Field Implementation & Environmental Conditions
Figure 2. DIN Rail Mounting Position
#
Description
1
SIM card slot
2
DIN rail mounting bracket
• Mounting the unit on a wall
If there is no DIN rail available for the mounting, you can also fix your Ewon
IG-0031-00 1.2
®
Cosy+ directly on the wall.
®
Ewon
Cosy+
Page 5 of 32
