14' x 12' PAVILION
with ALUMINUM ROOF
Installation and Operating Instructions – YM12949
HEIGHT:
10'10" or 3.3 m
Revised 08-09-2018
[4267.2]
14'
Yardistry – North America
Toll Free Customer Support: 1.888.509.4382
[3657.8]
12'
info@yardistrystructures.com
www.yardistrystructures.com
For Spanish instructions visit our website at:
(Para obtener instrucciones españoles, visite nuestro sitio web en:)
http://yardistrystructures.com/instruction-manuals/
Height: 10' 10" (3.3 m)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YM12949 and is the answer not in the manual?

Questions and answers

Related Manuals for Yardistry YM12949

Summary of Contents for Yardistry YM12949

  • Page 1 14’ x 12’ PAVILION with ALUMINUM ROOF Installation and Operating Instructions – YM12949 HEIGHT: 10’10” or 3.3 m Revised 08-09-2018 [4267.2] 14’ Yardistry – North America Toll Free Customer Support: 1.888.509.4382 [3657.8] 12’ info@yardistrystructures.com www.yardistrystructures.com For Spanish instructions visit our website at: (Para obtener instrucciones españoles, visite nuestro sitio web en:)
  • Page 2 Wood is NOT flame retardant and will burn. Grills, fire pits and chimineas are a fire hazard if placed too close to a Yardistry structure. Consult user’s manual of the grill, fire pit or chimnea for safe distances from combustible materials.
  • Page 3 Limited Warranty Yardistry warrants that this product is free from defect in materials and workmanship for a period of one (1) year from the original date of purchase. In addition, for any product with lumber, all lumber is warranted for five (5) years against rot and decay. This warranty applies to the original owner and registrant and is non-transferable.
  • Page 4 Instructions for Proper Maintenance Your Yardistry structure is designed and constructed of quality materials. As with all outdoor products it will weather and wear. To maximize the enjoyment, safety and life of your structure it is important that you, the owner, properly maintain it.
  • Page 5 Assembly Tips Following are some helpful tips to make the assembly process smooth and efficient. PRE-ASSEMBLIES: (i.e. Post and Beam Assemblies, Roof Rafter Assembly, etc) • Work on a raised, solid and flat surface such as, a table or saw horse. •...
  • Page 6 14 x 12 - Pavilion Permanent Installation Examples 12'-0" Note: It is critically important you start with square, solid and level footings, concrete Post To Post pad or deck to attach your Pavilion. 10'-4" We supply Post Mounts with this structure which gives you the flexibility to permanently install your structure Plinth to Plinth to a pre-existing or new wood or concrete surface.
  • Page 7 Permanent Installation Examples cont. Concrete Patio (min. 12’ 7” x 13’) with 6” clearance on all sides Anchoring Hardware not included Wood Deck (min. 12’7” x 13’) with 6” clearance on all sides Anchoring Hardware not included Post Mount Anchoring Hardware (not included) Post Mounts have a 1/2”...
  • Page 8 Part Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 8pc. (460) Plinth Long FSC 8pc. (459) Plinth FSC 23.8 x 133.4 x 276.2mm (5/4 x 6 x 10-7/8") 23.8 x 133.4 x 200mm (5/4 x 6 x 7-7/8") Y50229-460 Y50229-459...
  • Page 9 Part Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 2pc. (552) Gable Upright Assemby Right FSC 76.2 x 139.7 x 717.4mm (3 x 5½ x 28¼") 2pc.
  • Page 10 Hardware Identification Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 1/4 x 2-3/4" 6pc. Hex Bolt - (Y07718-223) 1/4 x 2" 10pc. Hex Bolt - (Y07718-220) 1/4 x 4-3/4"...
  • Page 11 Hardware Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 2pc. Ridge Cap Short 27.5 (Y01030-167) 4pc. Ridge Clip Short 27.5 (Y01030-168) 2pc. Roof Edge Left (Y01030-152) 2pc.
  • Page 12 • Please retain this information for future reference. You will need this information if you contact the Consumer Relations Department. PRODUCT NUMBER: YM12949 CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 1) CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 2) CARTON I.D.
  • Page 13 Step 2: Post Assemblies A: At the bottom of one (530) 6 x 9 Post insert two 5/16” T-Nuts on the outside of each long side. (fig. 2.2) B: At the bottom of the same (530) 6 x 9 Post place two Post Mounts tight to the bottom and inside faces on the long sides as shown in fig.
  • Page 14 Step 3: Gable Beam Assembly A: Connect one (535) Gable Beam to a second (535) Gable Beam using two 5/16 x 1-1/2” Hex Bolts (with 5/16” lock washer, 1/4-5/16” large washer and 5/16” t-nut) as shown in fig. 3.1 and 3.2. B: Repeat Step A one more time to make two Gable Beam Assemblies.
