all you have to do is to adhere to these 3 simple condi-tions: •...
  • Page 4 The Benchmark Scheme Sime Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance.
  • Page 5 FOR INSTALLER CONTENTS DESCRIPTION OF THE BOILER ..........................6 INSTALLATION ..............................10 CHARACTERISTICS ............................23 COMMISSIONING, USE AND MAINTENANCE ....................30 VERY IMPORTANT! PLEASE MAKE SURE YOUR COMMISSIONING CHECKLIST AND THE SERVICE INTERVAL RECORDS ENCLOSED FILLED IN CORRECTLY. ALL GAS SAFE REGISTERED INSTALLERS CARRY A GAS SAFE ID CARD. BOTH SHOULD BE RECORDED IN YOUR COMMISSIONING CHECKLIST AND A SERVICE INTERVAL RECORDS.

  • Page 6: Description Of The Boiler

    DESCRIPTION OF THE BOILER INTRODUCTION (from 20% to 100% of power) designed for For optimum installation and operation, single installation and in modular systems always follow the instructions provided in with multiple generators connected in this manual. Le MURELLE HM 35 R ErP are premixed sequence/cascade and independent from gas condensing boilers for heating only each other.
  • Page 7 TECHNICAL FEATURES DESCRIZIONE U.M. MURELLE HE 35 R ErP Heat output nominal (80-60°C) (Pn max) 33,8 Heat output nominal (50-30°C) (Pn max) 37,2 Heat output reduced G20 (80-60°C) (Pn min) Heat output reduced G20 (50-30°C) (Pn min) Heat output reduced G31 (80-60°C) (Pn min) Heat output reduced G31 (50-30°C) (Pn min)
  • Page 8 FUNCTIONAL DIAGRAM (fig. 2) Exhaust temperature sensor (SE) Heating flow sensor (SM) Gas valve Safety thermostat 100°C Aqua Guard Filter System 10 Pump high efficiency 11 Heating return sensor (SR) 13 Condensate drain trap 14 Safety valve 3 bar 15 Water pressure transducer 16 Boiler discharge 17 Primary heat exchanger CONNECTIONS...
  • Page 9 TECHNICAL DATA PLATE MODEL MODELLO TYPE TIPO APPARECCHIO SERIAL NUMBER NUMERO DI SERIE CODE CODICE YEAR OF CONSTRUCTION ANNO DI COSTRUZIONE PIN NUMBER NUMERO PIN DIRECTIVE OF REFERENCE DIRETTIVA DI RIFERIMENTO WATER CONTENT IN BOILER CONTENUTO D’ACQUA IN CALDAIA HEAT INPUT MAX PORTATA TERMICA MAX HEAT INPUT MIN PORTATA TERMICA MIN...

  • Page 10: Installation

    35 R (M) boilers and cascade systems. compliance with all instructions contained A single Murelle HE 35 R ErP (34,8 KW net in this manual. BS6644 has a requirement that the tem- input) boiler would require 174 cm² at high...
  • Page 11 It is possible to connect each individual press buttons The parameters for Sime Murelle HE boiler in MODBUS mode using the kit cod. to exit the menu and go back to the boilers in a cascade can be displayed and...
  • Page 12 WARNING: The manufacturer is not responsible for any WARNING: The external temperature sensor “SE” is damage caused by failure to earth the appliance or failure OBLIGATORY and MUST be connected to the master boiler to observe the information provided in the wiring diagrams WARNING: The external temperature sensor “SE”...
  • Page 13 2.4.3 Requirements for sealed water propane). the burner when the temperature of the systems MURELLE HE 35 R ErP water contained inside the appliance drops (fig. 5/b) An adhesive data plate is positioned inside to below 6°C.
  • Page 14 Ignition transformer (TRA) Condensate drain tap Gas valve Pressure transducer (TPA) Pump high efficiency (PI) Boiler discharge Safety valve 3.5 bar Fig. 5 Hose Double check unions valve assembly Heating circuit Mains return water supply Stop Stop valve valve Test cock Filling loop temporarily connected Fig.
