Specifications - P521

Product Specifications
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
DVI
DVI-D 24pin
DisplayPort DisplayPort Connector Digital RGB
VGA
15pin Mini D-sub
RGB/HV
BNC (R,G,B,H,V)
HDMI
HDMI Connector
DVD/HD1
RCA (Y, Cb/Pb, Cr/Pr)
DVD/HD2
BNC
VIDEO1
BNC/RCA
VIDEO2
BNC
S-VIDEO
Mini DIN 4 pin
Output Signal
RGB/HV
BNC (R,G,B,H,V)
DVD/HD2
BNC
VIDEO1/VIDEO2 BNC
AUDIO
AUDIO
RCA (L/R) X2
Input
STEREO Mini Jack
HDMI Connector
DisplayPort Connector Digital Audio
AUDIO
RCA (L/R)
Output
Speaker Output
Control
Power Supply
Operational Environment
Storage Environment
Dimension
Weight
VESA compatible arm mounting interface
Power Management
Plug & Play
Accessories
NOTE: Technical specifications are subject to change without notice.
52" /1321 mm diagonal
Pixel Pitch:
0.6 mm
Resolution:
1920 x 1080
Color:
Over 16 million colors (depending on video card used)
Brightness:
700 cd/m
Contrast Ratio:
2000:1
Viewing Angle:
89° (typ) @ CR>10
Design View Distance:
1300 mm
Horizontal:
15.625/15.734 kHz, 31.5 kHz - 91.1 kHz (Analog Input)
31.5 kHz - 91.1 kHz (Digital Input)
Vertical:
50.0 - 85.0 Hz
25.2 MHz - 162.0 MHz
1152.0 x 648.0 mm
Digital RGB
DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
DisplayPort Complies with Standard V1.1a, applicable to HDCP1.3
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Analog RGB
0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync
Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Analog RGB
0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync
Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Digital RGB
HDMI
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz
Component
Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
Composite
1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
S-VIDEO
Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Analog RGB
0.7 Vp-p with 75 ohm terminated
Separate HV sync: TTL level (Posi / Nega)
Component
Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
Composite
1.0 Vp-p with 75 ohm terminated
Analog Audio
Stereo L/R 0.5 Vrms
Digital Audio
PCM 32, 44.1, 48 KHz (16/20/24bit)
PCM 32, 44.1, 48 KHz (16/20/24bit)
Analog Audio
Stereo L/R 0.5 Vrms
External Speaker Jack 15 W + 15 W (8 ohm)
RS-232C In:
9 Pin D-sub
RS-232C Out:
9 Pin D-sub (with daisy chain)
LAN:
RJ-45 10/100 BASE-T
Remote IN:
Stereo Mini jack 3.5
Remote OUT:
Stereo Mini jack 3.5
4.9 - 2.0 A @ 100-240VAC, 50/60Hz
Temperature:
5 - 40°C / 41 - 104°F (Default brightness), 5 - 20°C / 41 - 68°F (Max brightness)
Humidity:
20 - 80% (without condensation)
Altitude:
0 - 3000 m (Brightness may decrease with altitude)
Temperature:
-20 - 60°C / -4 - 140°F
Humidity:
10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C
1200.0 (W) x 696.0 (H) x 147.5 (D) mm / 47.2 (W) x 27.4 (H) x 5.8 (D) inches
40.0 Kg (88.2 lbs)
400 mm x 400 mm (M6, 4 Holes)
VESA DPM
VESA DDC2B, DDC/CI, DisplayPort
Setup manual, Power Cord, Video Signal cable, Remote Control, AA Battery x 2, Clamp x 3,
Screw x 9, CD-ROM, Thumbscrew for optional stand x 2, Cable cover
2
(Max.), 500 cd/m
2
(Typ.) @25°C
English-38
1
, 1920X1080 (60Hz)
1
, 1920x1080 (60 Hz)
1
, 1920X1080 (60Hz)
1
, 1920X1080 (60Hz)
*1: Compressed image
