Yardistry CS002 Series Manual

Yardistry Structures- Collection Series CS002
Finished Project
Pilot holes to the right
Fig. A - Filler Strips on Bottom of
(54cm)
Screws* are 2 1/4"
included with
2x2x62" post/rail.
*Use los tornillos de
acero inoxidable
de 2 1/4" que se
incluyen en el
3' 5"
juego de
(104.1cm)
postes/travesaños
de 2x2x62".
*Les vis sons 2 1/4po
fourniers avec
poteau/Rail
2 x 2 x 62po.
(49.5cm)
Fig. D - Remove protruding
male connectors
ector
ctor
ulino
ecteur
male
ector
ctor
ulino
necteur
court
6 x One High X Topper | 2 x Two High X Panel | 6 x Arch Topper |10 x -2"x2"x62" Post/Rail
Panel!
(157.5cm)
4' 1 1/2"
(125.7cm)
(49.5cm)
2. Cut Posts and Rails to size indicated in Fig. 2. (It is recommended to use a
Mitre Box or Mitre Saw)
3. Attach Post and Rails to panels with 2 1/4" screws in locations indicated by
circles using pre-drilled holes where available. (Fig.3) When pre-drilled holes
are not available use a 1/8" Drill Bit to drill holes on an angle in the inside of
the panel as shown. (Fig. F)
4. Remove protruding male connectors to ensure flush connection with 2x2
posts in later steps. (Fig. D)
YM11522
1. Assemble panel in configuration shown. (Fig. 1) Secure panels with
2 1/4" screws provided in the direction and location of the arrows.
Use pre-drilled holes when available. *Ensure Panels are oriented
correctly! (Fig. A)
4' 8 1/2"
(143.5cm)
Fig. 2
(157.5cm)
(99.1cm)
Fig. 1
4' 1 1/2"
(125.7cm)
(49.5cm) (49.5cm)
(54cm)
3' 5"
(104.1cm)