  • Page 15 80 mm accessories TYPE B Code Description Load loss (mm H 8077450A single) 90° bend 8077450 (6 pieces) 8077351A (single) 1000mm Extension 0,25 8077351 (6 pieces) 8077350A (single) 500mm Extension 0,25 8077350 (6 pieces) 8091300 Articulated Tile 8091212B Roof terminal (1381mm) 6296513 Extension with test point (250mm) 8077451A (single)
  • Page 16 (clean electrical contact). spacing between contacts. Respect the L and N polarities and the earth connection. NOTE: SIME declines all responsibility for injury or damage to persons, animals or property, resulting from the failure to provide for proper earthing of the appliance.
  • Page 17 BASIC SYSTEM SYSTEM WITH A DIRECT ZONE AND ROOM THERMOSTAT, OR WITH Some examples are given below of REMOTE CONTROL SIME HOME (Code 8092280/81) AND EXTERNAL boiler systems combined with different SENSOR (Code 8094101) electronic systems. Where necessary, the parameters to be set in the boiler are given.
  • Page 18 3 BASIC SYSTEM MULTI-ZONE SYSTEM WITH PUMP, ROOM THERMOSTAT AND EXTERNAL SENSOR (Code 8094101) BASIC SYSTEM IMULTI-ZONE SYSTEM WITH VALVE, ROOM THERMOSTAT, REMOTE CONTROL SIME HOME (Code 8092280/81) AND EXTERNAL SENSOR (Code 8094101) PARAMETERS SETTINGS To use the remote control...
  • Page 19 BASIC SYSTEM MULTI-ZONE SYSTEM WITH PUMP, ROOM THERMOSTAT, REMOTE CONTROL SIME HOME (Code 8092280/81) AND EXTERNAL SENSOR (Code 8094101) PARAMETER SETTING To use the remote control SIME HOME (CR) as room reference for a zone, set: PAR 7 = 1...
  • Page 20 BOLLITORE BOLLITORE SYSTEM WITH MIXER VALVE SYSTEM WITH ONE DIRECT ZONE, ONE MIXED ZONE, ONE KIT MIXED ZONE (Code 8092275), REMOTE CONTROL SIME HOME (Code 8092226) AND EXTERNAL SENSOR (Code 8094101) BOLLITORE PARAMETERS SETTINGS To use the remote control SIME HOME (CR) as remote...
  • Page 21 SYSTEM SOLAR SYSTEM WITH TWO MIXED ZONE INDEPENDENT, ONE DIRECT ZONE, TWO KITS MIXED ZONE (Code 8092275 AND 80922766), ONE KIT SOLAR INSOL (Code 8092277), REMOTE CONTROL SIME HOME (Code. 8092280/81) AND EXTERNAL SENSOR (Code 8094101) Murell e HM T/HE T-R ErP...
  • Page 22 6319158 Pump high efficiency Zone 2 environment thermostat code 6319144 D.H.W. sensor L. 2000 (optional) code 6319156 Limit thermostat Remote control SIME HOME (optional) code 6316203 Ignition electrode External sensor (optional) Ionisation electrode Programming clock (optional) code 6316200 EV1-2...

  • Page 23: Characteristics

    ON/OFF KEYS PC CONNECTION ON = Electricity supply to boiler is on To be used only with the SIME programming kit OFF = Electricity supply to boiler is on but not ready and only by authorised personnel. Do not connect for functioning.
  • Page 24 ACCESS TO INSTALLER’S INFORMATION For access to information for the installer, press the key (3 fig. 12). Each time the key is pressed, the display moves to the next item of information. If expansion boards (MIXED ZONE o SOLARE) are connected, the related info will be displayed. If the key is not pressed, the system automatically quits the function.
  • Page 25 29. Display of valve operation with board MIXED ZONE 2 18. Display of heating return temperature sensor (SR) 18. Visualizzazione valore sonda ritorno riscaldamento (SR) 29. Visualizzazione comando chiusura valvola con schedino (respectively ON and OFF) ZONA MIX 2 (rispettivamente ON e OFF) 30.
  • Page 26 Luminous bar indicating presence of 0 = Disabled voltage 1 = Enabled Allocation of SIME HOME channels 0 = Not assigned The standard display returns automatically re in h x 100 (es. 14.000 e 10) 1 = Circuit 1...
