Summary of Contents for Kalamazoo K16-18
- Page 1 KALAMAZOO INDUSTRIES, INC. KALAMAZOO, MI. PH: (269) 382-2050 www.kalamazooind.com K16-18 16” TO 18” CHOP SAW MANUAL MADE IN USA...
- Page 2 Electrical: CAUTION: Voltage changes require wiring changes at drive motor. WARRANTY DOES NOT COVER unauthorized wiring changes/failures. Consult an electrician an electrician if your not familiar with electrics. K16-18 SETUP • BEFORE STARTING OR CONNECTING ELECTRICAL VERIFY THE PHASE AND VOLTAGE OF THE UNIT.
- Page 3 BASIC K16-18 AND K20SSF OPERATION 1. Be sure of the correct electrical power (phase and voltage) for the motor. The motor has a wiring diagram with specifications on the outer motor case. Verify electrical power before operating. Connect incoming AC power to L1, L2, and L3 on the contactor. CAUTION: IF NOT FAMILIAR WITH ELECTRICAL, CONSULT AN ELECTRICIAN!!! FOLLOW ALL SAFETY PROCEDURES.
- Page 4 inch...
- Page 5 TRUNNION FOR KM16-18, K16-18, K20SSF 831-021 1/4SQ X 2 KEY (NEW STYLE) HHC5037036 3/8-16 X 2-1/4 HHCS GR 5 Z NEW STYLE TRUNNION PIN FOR K16-18, KM 700-003 STYLE TRUNNION, K20SSF SAW ARM FOR K16-18, KM16-18, AND K20SSF 10 002-005 11 044-004...
