CENTRALINA DI COMANDO
GB
CONTROL UNIT
UNITÉ DE COMMANDE
F
E
CENTRAL DE MANDO
ISTRUZIONI D'USO E DI INSTALLAZIONE
INSTALLATION AND USER'S MANUAL
INSTRUCTIONS D'UTILISATION ET D'INSTALLATION
INSTRUCCIONES DE USO Y DE INSTALACION
www.BFTGateOpeners.com | (800) 878-7829
D811340 vers. 03 03-12-07
8
027908
1 9 5 4 8 7
RIGEL-4 UL
Advertisement
Related Manuals for BFT RIGEL-4 UL
Summary of Contents for BFT RIGEL-4 UL
- Page 1 CONTROL UNIT 027908 1 9 5 4 8 7 UNITÉ DE COMMANDE CENTRAL DE MANDO RIGEL-4 UL ISTRUZIONI D’USO E DI INSTALLAZIONE INSTALLATION AND USER’S MANUAL INSTRUCTIONS D’UTILISATION ET D’INSTALLATION INSTRUCCIONES DE USO Y DE INSTALACION www.BFTGateOpeners.com | (800) 878-7829...
-
Page 2: General Safety
40 terminals. The wiring diagram of the • The gate must be properly installed and work freely in both directions prior board is shown in figure 2. www.BFTGateOpeners.com | (800) 878-7829 RIGEL-4 UL - Ver. 03... - Page 3 36-37 Close limit switch motor 1 (n.c.) gate if closed and vice versa. 38-39 Open limit switch motor 2 (n.c.) 39-40 Close limit switch motor 2 (n.c.) 5) Functions controlled by the trimmers used. www.BFTGateOpeners.com | (800) 878-7829 RIGEL-4 UL - Ver. 03 -...