  • Page 27 PARAMETERS INSTALLER BOILER PAR 1 EXPANSION CARD Instantanious with diverter DESCRIPTION RANGE U.M. INC/DEC DEFAULT valve and flowmeter UNIT SETTING Instantanious with diverter Number of expansion boards 0 ... 3 valve, flowmeter and solar Mix valve stroke time 0 ... 199 10 sec.
  • Page 28 It can Interface with the following electronic be caused by a closed gas tap or by 12.090 systems: remote control SIME HOME, a broken valve coil (the interruption thermal regulator RVS, connected to 8.313 does not allow for opening).
  • Page 29 POMPA FISSA – No flame detected HEAD AVAILABLE TO SYSTEM POMPA MODULANTE WILO-YONOS PARA PWM (M) After start-up the electrode continues to (fig. 14) discharge even when the burner is on. Residual head for the heating system is After 10 seconds, the discharge stops, shown as a function of rate of flow in the burner is switched off and a fault is the graph in fig.

  • Page 30: Commissioning, Use And Maintenance

    3. Combustion check working gas supply pressure. If required Connect the flue gas analyser to the 1. Check the operational (working) gas contact Sime Ltd for further assistance. flue gas sampling point as shown in the inlet pressure. diagram (fig. 15/a).
  • Page 31 This operation must be performed by To change the fuel to propane (G31), it is (Methane) (Propane) authorised personnel using original Sime necessary to set SET 11, by pressing the 9,3 ±0,2 10,2 ±0,3 components. To convert from natural gas to LPG or vice versa, perform the following (es.
  • Page 32 MAX power (Methane) (Propane) 9,3 ±0,2 10,2 ±0,3 Codice/Code 8113370 Modello/Model MURELLE HE 35 R Matricola/Serial n. 9999999999 PAR 1 = 3 (G20) / 11 (G31) PAR 2 = 5 ATTENTION Before removing or refitting the front panel of the boiler, open the small upper plastic door.
  • Page 33 4.5.1 Chimney sweep function (fig. 21) To check boiler combustion, press the installer’s key for a few seconds. The chimney sweep function will switch on and will continue for 15 minutes. The boiler will start working in heating mode at maximum power, with cut off at 80°C and re-ignition at 70°C (ATTENTION! Ensure adequate circulation to the heating system is available before...
  • Page 34 4.5.3 Operation floor drying (fig. 22/a) The operation can be stopped by turning ATTENTION: the boiler off, or automatically at the end of Observe the relevant standards and The operation floor drying keeps the floor the cycle, or by altering PAR 43 to 0. regulations of the floor manufacturer.
  • Page 35 FUNCTIONING ERRORS Circuito When there is a functioning error, an riscaldamento 2 alarm appears on the display and the blue Circuito riscaldamento 2 luminous bar may becomes red. Apre Descriptions of the errors with relative Circuito alarms and solutions are given below: riscaldamento 2 Circuito Fig.
  • Page 36 SAFETY/LIMIT THERMOSTAT ERROR “ALARM 07” (fig. 23/6) If the connection with the safety Circuito thermostat/ limit thermostat riscaldamento 2 interrupted, the boiler will stop; the flame control will remain waiting to be switched off for one minute, keeping the system pump on for that period. If, Apre the thermostat connection is restored within the minute, the boiler will start...
  • Page 37 rcuito scaldamento 2 Circuito riscaldamento 2 FAN ERROR ALL 15 (fig. 23/12) SAFETY THERMOSTAT AUXILIARY SENSOR ERROR (S3) The fan speed does not fall within INTERVENTION SECOND MIXED “ALL 26” (fig. 23/20) the rated speed range. If the error ZONE “ALL 22”...
  • Page 38 When the boards connected to the RS- cascade connection, error codes 70 and 485 are not enough and/or at least one 71 will appear on the SIME HOME remote of them it is not mixing zone board, control display: the boiler stops and anomaly ALL 32 is displayed.
