Table of Contents
LAN SETTING
DHCP
IP ADDRESS
SUBNET MASK
DEFAULT GATEWAY
DNS PRIMARY
DNS SECONDARY
SETTING COPY
COPY START
ALL INPUT
MULTI DISPLAY RESET

DISPLAY PROTECTION

POWER SAVE
All inputs except for TV*
STANDBY MODE
HEAT STATUS
FAN CONTROL
SCREEN SAVER
GAMMA
BRIGHTNESS
MOTION
SIDE BORDER COLOR
AUTO BRIGHTNESS
DPORT, DVI, VGA, RGB/HV inputs only
CHANGE SECURITY
PASSWORD
SECURITY LOCK
DDC/CI
DISPLAY PROTECTION
RESET
*: The product you purchased may not have this feature.
When you use this function, EXTERNAL CONTROL should be "LAN".
NOTE: When changing the LAN SETTING, turn the monitor off and then back on.
After turning on the monitor, you need to wait several seconds until the LAN SETTING is applied.
Enabling this option automatically assigns an IP address to the monitor from your DHCP server.
Disabling this option allows you to register the IP address or subnet mask number obtained
from your network administrator.
NOTE: Consult your network administrator for the IP address when "ENABLE" is selected for [DHCP].
Set your IP address of the network connected to the monitor when "DISABLE" is selected for [DHCP]. 192.168.0.10
Set your subnet mask number of the network connected to the monitor when "DISABLE" is
selected for [DHCP].
Set your default gateway of the network connected to the monitor when "DISABLE" is selected
for [DHCP].
Set your primary DNS settings of the network connected to the monitor.
Set your secondary DNS settings of the network connected to the monitor.
In a daisy chain scenario, select the OSD menu categories that you want to copy over to the
other monitor. NOTE: When you use this function, EXTERNAL CONTROL should be "RS-232C".
This function resets to default when power is off. This function has a limit depending on the
cable you use.
Select "YES" and press the SET button to start copying.
All input terminals settings are copied when you select this item. Default is off.
Resets "MULTI DISPLAY" options back to factory settings.
Sets how long the monitor waits to go into power save mode after the signal is lost.
Note: When connecting DVI, the video card might not stop sending the digital data even though
the image might have disappeared. If this occurs the monitor will not switch into power
management mode (standby mode).
Lowers power consumption.
Note: When in ECO STANDBY mode, DDC/CI does not function.
Displays status of the FAN, BRIGHTNESS and TEMPERATURE.
Cooling fan reduces the temperature of the display to protect from overheating.
If "AUTO" is selected, you can adjust the start temperature of the cooling fan and fan speed.
Use the SCREEN SAVER function to reduce the risk of Image Persistence.
The display gamma is changed and fixed when "ON" is selected.
The brightness is decreased when "ON" is selected.
NOTE: Do not select this function when picture model is AMBIENT1 or AMBIENT2.
The screen image is slightly expanded and moves in 4 directions (UP, DOWN, RIGHT, LEFT)
at user determined intervals. You can set interval time and zooming ratio.
This function is disabled when PIP, STILL, TEXT TICKER or TILE MATRIX are enabled.
Adjusts the color of the side borders when a 4:3 image is displayed.
Press + button, the bar will become lighter.
Press - button, the bar will become darker.
Adjusts the brightness level according to the input signal.
NOTE: Do not select this function when picture model is AMBIENT1 or AMBIENT2.
Allows the security password to be changed.
The factory preset password is 0000.
Locks the security password.
ENABLE/DISABLE: Turns ON or OFF the two way communication and control of the monitor.
Resets the following settings within the DISPLAY PROTECTION menu back to factory setting:
POWER SAVE, STANDBY MODE, FAN CONTROL, SCREEN SAVER, SIDE BORDER COLOR,
AUTO BRIGHTNESS, DDC/CI.
English-24
DISABLE
255.255.255.0
192.168.0.1
0.0.0.0
0.0.0.0
NO
-
ON
ECO
STANDBY
-
AUTO
OFF
OFF
OFF
15
OFF
-
OFF
ENABLE
-
