3.7m x 4.3m (12.1' x 14.1') GRAND GAZEBO
Installation and Operating Instructions – YM12978
Yardistry – North America
Toll Free Customer Support:
1.888.509.4382
info@yardistrystructures.com
www.yardistrystructures.com
Regular Hours: Mon - Fri, 8:30 am - 5:00
pm EST (excl. holidays)
(For extended hours see our website)
English and French Spoken
Patents Pending
Y40000-978
with ALUMINUM ROOF
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
02-22-2021
4.293 m
14' 1"
HEIGHT:
3.175m / 10'5"
3.683 m
12' 1"
Advertisement
Table of Contents
Related Manuals for Yardistry YM12978
Summary of Contents for Yardistry YM12978
- Page 1 3.7m x 4.3m (12.1’ x 14.1’) GRAND GAZEBO with ALUMINUM ROOF Installation and Operating Instructions – YM12978 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY 02-22-2021 4.293 m 14’ 1” Yardistry – North America Toll Free Customer Support: 1.888.509.4382 3.683 m info@yardistrystructures.com...
- Page 2 Wood is NOT flame retardant and will burn. Grills, fire pits and chimineas are a fire hazard if placed too close to a Yardistry structure. Consult user’s manual of the grill, fire pit or chiminea for safe distances from combustible materials.
- Page 3 Limited Warranty Yardistry warrants that this product is free from defect in materials and workmanship for a period of one (1) year from the original date of purchase. In addition, for any product with lumber, all lumber is warranted for five (5) years against rot and decay. This warranty applies to the original owner and registrant and is non-transferable.
- Page 4 Instructions for Proper Maintenance Your Yardistry structure is designed and constructed of quality materials. As with all outdoor products it will weather and wear. To maximize the enjoyment, safety and life of your structure it is important that you, the owner, properly maintain it.
- Page 5 Assembly Tips Following are some helpful tips to make the assembly process smooth and efficient. PRE-ASSEMBLIES: (i.e. Post and Beam Assemblies, Roof Rafter Assembly, etc) • Work on a raised, solid and flat surface such as, a table or saw horse. •...
- Page 6 Concrete Footer Anchoring Hardware not included Post Mount Required Depth YM12978 - 12 x 14 Grand 13'-1" 3.921 m Post to Post 12’ 10-3/8” Post to Post 3.007 m 4.626 m...
- Page 7 Permanent Installation Examples cont. Concrete Patio [min. 3.616 m x 4.226 m (11’10-3/8” x 13’10-3/8”)] with 15.24 cm (6”) clearance on all sides Anchoring Hardware not included Wood Deck [min. 3.616 m x 4.226 m (11’10-3/8” x 13’10-3/8”)] with 15.24 cm (6”)clearance on all sides Anchoring Hardware not included Post Mount...
- Page 8 Part Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 2pc. (1036) - 6 x 8 Post Right Side 2387.6mm (94") Y70229-1036 2pc. (1035) - 6 x 8 Post Left Side 2387.6mm (94") Y70229-1035 4pc.
- Page 9 Part Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 2pc. (337) - Strap Short 1561.3mm 2pc. (433) - Strap Brace 574.7mm (61 1/2") Y50229-337 (22 5/8") Y50229-433 2pc.
- Page 10 Hardware Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 5/16 x 1-1/2" 24pc. Hex Bolt - (Y07718-312) 12pc. 1/4 x 2-3/4 Hex Bolt - (Y07718-223) 5/16 x 3"...
- Page 11 Hardware Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 4pc. 4pc. - Long Panel Right 4pc. - Short Panel Left Ridge Cap Short 25.2 (Y01037-129) (Y01037-126) (Y01030-132)
- Page 12 • Please retain this information for future reference. You will need this information if you contact the Consumer Relations Department. PRODUCT NUMBER: YM12978 CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 1) CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 2) CARTON I.D.
- Page 13 Step 2: Post Assemblies Part 1 A: At the bottom of one (1035) 6 x 8 Post Left Side insert one 5/16” T-Nut on the outside of each short side. (F2.1 and F2.2) B: At the bottom of the same post place two Post Mounts tight to the bottom and inside faces on the short sides as shown in F2.1 and F2.2.
