Product Summary

2. Product Summary
2.1. Type & Part Numbers
There are 5 models of the Ewon
They include the following part numbers:
Part number
Model
EC71330_00MA
01702
EC7133J_00MA
04002
EC7133K_00MA
04102
EC7133L_00MA
04302
EC7133M_00MA
04402
The part number syntax is explained in the
Technical specification and certification by model can be found in the

2.2. Hardware General Specification

Characteristic
Design
Clock
Ethernet Interface
Digital Input
Digital Output
Mounting
2.3. Typical Applications for Ewon
®
You can use the Ewon
Cosy+ for :
• Remote access of Ethernet and / or USB devices using Talk2M connection
®
The Ewon
Cosy+ should not be used
• As a pure Ethernet switch.
IG-0031-00 1.2
®
Cosy+ each proposing different communication media.
Model name
Description
®
Ewon
Cosy+ ETH
LAN / WAN – 4 Ethernet ports only
®
Ewon
Cosy+ WiFi
LAN / WAN, Wi-Fi – 4 Ethernet ports, WiFi Modem (802.11 a/b/g/n)
®
Ewon
Cosy+ 4G NA
LAN / WAN, 4G quad–band – 4 Ethernet ports, Cellular Modem (NA)
®
Ewon
Cosy+ 4G EU
LAN / WAN, 4G quad–band – 4 Ethernet ports, Cellular Modem (EU)
®
Ewon
Cosy+ APAC
LAN / WAN, 4G quad–band – 4 Ethernet ports, Cellular Modem (APAC)
Label (page 9)
Value
Industrial design:
• 24Vdc power supply
• DIN Rail mounting
• Extended temperature: -25°C to +60°C
Backed up real time clock (RTC)
Backup battery lifetime has 10 years expectancy
LAN Ethernet port 10 / 100 Mbps
2
1
Latch is DIN Rail EN50022 compliant.
®
Cosy+
section.
Ewon Cosy+ models (page 15)
®
Ewon
Cosy+
section.
Page 2 of 32