  • Page 39 USER INSTRUCTIONS WARNINGS – In case of failure or malfunction of the equipment, contact authorised technical staff. – For safety reasons, the User cannot access the internal parts of the appliance. All operations involving the removal of protections or otherwise the access to dan- gerous parts of the appliance must be performed by qualified personnel.
  • Page 40 3 technical personnel. (impianto tre zone) ALL 70 e ALL 71 These alarms appear on the SIME TO SWITCH OFF THE BOILER (fig. 24) HOME remote control display. Request Fig. 27/c assistance from qualified technical In the case of a short absence, press the personnel.
  • Page 41 FAULT FINDING than infinity (∞) there is a fault which should be isolated. A detailed continuity If an electrical fault occurs on the appliance check is required to trace the faulty the preliminary electrical system checks component. must be carried out first. When any service or replacement of IMPORTANT: These series of checks are electrical components which has required...
  • Page 42 Isolate the flow and return valves, and drain Apply heat conducting paste to the be used that are not supplied by Sime Ltd, the boiler using the drain vents provided. replacement stat. and only suitably qualified personnel are Protect any electrical equipment from Refit in reverse order.
  • Page 43 EXPLODED VIEWS...
  • Page 44 UK HYDRAULIC COMPENSATOR KIT...
  • Page 45 ------------------------------------------------------------------------------------------------ Pos. Code Description Model ------------------------------------------------------------------------------------------------ 6138533 Right hand side frame part 6138632 Left hand side frame part 6255431 Expansion vessel lower support 6318070 Frame assembly lower side 6266081 Rear panel 6256751 Upper protection fixing bracket 6277207 Water trap 6010831 Main exchanger supporting bracket 6010829 Main exchanger fixing bracket...
  • Page 46 ------------------------------------------------------------------------------------------------ Pos. Code Description Model ------------------------------------------------------------------------------------------------ 6226619 Spring for heat exchanger connection 6146701 100°C safety stat 6022010 Sensor gasket 6231351 Plunged sensor 6120560 Pump nipple 3/4" 6226644 Spring clip for rotating connection 6040212 Press. relief valve 1/2" 3.5 bar 6226475 ORing diam.18,64x3,53 6243837 Gas valve...
  • Page 47 ---------------------------------------------------------------------------------------------------- Pos. Code Description Model ---------------------------------------------------------------------------------------------------- 6245108 D.H.W. expansion vessel l. 8 2040250 Nipple 1-1/2" x 1" 6216263 C.H. flow pipe 6227442 C.H. return pipe 6227698 Pipe connecting expans. vessel 6104702 Adaptors M.F. 1" x 3/4" 2030254 Gasket Ø 33x44x3 2030257 Gasket diam.
  • Page 48 Manufacturers Instructions Manufacturer’s instructions must be followed for the correct connection of the condensate discharge pipe from the boiler as this may vary due to the design of the boiler. For example a visible air break and trap is not required if there is a trap with a minimum condensate seal of 75 mm incorporated into the boiler.
  • Page 49 Figure 1 – Connection of condensate discharge pipe to internal soil and vent stack. Note – Check manufacturer’s instructions to see if an air break is required. Boiler Visible air break 75 mm trap Visible air break and trap not required if there is a trap with a minimum condensate seal of 75 mm incorporated into the boiler Soil and vent stack Invert...
  • Page 50 Internal Condensate Pipe Discharge Termination Figure 2(a) – Connection of a condensate discharge pipe downstream of a sink, basin, bath or shower waste trap. Note – Check manufacturer’s instructions to see if an air break is required. Boiler Visible air break 75 mm trap Visible air break and trap not required if there is a trap with a minimum condensate seal of 75 mm incorporated into the boiler.
  • Page 51 Internal Condensate Pipe Discharge Termination Figure 2(b) – Connection of a condensate discharge pipe upstream of a sink, basin, bath or shower waste trap Boiler Visible air break at plug hole – alternative connection can be below sink trap 75 mm sink, basin, bath or shower waste trap Open end of condensate discharge pipe direct into gully 25 mm min below grating but above water level;...
  • Page 52 Internal Condensate Pipe Discharge Termination The possibility of waste pipes freezing downstream of the connection point should be considered when determining a suitable connection point - e.g. a slightly longer pipe run to an internal soil stack may be preferable to a shorter run connecting into a kitchen waste pipe discharging directly through the wall to an external drain.
