LAST DETECT: The video input has to be switched to the "LAST DETECT" mode. When the monitor is
displaying a signal from the current source and a new secondary source is supplied to the monitor, then the
monitor will automatically switch to the new video source. When current video input signal is not present, then
the monitor searches for a video signal from the other video input port. If the video signal is present in the
other port, then the monitor switches the video source input port to the new found video source automatically.
NONE: The Monitor will not search the other video input port unless the monitor is turned on.
DVI SELECTION: This function selects the DVI input mode (Input 1). When the DVI selection changes, the
AUTO: By using the DVI-D to DVI-D cable, the DVI SELECTION is DIGITAL.
By using the D-SUB to DVI-A cable, the DVI SELECTION is ANALOG.
DIGITAL: DVI digital input is available.
ANALOG: DVI analog input is available.
Note: For the MAC with digital output: Before turning on the MAC, the DVI Input mode must be set to
DIGITAL in "DVI SELECTION" of OSM by pressing "SELECT" button then "CONTROL" button when the DVI
signal cable is connected to the DVI-I connector (Input1) of the monitor. Otherwise the MAC may not turn on.
Note: Depending on the PC and Video card used, or when another Video signal cable is attached, this
function may not operate.
OFF TIMER: Monitor will automatically power-down when after reaching a pre-determined amount of time that
as determined by the end user.
IPM: Monitor will go into power-save mode automatically a few minutes after the surrounding illumination is less
than the one pre-determined at the User Setting.
You can adjust this illumination setting in the Advanced menu Tag 7.
During power-save mode, the LED is blinks amber.
During power-save mode, push any of the front buttons, except the POWER or SELECT buttons, and the
monitor will return to normal mode.
When the surrounding illumination is higher than pre-determined User Setting, the monitor will return to
normal mode automatically.
Tools 2
LANGUAGE: OSM control menus are available in seven languages.
OSM LEFT/RIGHT: You can choose where you would like the OSM control image to appear on your screen.
Selecting OSM Location allows you to manually adjust the position of the OSM control menu
left or right.
OSM DOWN/UP: You can choose where you would like the OSM control image to appear on your screen.
Selecting OSM Location allows you to manually adjust the position of the OSM control menu down or up.
OSM TURN OFF: The OSM control menu will stay on as long as it is in use. In the OSM Turn Off submenu,
you can select how long the monitor waits after the last touch of a button to shut off the OSM control menu.
The preset choices are 10-120 seconds by 5 seconds increments.
OSM LOCK OUT: This control completely locks out access to all OSM control functions. When attempting to
activate OSM controls while in the Lock Out mode, a screen will appear indicating the OSM controls are locked
out.
There are three types of OSM LOCK OUT:
OSM LOCK OUT with BRIGHTNESS and CONTRAST control: To activate this OSM Lock Out function, press
SELECT, then "+" key and hold down simultaneously. To deactivate this OSM Lock Out, press SELECT, then "+" key
and hold down simultaneously while in the OSM menu. BRIGHTNESS and CONTRAST can be adjusted while in
the lock out mode.
OSM LOCK OUT with no control: To activate this OSM Lock Out function, press SELECT, then ">" key and hold
down simultaneously. To deactivate this OSM Lock Out, press SELECT, then ">" key and hold down simultaneously
while in the OSM menu. No controls can be adjusted while in the lock out mode.
OSM LOCK OUT with BRIGHTNESS (only) control: To activate this OSM Lock Out function, press SELECT, then "–"
and "<" keys and hold down simultaneously. To deactivate this OSM Lock Out, press SELECT, then "+" key and
hold down simultaneously while in the OSM menu. BRIGHTNESS can be adjusted while in the lock out mode.
OSM ROTATION: Rotates the OSM between Landscape and Portrait modes.
RESOLUTION NOTIFIER: This optimal resolution is 1280 x 1024. If ON is selected, a message will appear
on the screen after 30 seconds, notifying you that the resolution is not at 1280 x 1024.
HOT KEY: You can adjust the brightness and contrast directly. When this function is set to ON, you can
adjust the brightness with
be accessed with the EXIT button.
computer has to be restarted.
or , contrast with + or - key, while the OSM menu is off. The standard OSM can
