- Page 1 Instruction Manual ® MEGA STAR 3.0 / 3.0R 50142582 EU Catalogue Numbers: VWR MEGA STAR 3.0: 521-1751 VWR MEGA STAR 3.0R: 521-1752 Version: Issued: 25.06.2020...
-
Page 2: Legal Address Of Manufacturer
Legal Address of Manufacturer Europe VWR International bv Researchpark Haasrode 2020 Geldenaaksebaan 464 B-3001 Leuven + 32 16 385011 www.vwr.com Country of origin VWR Mega Star 3.0 / 3.0R: Germany VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 5: Table Of Contents
Storage ..............................11 Intended Use ........................ 11 Symbols and Conventions ..................11 Product Specifications ....................12 Characteristics of the VWR MEGA STAR 3.0 / 3.0R ................12 Refrigerant ............................... 12 Mains supply ............................12 Technical data ............................13 Functions and features ..........................14 Description of Buttons and Switches ................ - Page 6 Technical service ......................35 Warranty .......................... 35 Compliance with local Laws and Regulations ............. 35 WEEE Conformity ......................36 APPENDIX ........................37 Chemical Compatibility chart ........................37 Autoclaving Protocol ..........................42 VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
-
Page 7: Warning
Before starting to use the centrifuge, read through this instruction manual carefully and follow the instructions. The information contained in this instruction manual is the property of VWR; it is forbidden to copy or pass on this information without explicit approval. - Page 8 • Highly corrosive substances which can cause material damage and impair the mechanical stability of the rotor, should only be centrifuged in corresponding protective tubes. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
-
Page 9: Package Contents
Anti-corrosion oil If any parts are missing, please contact your nearest VWR representative. Delivery Content The VWR Mega Star 3.0 / 3.0R centrifuge is supplied with 1 TX-750 rotor. Unpacking and Installation Before setting up 1. Check the centrifuge and the packaging for any shipping damage. -
Page 10: Location
CAUTION If the centrifuge isn’t level, imbalances can occur and the centrifuge can be damaged. Do not place anything under the centrifuge to level. Mains Connection Figure 2. Mains connection VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 11: Storage
WARNING means that injuries or material damage or contamination could occur. This symbol refers to biological hazards. Observe the information contained in the instruction manual to keep yourself and your environment safe. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 12: Product Specifications
Contains fluorinated greenhouse gases in a hermetically sealed system. Mains supply The following table contains an overview of the electrical connection data for the VWR MEGA STAR 3.0 / 3.0R. This data is to be taken into consideration when selecting the mains connection socket. -
Page 13: Technical Data
Technical data The technical data of the VWR MEGA STAR 3.0 / 3.0R is listed in the following table. Feature MEGA STAR 3.0 MEGA STAR 3.0R Environmental conditions - Use in interior spaces. - Altitudes of up to 2,000 m above sea level. -
Page 14: Functions And Features
9 acceleration and 10 braking curves Rotor recognition Automatic Imbalance recognition Electronic, contingent on rotor and speed Lid lock Automatic lid closing and locking starting from an initial hold position VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 15: Description Of Buttons And Switches
In the control panel you find the keys and displays of the centrifuge. All parameters can be selected and changed during operation. Figure 3. Control Panel of VWR MEGA STAR 3.0 / 3.0R Operational keys The keys allow user intervention for controlling the operating mode as follows:... -
Page 16: Getting Started And Operation
The centrifuge is equipped with an Auto-Lock™ locking system. This system is used to automatically lock the rotor to the centrifuge spindle. The rotor does not have to be bolted on to the centrifuge spindle. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 17: Entering Parameters
Close the centrifuge lid. Entering parameters The VWR Mega Star 3.0 / 3.0R centrifuge offers you a total of 9 acceleration and 10 braking curves with which samples and gradients can be centrifuged. After the centrifuge is turned on, the last running profile selected is shown. - Page 18 The maximum RCF value is related to the maximum radius of the tube opening. Remember that this value is reduced depending on the tubes and adapters used. This can be accounted for in the calculation above if required. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
- Page 19 2. Enter the desired value by pressing the key repeatedly, until the desired value shows. 3. The display shows: The display shows the current temperature inside the rotor chamber. 4. Press the START key VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
-
Page 20: Centrifugation
"Imbalanced load". The run will terminate. Check the loading and start the centrifuge once again. See the information on proper loading in the rotor instruction manual. For information on troubleshooting. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 21: Temperature Adaption During Standstill
Short-term Centrifugation For short-term centrifuging, the VWR MEGA STAR 3.0 / 3.0R has a PULSE- function. By holding down the key, spinning will start and continue until the key is let go. -
Page 22: Aerosol-Tight Rotors
Figure 6. Auto-Lock- for aerosol-tight rotors WARNING Mind the Auto-Lock-mandrel inside the lid. Do not touch the mandrel. Aligning the Centrifuge • To turn off the centrifuge put the mains switch to "0". VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 23: System Menu