- Page 14 Step 2: Post Assemblies Part 2 C: Flush to the bottom of (1035) 6 x 8 Post Left Side place one (1048) Plinth Long on each long side and one (459) Plinth on each short side then attach with four #8 x 1-1/2” Wood Screws per plinth. Rounded edges on top. (F2.3 and F2.4) D: Repeat Steps A - C one more time to make two Post Left Assemblies.
- Page 15 Step 3: Short Beam Assembly Part 1 A: Connect two (1044) Beam Shorts using two 5/16 x 1-1/2” Hex Bolts (with 5/16” lock washer, 1/4-5/16” large washer and 5/16” t-nut) as shown in F3.1 and F3.2. B: Connect one (1043) Beam Short End to each end of one (1042) Short Beam Centre using two 5/16 x 1-1/2” Hex Bolts (with 5/16”...
- Page 16 Step 3: Short Beam Assembly Part 2 D: Place one Beam Short Assembly tight to one Short Beam End Assembly. Match the bolt holes in each (1043) Beam Short End with the bolt holes in each (1044) Beam Short. Attach with 18 #8 x 2-1/2” Wood Screws. (F3.3 and F3.4) E: Repeat Step D one more time to make two Short Beam Assemblies.
- Page 17 Step 4: Long Beam Assembly Part 1 A: Connect two (1045) Beam Longs using two 5/16 x 1-1/2” Hex Bolts (with 5/16” lock washer, 1/4-5/16” large washer and 5/16” t-nut) as shown in F4.1 and F4.2. B: Connect one (1047) Beam Long End to each end of one (1046) Long Beam Centre using one 5/16 x 1-1/2” Hex Bolts (with 5/16”...
- Page 18 Step 4: Long Beam Assembly Part 2 D: Place one Long Beam Insert in between one Beam Long Assembly and one Long Beam End Assembly then fit tight together. Beam Long Assembly overhangs Long Beam End Assembly by 1-3/8” on each end. Match the bolt holes and wood screw pilot holes in both beam assemblies and Long Beam Insert.
- Page 19 Step 5: Frame Assembly Part 1 - Short Side F5.1 A: Against the short sides of one Post Right Assembly and one Post Left Assembly place one Short Beam Assembly and Short Beam Assembly loosely attach with one 3/8 x 10” Hex Bolt (with two 3/8” large washers and one 3/8”...
- Page 20 Step 5: Frame Assembly Part 2 - Short Side C: Make sure Short Beam Assembly is square to Posts then F5.4 pre-drill with a 1/8” drill bit in the top holes of each Short Beam Short Beam Assembly and bottom hole of (1053) Arched Gusset Short, Assembly then attach with two 5/16 x 4”...
- Page 21 Hex Bolt Assembly Gusset these holes (1049) Arched Gusset Post YM12978 - 12 x 14 Grand Long Side 4- Arched Gusset -(Y70000-1049) 2- Long Beam Assemblies 13'-1" 3.921 m Post to Post 12’ 10-3/8” 8- 3/8 x 8" Hex Bolts...
- Page 22 Step 5: Frame Assembly Part 4 - Long Side I: Make sure Long Beam Assembly is square to Posts then pre-drill with a 1/8” drill bit in the bottom holes of each Long Beam Assembly and (1049) Arched Gusset then attach with two 5/16 x 4” Lag Screws (with 1/4- 5/16”...
- Page 23 Step 6: Attach Roof Brackets A: At each corner, tight to the outside edges of the joining Beam Assemblies attach one Rafter to Post Bracket with two #8 x 1” Pan Screws. (F6.1 and F6.2) Long Beam Short Beam Assembly Assembly F6.1 Short Beam...
- Page 24 Step 7: Fascia Beam Assemblies A: Tightly connect one (443) Fascia Left and one (444) Fascia Right using one 5/16 x 1-1/2” Hex Bolt (with 5/16” lock washer, 1/4-5/16” large washer and 5/16” t-nut) as shown in F7.1 and F7.2. Repeat to make a second Fascia Beam Assembly.
- Page 25 Step 8: Small Roof Rafter Assembly Part 1 A: On each side of one (440) Rafter place one (438) Rafter Corner Left and one (439) Rafter Corner Right so the tops and edges are flush then attach with two #8 x 2-1/4” Wood Screws per side. (F8.1 and F8.2) B: Place Fascia Beam Assembly from Step 7A on the bottom of (438) Rafter Corner Left, (439) Rafter Corner Right and (440) Rafter so the sides are flush then attach with two #8 x 2-1/4”...