  • Page 15 Step 4: Side Beam Assembly Part 1 A: Connect one (536) Side Beam Outside to a second (536) Side Beam Outside using two 5/16 x 1-1/2” Hex Bolts (with 5/16” lock washer, 1/4-5/16” large washer and 5/16” t-nut) as shown in fig. 4.1. B: Connect one (538) Side Beam End to each end of one (537) Side Beam Inside using one 5/16 x 1-1/2”...
  • Page 16 Step 4: Side Beam Assembly Part 2 D: Place one Beam Insert in between one Side Beam Outside Assembly and one Side Beam Inside Assembly then fit tight together so the beam assembly ends are flush. Match the bolt holes and wood screw pilot holes in both beam assemblies and Beam Insert.
  • Page 17 Step 5: Frame Assembly and Anchoring Part 1 A: Move your Post Assemblies to the final location. Fig. 5.1 Make sure the ground is flat and level before Side Beam Assembly continuing assembly. 14 x 12 - Pavilion Gable Beam Assembly B: With one person at each Post stand two complete Post Assemblies.
  • Page 18 Step 5: Frame Assembly and Anchoring Part 2 E: Make sure each corner is square and level then attach Side Beam Assembly to Post Assemblies with one 5/16 x 4-3/4” Lag Screw (with 1/4-5/16” large washer) per corner and Gable Beam Assembly to Post Assemblies with one 5/16 x 3”...
  • Page 19 Step 6: Attach Gussets (551) Left (577) Right Note: The bevelled ends on each Fig. 6.1 Gusset Gussett gusset should always face away from Side Beam Gable Beam Assembly the wood it is attaching to. Assembly (577) Right Gusset A: Make sure the assembly is still (551) Left square and level then facing one Side Gussett...
  • Page 20 Step 7: Gable Frame Assembly Part 1 A: Place one (549) Gable Inside against one Gable Beam Assembly, on the inside, tight to the top of (551) Left Gusset and (577) Right Gusset. The ends of (549) Gable Inside measures 17” from the Post Assemblies. Attach (549) Gable Inside to Gable Beam Assembly with eight #8 x 2-1/2”...
  • Page 21 Step 7: Gable Frame Assembly Part 2 C: Tight to each end of one (549) Gable Inside attach one (548) Gable End to Gable Beam Assembly with three #8 x 2-1/2” Wood Screws. (548) Gable End should be flush to the top of (549) Gable Inside. (fig. 7.4 and 7.5) D: Repeat Step C for the other Gable Beam Assembly.
  • Page 22 Step 7: Gable Frame Assembly Part 3 E: From the inside of the pavalion frame measure 41” from Post Assembly on the left then place one (553) Gable Upright Assembly Left tight to top of (549) Gable Inside and Gable Beam Assembly, make sure it is square then attach with two #8 x 2-1/2”...
  • Page 23 Avery Inst 6A - Frame Roof Panel Step 8: Frame Roof Panel Part 1 A: Lay out five (539) Rafter As and two (540) Rafter Bs on a hard flat surface as shown in fig. 8.1. You will need lots of room for this step. Avery Inst 6A - Frame Roof Panel B: Place 1 (543) Strap Long on the bottom of the one (540) Rafter B, flush to the outside edge and four (539) Rafter As, centred on the last.
  • Page 24 Step 8: Frame Roof Panel Part 2 D: Tight to each (543) Strap Long place one (544) Strap Short and tight to the first two (544) Strap Shorts place one (543) Strap Long. Make sure the wider gap on each strap is on the outside. Make sure the assembly is square, pre-drill the first (544) Strap Short with a 1/8”...
  • Page 25 Step 8: Frame Roof Panel Part 3 F: Make sure frame is square. Measurements to be as shown in fig. 8.6. G: In the two middle gaps between (539) Rafter As place one (545) Rafter Brace flush to the top of (542) Ridge Short and (541) Ridge Long.
  • Page 26 STOP STOP STOP STOP INSTALLING ROOFING MATERIAL CAUTION! Roofing material may have sharp edges! Wear gloves! HANDLE WITH CARE! Place roofing material on a non-abrasive surface before assembly as it can bend, dent and scratch easily. WARNING – DO NOT OVER TIGHTEN ROOFING SCREWS! Over tightening screws will cause roofing material to crush.
  • Page 27 STOP STOP STOP STOP INSTALLING ROOFING MATERIAL CAUTION! Roofing material may have sharp edges! Wear gloves! BE SURE TO REMOVE ALL PLASTIC COVERING, ON BOTH SIDES OF THE ALUMINUM PANELS AND TRIM, DIRECTLY BEFORE INSTALLING EACH PIECE. (One side is clear and the other is blue, both must be removed.) Example #1 Example #2 Overtightened and Crushed...
  • Page 28 Step 9: Attach Roof Panels Part 1 Note: Be sure to remove all plastic covering on both sides of the metal panels directly before installing each piece. A: Make sure panel is still square then on one Roof Panel Frame place one Main Panel flush to the top and sides of the outside (540) Rafter B.