System Menu • Use the keys below the bucket selection in order to navigate within the system menu points. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 24: Description
NO. Use the keys below the speed display in order to navigate through the system menu. Press the STOP key to quit the system menu. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... - Page 25 Here you fine the current numbers of cycles. Use the keys below the speed display in order to navigate through the system menu. Press the STOP key to quit the system menu. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
-
Page 26: Troubleshooting
4. Push the cord back into the centrifuge and mount the plug. Reconnect the centrifuge once the power has been restored. Switch on the centrifuge. Press the OPEN key to have the door locks operative again. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 27: Troubleshooting By User
The centrifuge cannot be operated. Restart the centrifuge. The run does not start or the If an error message appears again, inform centrifuge runs down without being Customer Service. braked. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... - Page 28 If an error message appears again, inform Customer Service. E-15 - E-16 Temperature sensor broken / Malfunction in the temperature detection. controller defective Restart the centrifuge. If an error message appears again, inform Customer Service. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
- Page 29 The run does not start or the Clean the air inlet for the condenser. centrifuge runs down without being Restart the centrifuge. braked. If an error message appears again, inform Customer Service. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
- Page 30 Hold down any of the keys and then switch on the centrifuge. You enter the system menu. Press the START key Press the key, until the following message is displayed: Software ID: XXXXXXXX Communicate the software version to the service technician. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
-
Page 31: Repair And Maintenance
After cleaning, treat the entire surface of aluminium parts with corrosion protection oil (521-1769). Also treat the cavities with oil. • Store the aluminium parts at room temperature or in a cold-storage room with the cavities pointing down. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... - Page 32 Observe the safety precautions and handling instructions for the cleaning agents used. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
- Page 33 Contact the Service Department of VWR for questions regarding the use of other disinfectants. Disinfect the rotor and accessories as follows: 1. Open the centrifuge. 2. Turn off the centrifuge. 3. Pull out the power supply plug. 4. Grasp the rotor with both hands and lift it vertically off the centrifuge spindle.
- Page 34 • the fixation of the rotor and the drive shaft. VWR offers inspection and service contracts for this work. Any necessary repairs are performed for free during the warranty period and afterwards for a charge. This is only valid if the centrifuge has only been maintained by a VWR service technician.
-
Page 35: Technical Service
(2) years from date of delivery. If a defect is present, VWR will, at its option and cost, repair, replace, or refund the purchase price of this product to the customer, provided it is returned during the warranty period. -
Page 36: Weee Conformity
By doing so, you will help to conserve natural and environmental resources and you will ensure that your equipment is recycled in a manner that protects human health. Thank you VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... -
Page 37: Appendix
Barium Salts Benzene Benzyl Alcohol Boric Acid Cesium Acetate Cesium Bromide Cesium Chloride Cesium Formate Cesium Iodide Cesium Sulfate Chloroform Chromic Acid (10%) Chromic Acid (50%) Cresol Mixture Cyclohexane Deoxycholate VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... - Page 38 Hydrochloric Acid (conc.) Formaldehyde (40%) Glutaraldehyde Glycerol Guanidine Hydrochloride Haemo-Sol™ Hexane Isobutyl Alcohol Isopropyl Alcohol Iodoacetic Acid Potassium Bromide Potassium Carbonate Potassium Chloride Potassium Hydroxide (5%) Potassium Hydroxide (conc.) Potassium Permanganate VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
- Page 39 Sodium Hypochlorite (5%) Sodium Iodide Sodium Nitrate Sodium Sulfate Sodium Sulfide Sodium Sulfite Nickel Salts Oils (Petroleum) Oils (Other) Oleic Acid Oxalic Acid Perchloric Acid (10%) Perchloric Acid (70%) Phenol (5%) VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
- Page 40 Tetrahydrofuran Toluene Trichloroacetic Acid Trichloroethane Trichloroethylene Trisodium Phosphate Tris Buffer (neutral Triton X/100™ Urea Hydrogen Peroxide (10%) Hydrogen Peroxide (3%) Xylene Zinc Chloride Zinc Sulfate Citric Acid (10%) ¹ Polyethlyeneterephtalate VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
- Page 41 Chemical resistance data is included only as a guide to product use. Because no organized chemical compatibility data exists for materials under the stress of centrifugation, when in doubt we recommend pretesting sample lots. VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020...
-
Page 42: Autoclaving Protocol
Autoclaving Protocol Date Comment Operator Signature VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020... - Page 43 D - 64295 Darmstadt VWR International AS Freecall: 0800 702 00 07 Brynsalleen 4 Tel.: +49 (0) 6151 3972 0 0667 Oslo (international) Tel.: +47 22 90 00 00 VWR MEGA STAR 3.0 / 3.0R ver b, rel 25.06.2020 Email: info.de@vwr.com Email: info.no@vwr.com...