- Page 26 Step 8: Small Roof Rafter Assembly Part 2 D: Place one (337) Strap Short in the notches of (438) Rafter Corner Left, (439) Rafter Corner Right and (440) Rafter so the ends do not overhang the outside edges of the outside boards then attach with six #8 x 1-1/2” Wood Screws.
- Page 27 Step 9: Attach Roof to Beam Brackets - Small Roof Rafter Assembly A: On the Back of one Small Roof Rafter Assembly, centred and 1-1/2” (3.81 cm) from the bottom of (442) Rafter Short Right, (441) Rafter Short Left and (440) Rafter attach one Roof to Beam Bracket per board with one #8 x 1”...
- Page 28 Step 10: Large Roof Rafter Assembly Part 1 A: On each side of one (434) Top place one (440) Rafter so the tops and edges are flush then attach with two #8 x 2-1/2” Wood Screws per side. (F10.1 and F10.2) B: Place Large Fascia Beam Assembly from Step 7B on the bottom of (440) Rafters so the sides are flush and holes are centred on the (440) Rafters then attach with two #8 x 2-1/4”...
- Page 29 Step 10: Large Roof Rafter Assembly Part 2 D: Beside each (440) Rafter place one (438) Rafter Corner Left and one (439) Rafter Corner Right so the tops and edges are flush and the bottom edges are flush to Large Fascia Beam Assembly then attach with two #8 x 2-1/4”...
- Page 30 Step 10: Large Roof Rafter Assembly Part 3 F: Place one (430) Strap Short - Large Roof in the notches of (438) Rafter Corner Left, (439) Rafter Corner Right and both (440) Rafters so the ends do not overhang the outside edges of the outside boards then attach with eight #8 x 1-1/2”...
- Page 31 Step 10: Large Roof Rafter Assembly Part 4 J: Turn Large Roof Rafter Assembly over then attach one (433) Strap Brace to (431) Strap Left - Large Roof and (432) Strap Right - Large Roof with eight #8 x 2-1/4” Wood Screws. Edges are flush. (F10.8 and F10.9) K: Complete Steps F - J for both Large Roof Rafter Assemblies.
- Page 32 Step 11: Attach Roof to Beam Brackets - Large Roof Rafter Assemblies A: On the Back of both Large Roof Rafter Assemblies, centred and 1-1/2” (3.81 cm) from the bottom of (442) Rafter Short Right, (441) Rafter Short Left and both (440) Rafter attach one Roof to Beam Bracket per board with one #8 x 1”...
- Page 33 STOP STOP STOP STOP INSTALLING ROOFING MATERIAL CAUTION! Roofing material may have sharp edges! Wear gloves! HANDLE WITH CARE! Place roofing material on a non-abrasive surface before assembly as it can bend, dent and scratch easily. WARNING – DO NOT OVER TIGHTEN ROOFING SCREWS! Over tightening screws will cause roofing material to crush.
- Page 34 STOP STOP STOP STOP INSTALLING ROOFING MATERIAL CAUTION! Roofing material may have sharp edges! Wear gloves! BE SURE TO REMOVE ALL PLASTIC COVERING, ON BOTH SIDES OF THE ALUMINUM PANELS AND TRIM, DIRECTLY BEFORE INSTALLING EACH PIECE. (One side is clear and the other is blue, both must be removed.) Example #1 Example #2 Overtightened and Crushed...
- Page 35 Step 12: Attach Roof Panels - Small Roof Part 1 A: Place one Long Panel Left on the front of one Small Roof Rafter Assembly so it is flush to the side of (438) Rafter Corner Left and a slight overhang at the bottom of the Fascia Beam Assembly. Holes should line up with (440) Rafter.
- Page 36 Step 12: Attach Roof Panels - Small Roof Part 2 E: Place one Short Panel Left on Small Roof Rafter Assembly so it overlaps the Long Panel Left and it is flush to the sides of (438) Rafter Corner Left and a slight overhang at the bottom of the Fascia Beam Assembly. There should be no overhanging at the corners.
- Page 37 Step 13: Attach Ridge Clips and Roof Edges - Small Roof A: Place one Roof Edge Left 72.2 and one Roof Edge Right 72.2 on the bottom of each Small Roof Rafter Assembly so the ends are flush with the outside ends of the Fascia Beam Assembly and meet tight in the centre. Attach both Roof Edges with 17 #8 x 1”...
