Connections

NOTE: Do not connect/disconnect cables when turning on the monitor or other external equipment as this may result in a
loss of the monitor image.
NOTE: Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor turns down the sound.
Before making connections:
*
First turn off the power of all the attached equipment and make connections.
*
Refer to the user manual included with each separate piece of equipment.

Wiring Diagram

DVD player
with HDMI out
Computer (Analog)
*: Multiple monitors that are daisy-chained have a limit to the connectable monitors.
Connected
Connecting
equipment
terminal
DVD/HD1 (3RCA)
DVI (DVI-D)
HDMI
AV
DVD/HD+VIDEO
VIDEO1 (BNC&RCA)
S-VIDEO
VIDEO2 (5BNC)
DVD/HD2 (5BNC)
VGA (D-Sub)
PC
DVI (DVI-D)
RGB/HV (5BNC)
DisplayPort
*1: depend on signal type.
AUDIO IN 1, 2 and 3 can be used for audio input. To select audio source [IN1], [IN2] or [IN3] in AUDIO INPUT in OSD
menu or press the AUDIO INPUT button (remote control).
DVD player
Computer (Digital)
Setting in Terminal Mode
-
DVI MODE: DVI-HD
RAW/EXPAND*
1
SCART: ON
-
-
BNC MODE: VIDEO
BNC MODE: COMPONENT
-
DVI MODE: DVI-PC
BNC MODE: RGB
-
English-14
Stereo Amplifier
VCR or DVD
Player
Input signal
Connecting
name
Audio terminal
DVD/HD1
AUDIO IN1, IN2, IN3
DVI
AUDIO IN1, IN2, IN3
HDMI
HDMI
SCART
AUDIO IN1, IN2, IN3
VIDEO1
AUDIO IN1, IN2, IN3
S-VIDEO
AUDIO IN1, IN2, IN3
VIDEO2
AUDIO IN1, IN2, IN3
DVD/HD2
AUDIO IN1, IN2, IN3
VGA
AUDIO IN1, IN2, IN3
DVI
AUDIO IN1, IN2, IN3
RGB/HV
AUDIO IN1, IN2, IN3
DPORT
DPORT
Second monitor*
DVD player with
SCART OUT
Input button
in remote control
DVD/HD
DVI
HDMI
DVD/HD
VIDEO
S-VIDEO
VIDEO
DVD/HD
VGA
DVI
RGB/HV
DISPLAYPORT