  • Page 29 Step 9: Attach Roof Panels Part 2 E: Place one Roof Edge Left and one Roof Edge Right on the bottom of each Roof Panel Frame so they meet tight and the ends are flush with the outside ends of (544) Short Strap and (543) Long Strap. Predrill the two end holes with a 1/8”...
  • Page 30 Step 9: Attach Roof Panels Part 3 F: Attach the three Main Panels and one Right Side Panel to one Roof Panel Frame using 63 #8 x 1” Hex Roofing Screws as shown in fig. 9.8. On the outside (540) Rafter Bs, in between the screw holes, four additonal screws are to be inserted through the panels in the spaces indicated below (see A and B).
  • Page 31 Step 9: Attach Roof Panels Part 4 G: Place Weather Seal on the inside of two Ridge Clip Short then place one Ridge Clip Short flush to each side of Roof Panel Frame and 3-1/4” up from the bottom of (541) Ridge Long and (542) Ridge Short, make sure not to compress Weather Seal.
  • Page 32 Step 10: Attach Roof Panels to Frame Part 1 A: With four assemblers lift one Roof Panel Frame up and over the pavilion frame so it rests on (552) Gable Upright Assembly Right and (553) Gable Upright Assembly Left. The notches in the rafters sit tight on the Side Beam Assemblies.
  • Page 33 Step 10: Attach Roof Panels to Frame Part 2 B: From inside the assembly attach the two Roof Panel Frames together through each (545) Rafter Brace with four 1/4 x 4-3/4” Hex Bolts (with two 1/4-5/16” large washer and one 1/4” lock nut) and through (541) Ridge Longs and (542) Ridge Shorts with six 1/4 x 2-3/4”...
  • Page 34 Step 10: Attach Roof Panels to Frame Part 3 C: Loosely attach each of the (539) Rafter As to the inside of each Side Beam Assembly with one Rafter to Beam Bracket per rafter using one 1/4 x 2” Hex Bolt (with two 1/4-5/16” large washer and one 1/4” lock nut) per bracket. Push up on the centre of the Roof Panels so the notches in the rafters are tight to the Side Beam Assembly then attach five #10 x 1-1/4”...
  • Page 35 Step 11: Attach Ridge Caps Part 1 A: Slide Ridge Cap over the Ridge Clips towards the centre of the roof. (fig. 11.1 and 11.2) B: With the swaged end facing in slide one Ridge Cap Short at each end of the roof over the Ridge Clips. Use the swaged end to help push the Ridge Cap to the centre of the roof.
  • Page 36 Step 11: Attach Ridge Caps Part 2 C: Make sure the Ridge Cap Shorts are flush to the outside edge of the roof then attach each end of the Ridge Cap to each Ridge Cap Short with two #8 x 3/4” Metal Screws per side. (fig. 11.5, 11.6 and 11.7) Fig.
  • Page 37 Step 12: Attach Fascia A: On one side of the assembly place two (550) Fascia against the outside rafters so the peaks meet in the centre and they are tight together. Bottom of (550) Fascia to bottom of rafter should measure 1” all along each (550) Fascia.
  • Page 38 Step 13: Truss Assemblies Part 1 A: Place one (547) Tie Brace centred, tight and square to the top of (546) Tie. Attach (546) Tie to (547) Tie Brace using two Jamb Mounts (one per side) with four #8 x 1” Pan Screws per mount. Repeat to complete five Tie Brace Assemblies.
  • Page 39 Step 13: Truss Assemblies Part 2 C: Attach one Tie Centre Bracket to the peak of five rafters, (541) Ridge Long, (542) Ridge Short with four #8 x 1” Pan Screws per bracket. Notice that three Tie Centre Brackets face one way and one faces the opposite direction.
  • Page 40 Step 13: Truss Assemblies Part 3 D: With a helper place five (546) Tie with brackets tight against the rafters so (547) Tie Braces fit into Tie Centre Brackets. Make sure (546) Ties are level then attach Tie Wrap Brackets to the rafters with two #10 x 1-1/4” Pan Screws on both sides of each bracket and one #12 x 1-1/4”...
  • Page 41 Step 13: Truss Assemblies Part 4 F: Secure four (547) Tie Braces to each Tie Centre Bracket with two #8 x 1” Pan Screws per bracket. (fig. 13.9 and 13.10) G: Secure remaining (547) Tie Brace to (541) Ridge Long and (542) Ridge Short with one Corner Bracket using four #8 x 1”...
  • Page 42 Step 14: Attach Plaque A: Attach Gazebo ID Plaque to a prominent location on your Pavilion with two #8 x 1” Pan Screws. This provides warnings concerning safety and important contact information. A tracking number is provided to allow you to get critical information or order replacement parts for this specific model.
  • Page 43 NOTES support@yardistrystructures.com...
  • Page 44 Would you recommend the purchase of our products to friends and family? Comments: MAIL TO: Yardistry 375 Sligo Road W., PO Box 10 Mount Forest, Ontario, Canada Yardistry would like to say Thank You for your time and feedback. N0G 2L0 Attention: Customer Service REVISION: 09/06/2017 support@yardistrystructures.com...