- Page 38 Step 14: Attach Roof Panels - Large Roof Part 1 A: Place one Middle Panel on the front of one Large Roof Rafter Assembly so it slightly overhangs the top of (434) Top and an overhang at the bottom of the Large Fascia Beam Assembly. Holes should line up with (440) Rafter and (430), (431) and (432) Straps (F14.1) B: Place one Long Panel Left and one Long Panel Right on each side of Middle Panel so they overlap the Middle Panel and are flush to the sides of (438) Rafter Corner Left and (439) Rafter Corner Right and an...
- Page 39 Step 14: Attach Roof Panels - Large Roof Part 2 C: Place one Short Panel Left so it overlaps the Long Panel Left and it is flush to the sides of (438) Rafter Corner Left and one Short Panel Right so it overlaps the Long Panel Right and it is flush to the side of (439) Rafter Corner Right.
- Page 40 Step 14: Attach Roof Panels - Large Roof Part 3 F: On one Large Roof Rafter Assembly place one (463) Spacer Top flush to the outside edges and centred on (434) Top then attach with three #8 x 2-1/4” Wood Screws. (F14.5 and F14.6) (463) F14.6 Spacer Top...
- Page 41 Step 15: Attach Ridge Clips and Roof Edges - Large Roof A: Place one Roof Edge Left 72.2 and one Roof Edge Right 96.2 on the bottom of each Large Roof Rafter Assembly so the ends are flush with the outside ends of the Large Fascia Beam Assembly and meet tight in the centre.
- Page 42 Step 16: Attach Roof Panels to Frame Part 1 A: From inside the Post Assemblies measure 4’ 11-3/16” (1.503m) to mark the centre of each Short Beam Assembly. (F16.1) B: With all four assemblers place Small Roof Panel Assembly with Roof to Beam Brackets just in front of the Posts then raise it up so it is over Short Beam Assembly, taking care not to drag the panel on the beams.
- Page 43 Step 16: Attach Roof Panels to Frame Part 2 C: Lift a Large Roof Panel Assembly with Roof to Beam Brackets over Long Beam Assembly taking care not to drag the panel on the beams. Make sure the Rafter Corners are flush with each other. One person must remain on the centre ladder to hold both panels in place until three panels are up and secure.
- Page 44 Step 16: Attach Roof Panels to Frame Part 3 E: Lift second Large Roof Panel Assembly with Roof to Beam Brackets over Large Beam Assembly taking care not to drag the panel on the beams then set in place beside the Small Roof Panel Assembly. (F16.6) F: Starting at the bottom and working up connect Large Roof Panel Assembly to Small Roof Panel Assembly through the Rafter Corners with three 1/4 x 2-3/4”...
- Page 45 Step 17: Roof Peak Assembly A: Insert two Carriage Bolts with Contoured Washers through the top of Peak Cap Long, into Peak Post then Spring Clip. The Spring Clip holds the assembly together. (F17.1) B: Insert one 1/4” Nut into each Peak Loop. Be careful nut is loose and will fall out until attached to Peak Cap Assembly.
- Page 46 Step 18: Attach Roof Peak to Roof Panels A: Insert Roof Peak Assembly in gap between Large and Small Roof Panels. Peak Cap Long to be lined up with Rafter Corners. (F18.1 and F18.2) B: Insert two Roof Peak Brackets through each Carriage Bolt and attach Peak Loop to Carriage Bolts then twist to tighten loosely.
- Page 47 Step 19: Attach Final Roof Panel Part 1 A: Lift last Small Roof Panel Assembly (without Roof to Beam Brackets) over Short Beam Assembly taking care not to drag the panel on the beams. Panel fits under the Peak Cap Long, push up on Peak Loop to lift Peak Cap Long.
- Page 48 Step 19: Attach Final Roof Panel Part 2 Remember to push up centre to assist with alignment. B: Starting at the bottom and working up loosely connect Roof Panel Assemblies through the Rafter Corners with three 1/4 x 2-3/4” Hex Bolts (with two 1/4-5/16” large washers and one 1/4” lock nut) per side. To align bolt holes helper on the centre ladder may have to push up in the centre of the panels and others make sure corners are aligned.
