Yardistry CS005 Assembly

Yardistry Structures- Collection Series CS005
Finished Project
Pilot holes to the left
Fig. B - Filler Strips on Bottom of
Panel!
8 11/16"
(22.1cm)
Fig. 2
2' 7 1/2"
(80cm)
(49.5cm)
2. Cut Posts and Rails to size indicated. (Fig. 2) Circles and
Triangles indicate a 45° cut.
3. Where indicated by a triangle, use a 1/8" drill bit to pre-drill a
hole into the 2x2 Rail. (Fig.E)
3 x One High X Topper | 5 x One High Lattice Topper | 2 x Arch Topper
1. Assemble panels in configuration shown. (Fig. 1) Secure with 2 1/4"
screws provided in the direction and location of the arrows. Use pre-
drilled holes when available.
*Ensure Panels are oriented correctly! (Fig. B)
(111.8cm)
(Use a Mitre Box or Mitre Saw)
6 x -2"x2"x62" Post/Rail
YM11525
Fig. 1
Top View
(157.5cm)
(148.6cm)
8 11/16"
(22.1cm)
(111.8cm)
(49.5cm)
(2.54cm)
1/8" Drill
Hole
Cut Rail
Fig. E- Pre-Drill Hole with 1/8"
Drill Bit.
2' 7 1/2"
(80cm)