  • Page 53 Internal Condensate Pipe Discharge Termination Figure 3 – Connection of a condensate pump - typical method (NB manufacturer’s detailed instructions should be followed). Note – Any external pipe work should be insulated, pipe cut at 45 degrees and a drain/ leaf Condensate discharge from boiler Condensate pump Visible air break at plug hole...
  • Page 54 External Connections External Connections pumped connection is impractical to install. The pipe work from the boiler should be of a minimum 19mm ID or as per manufacturer’s instructions and the condensate discharge pipe shall be run in a standard drainpipe material, e.g. poly (vinyl chloride) (PVC), un-plasticized poly (vinyl chloride) (PVC-U), acrylonitrile butadiene-styrene (ABS), polypropylene (PP) or chlorinated poly (vinyl chloride) (PVC-C).
  • Page 55 External Connections Figure 4 – Connection of condensate discharge pipe to external soil and vent stack Boiler Visible air break 75 mm trap Visible air break and trap not required if there is a trap with a minimum condensate seal of 75mm incorporated into the boiler.
  • Page 56 External Connections Alternative Solutions Cold weather protection methods approved or endorsed by boiler manufacturers and/or service organisations may be adopted if these are considered suitable by the parties involved. It is the responsibility of the manufacturer of these products to ensure they have completed the necessary testing or calculations to ensure the product offers suitable protection to prevent the condensate pipe from freezing.
  • Page 57 External Connections Electric Trace Heating condensate pipe to raise the temperature of the condensate pipe in freezing conditions. Trace heating takes the form of an electrical heating element run in physical contact along the length of the condensate pipe. The pipe is usually covered with thermal insulation to retain heat losses from the pipe.
  • Page 58 External Connections Figure 5 – External termination to rainwater downpipe (NB only combined foul/rainwater drain) Condensate discharge pipe from boiler Pipe size transition point Water/weather proof insulation 43mm 90° male/female bend External rain water pipe into foul water External air break Air gap Minimum internal diameter 19mm Minimum internal diameter 30mm...
  • Page 59 External Connections External Termination of the Condensate Pipe Where the condensate discharge pipe is terminated over an open foul drain or gully, the pipe should terminate below the grating level, but above water level, in order to minimise “wind chill” at the open end. Pipe drainage and resistance to freezing will be improved if the termination end of the condensate pipe is cut at 45 degrees as opposed to a straight cut.
  • Page 60 External Connections Figure 6 – External drain, gully or rainwater hopper Boiler Visible air break 38mm minimum trap Visible air break and trap not required if there is a trap with a minimum condensate seal of 38 mm incorporated into the boiler – refer to manufacturers instructions External length of pipe 3 m maximum Open end of condensate discharge pipe direct into gully 25 mm min below grating but above water level;...
  • Page 61 External Connections Figure 7 – Example of a purpose made soakaway Condensate discharge pipe from boiler Ground (this section of the condensate discharge pipe may be run either above or below round level); End cut at 45° Diameter 100 mm minimum plastic tube Bottom of tube sealed Limestone chippings Two rows of three 12 mm holes at 25 mm centres, 50 mm from bottom of tube and facing...
  • Page 62 APPENDICE SCHEDA PRODOTTO Murelle HE 35 R ErP Classe efficienza energetica stagionale riscaldamento Clase de eficiencia energética estacional en calefacción Classe de eficiência energética do aquecimento ambiente sazonal C.H. energy efficiency class Potenza termica (kW) Potencia térmica (kW) Potência calorífica (kW) Heat output (kW) Consumo annuo di energia riscaldamento (GJ) Consumo anual de energía en calefacción (GJ)
  • Page 63 ALLEGATO AA.1 - MURELLE HE 35 R ErP (cod. 8113370) Informazioni da fornire per le caldaie per il riscaldamento d’ambiente e le caldaie miste Información obligatoria para calderas de calefacción de espacios y calderas mixtas Informações a fornecer para aquecedores de ambiente com caldeira e aquecedores combinados com caldeira...