- Page 49 Step 19: Attach Final Roof Panel Part 3 C: On the Small Roof Rafter Assembly just installed, centred on the bottom of (442) Rafter Short Right, (441) Rafter Short Left and (440) Rafter attach one Roof to Beam Bracket per board with one #8 x 1” Pan Screw in the bottom hole and one #12 x 1-1/2”...
- Page 50 Step 20: Secure Roof Corners A: Make sure middle Roof to Beam Brackets are flush and tight to the Beam Assemblies. Lift in centre if needed. B: From outside the assembly attach Roof Panel Assemblies together at the Fascia Beam Assembly Ends with two #8 x 2-1/2”...
- Page 51 Step 21: Attach Corner and Beam Caps A: At each corner place one Corner Cap tight to Fascia Assemblies, push up so the bottom is tight to the bottom of the assemblies then attach with four #8 x 3/4” Sheet Metal Screws per Corner Cap. (F21.1 and F21.2) F21.1 F21.2 #8 x 3/4”...
- Page 52 Step 22: Secure Roof to Beam Brackets A: From inside the assembly attach Roof to Beam Brackets to Beam Assemblies with two #12 x 1-1/2” Pan Screw per bracket. (F22.1 and F22.2) F22.1 Inside View Beam Assembly F22.2 Roof to Beam Bracket Beam...
- Page 53 Step 23: Secure Roof Peak Brackets A: Tighten the six screws in Roof Peak Brackets then attach to Corner Rafters in the remaining holes with ten #10 x 1-1/4” Pan Screws. (F23.1) F23.1 Roof Peak Bracket Rafter Rafter Corner Corner Rafter Corner Rafter...
- Page 54 Step 24: Attach Ridge Caps to Roof Panels A: Slide one Ridge Cap Long 81.5 over the Ridge Clips, with cut end leading, on each corner of the assembly from the bottom up. Slide Ridge Cap Short 25.2 over the Ridge Clips leading with the insert end to push the Ridge Cap Long 81.5 to the top, lifting Peak Cap Long by pushing up the Peak Loop so Ridge Cap Long 81.5s fit under Peak Cap Long.
- Page 55 Step 25: Attach Tie Wrap Brackets and Ties F25.1 A: Attach one Tie Wrap Bracket to each end of one (461) Tie with one #10 x 1-1/4” Pan Screw per bracket using the inside holes. (461) Tie is tight to end of bracket. (F25.1, F25.2 and F25.3) B: With a helper place (461) Tie with brackets against a (440) Rafter on each...
- Page 56 Step 26: Attach Twist Brackets A: Measure 3-3/4” (9.53 cm) down from the inside of each post, place bottom of either 45° Twist Bracket LT or 45° Twist Bracket RT at measured location then attach to post and Corner Rafter (Left or Right) with four #12 x 1-1/2” Pan Screws per bracket.
- Page 57 Step 27: Metal Hooks and Plaque Part 1 A: Two 50 mm Hooks are included with this unit for attaching wiring. They can be placed anywhere along the Rafter Corners as needed. Pre-drill with a 1/8” drill bit before installing. (F27.1 and F27.2) B: One Eye Lag is included with this unit for hanging items with a maximum weight of 22 lbs (10 kg).
- Page 58 Step 27: Metal Hooks and Plaque Part 2 C: Attach Gazebo ID Plaque to a prominent location on your gazebo with two #8 x 1” Pan Screws. This provides warnings concerning safety and important contact information. A tracking number is provided to allow you to get critical information or order replacement parts for this specific model.
- Page 59 Yardistry 375 Sligo Road West, P.O. Box 10, Mount Forest, ON Canada N0G 2L1 ® Distributed by: Costco Wholesale Canada Ltd.* Importado por: Costco Wholesale Australia Pty Ltd Costco Wholesale Corporation 415 W. Hunt Club Road Importadora Primex S.A. de C.V.
- Page 60 NOTES support@yardistrystructures.com...
- Page 61 NOTES support@yardistrystructures.com...
- Page 62 À l’attention de: Service à la clientèle Anglais et français parlés / Inglés y francés hablado Yardistry would like to say “Thank you” for your time and feedback. Yardistry quiere “Agradecerle” por su tiempo y su opinión. Yardistry aimerait vous remercier d’avoir pris le temps de répondre au sondage.
