Specifications
Monitor Specifications
LCD Module
Viewable Image Size: 48 cm/19.0 inches
Native Resolution (Pixel Count): 1280 x 1024
Input Signal
Display Colors
Synchronization Range
Viewing Angle
Image Formation Time
Resolutions Supported
Active Landscape: Horiz.: 376 mm/14.8 inches
Display Area
Portrait: Horiz.: 301 mm/11.9 inches
Power Supply
Power Consumption
(without optional Sound Bar)
Current Rating
Dimensions
Height Adjustment: 130 mm/5.1 inches (Landscape)
Weight
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Storage Temperature: -10°C to 60°C/14°F to 140°F
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on the screen is actually
one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 NEC DISPLAY SOLUTIONS cites recommended resolution for optimal display performance.
NOTE: Technical specifications are subject to change without notice.
MultiSync LCD1980FXi Monitor
Diagonal: 48 cm/19.0 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7V p-p and Sync Negative 0.3V p-p)
16,777,216
Horizontal: 31.5 kHz to 81.1 kHz
Vertical: 50 Hz to 85 Hz
Left/Right: ±89° (CR > 10)
Up/Down: ±89° (CR > 10)
18 ms (Typ.)
Landscape: 720 x 400*
1
640 x 480*
1
800 x 600*
1
832 x 624*
1
1024 x 768*
1152 x 864*
1280 x 1024 at 60 Hz*
Portrait: 480 x 640*
1
600 x 800*
1
624 x 832*
1
768 x 1024*
864 x 1152*
1024 x 1280 at 60 Hz*
Vert.: 301 mm/11.9 inches
Vert.: 376 mm/14.8 inches
AC 100-240V ~ 50/60Hz
48W (typ)
0.48A@100-120V / 0.23A@220-240V (without optional Sound Bar)
0.55A@100-120V / 0.25A@220-240V (with optional Sound Bar)
Landscape: 402.3 mm (W) x 361.5 - 491.5 mm (H) x 200.0 mm (D)
16.2 inches (W) x 14.4 - 19.5 inches (H) x 7.9 inches (D)
Portrait: 330.3 mm (W) x 397.5 - 521.5 mm (H) x 200.0 mm (D)
13.3 inches (W) x 16.9 - 21.0 inches (H) x 7.9 inches (D)
9.7 kg (21.4 lbs)
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
Humidity: 10% to 85%
Feet: 0 to 40,000 Feet
: VGA-Text
at 60 Hz to 85 Hz
at 56 Hz to 85 Hz
at 75 Hz
at 60 Hz to 85 Hz
1
at 75 Hz
1
to 75 Hz
2
at 60 Hz to 85 Hz Some systems may not support all modes listed.
at 56 Hz to 85 Hz
at 75 Hz
at 60 Hz to 85 Hz
1
at 75 Hz
1
to 75 Hz
2
12
Notes
Active matrix; thin film transistor (TFT) liquid
crystal display (LCD); 0.294 mm dot pitch;
270 cd/m white luminance, typical;
2
600:1 contrast ratio, typical.
Digital Input: DVI
Depends on display card used.
Automatically
Automatically
Some systems may not support all modes listed.
