AAXA Technologies LED PICO + User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

aaxa
TECHNOLOGIES
LED PICO +
Pico Projector
User Guide

Advertisement

Table of Contents
loading

Related Manuals for AAXA Technologies LED PICO +

Summary of Contents for AAXA Technologies LED PICO +

  • Page 1 aaxa TECHNOLOGIES LED PICO + Pico Projector User Guide...
  • Page 2 Caution! WARNING: Please use this product as instructed. Misuse may cause injury or death. DO NOT use while driving Caution for Battery Use • Do not pierce or puncture the battery DO NOT expose to water or wet with sharp objects surfaces.

  • Page 3: Table Of Contents

    Table of Contents Connecting a USB Drive Chapter 1: LED Pico+ at a Glance Chapter 3: Menu Screens LED Pico+ Introduction Main Menu Keypad Keypad Video Player Menu Accessories Photo Menu Chapter 2: Getting Started Chapter 4: Settings Menu Charging & Powering On / Off Picture Settings Focus Adjustment / Throw Distance Sound Settings...

  • Page 4: Chapter 1: Led Pico+ At A Glance

    Chapter 1 LED Pico+ at a Glance Main Unit Front/Back USB Port Charging Port Back/Exit Mini Digital AV Port AV Input Focus Adjustment Audio Out Power Button Menu Navigation Hard Reset TF Card Slot...

  • Page 5: Keypad

    Keypad Back/Exit On/Off Directional Keys...

  • Page 6: Accessories

    Accessories USB-C Charge Cable Tripod HDMI to Mini HDMI Cable AV Cable * Under various circumstances, the actual accessories may be different from those shown in the pictures above.

  • Page 7: Chapter 2: Getting Started

    Chapter 2 Getting Started Charging the projector Turn the LED Pico+ Projector completely off before charging. Connect the USB-C end of the included Charge Cable to the DC port of the LED Pico+ Projector. Connect the USB end of the included Charge Cable to a power source. For continu- ous operation, a USB charger with 5V/2A output is required.

  • Page 8: Focus Adjustment / Throw Distance

    Focus Adjusment / Throw Distance Focus Adjustment • Spin the focus wheel up or down until the image becomes clear. Throw Distance Chart Throw Distance Diagonal Size Units: Inches Units: Inches 16:9 Aspect Ratio Throw Ratio 1.9 Projection Angle: 0% Offset *minimum throw distance: 10 inches...

  • Page 9: Mirroring Menu

    Mirroring Menu • The LED Pico+ allows for wireless mirroring and projection of smartphone content including pictures, videos, and other on- screen media. The wireless mirroring function works through a direct wireless connection and is compatible with smartphones that provide this feature. •...
  • Page 10 Mirroring Menu To Wirelessly Mirror your smart device In the Main Menu, select the Mirroring icon. In the Mirroring submenu, select your smart device manufacturer (iPhone compatible or Android compatible).
  • Page 11 Direct Mirroring for Android Compatible Devices • Once the Mirroring Menu appears, select the mirroring feature in your smart device. • For Samsung phones this is often the “Smart View” icon. (fig. 2.1) • The Smart View icon can typically be found by swiping down on the settings menu and selecting the icon;...
  • Page 12 Direct Mirroring For iPhone Compatible Devices • Enter the “iPhone Compatible” mirroring submenu • Go to your iPhone settings, Select Wireless Connections (fig. 2.3) • Select “AAXA-PICOPLUS” as a wireless connection (fig. 2.4) fig. 2.3 fig. 2.4...
  • Page 13 Direct Mirroring For iPhone Compatible Devices • The password should be “12345678”. • In your iPhone’s “Screen Mirroring” menu, select AAXA-PICOPLUS (fig. 2.5). The Screen Mirroring Menu can typically be found by swiping down from the Home screen. • Tap “Stop Mirroring” when you wish to stop mirroring your iPhone. fig.
  • Page 14 A: The LED Pico+ is compatible with wired mirroring through Apple’s pro- prietary Lightning to HDMI adapter. This can be purchased from an autho- rized Apple Retailer. Note: Samsung is a trademark of Samsung Group and iPhone is a trade- mark of Apple inc. AAXA Technologies Inc claims no rights.

  • Page 15: Connecting To A Device Via Digital Av

    Connecting to a Device via Digital AV The LED Pico+ has a mini-Digital AV port. A Digital AV cable is required to connect your LED Pico+ to Digital AV compatible devices. In the Main Menu Select “INPUTS” icon Select “DIGITAL” icon Connectivity to Multimedia Devices The LED Pico+ can connect to many media devices including: computers, laptops, iPhones, iPads, DVD players, smart phones, cameras, video game consoles and...
  • Page 16 Connecting to a Device via Digital AV (Cont) Step 1: Connect one end of the mini-Digital AV Cable to your device’s Digital AV port. Step 2: Connect the other end of the mini-Digital AV Cable to your LED Pico+’s Video In port. Step 3: In the Main Menu, select the “INPUTS”...

  • Page 17: Connecting To A Computer

    Connecting to a Computer Step 4: Enabling Digital Video output on your Computer – To enable Digital Video output on your computer most computers require “turning on” the video output feature. Each computer is different. Please consult your owner’s manual for instructions to enable Digital Video output. Below are standard instructions for a Windows 10 computer –...

  • Page 18: Connecting To Composite Video

    Connecting to Composite Video Step 1: Connect the 3.5mm Composite AV Cable to the AV Port of the LED Pico+. Step 2: Plug the composite end of the AV Cable (Red, White,Yellow) to your device.
  • Page 19 Connecting to Composite Video Cont. Step 3: In the Main Menu Select “INPUTS” icon Select “AV” icon Step 4: Turn on your multimedia device. If available, select 1280x720 or 1920x1080. Connectivity with multimedia devices The LED Pico+ can connect to many media devices including: DVD players, Blu- Ray players, smartphones, cameras, video game consoles and other peripherals with ease.

  • Page 20: Connecting To Speaker Or Headphones

    Connecting to Speakers / Headphones Step 1: Connect your speaker/headphones to the projector’s audio port. Step 2: Ensure that the projector and/or the headphones are powered on. Step 3: Place the headphones on and enjoy! *CAUTION Prolonged use of headphones at a high volume may impair hearing.

  • Page 21: Connecting A Tf Card

    TF Card How to insert your TF Card • Slide in your TF card into the TF card slot on the side of the LED Pico+ (facing up as shown in picture). • Gently slide the TF card until it clicks into place.
  • Page 22 TF Card Cont. File Menu System • The LED Pico+ will show all folders and files you have on your TF Card. • Use the keypad to navigate to different Media Player menu folders or files. • In the Main Menu, select the type of file you wish to play.

  • Page 23: Connecting A Usb Drive

    USB Drive How to insert your USB Drive • Slide your USB Drive (up to 64GB) into the USB port. • Gently slide the drive until it cannot go in any further. How to access your USB Drive • Once your USB Drive has been inserted, you can navigate to any media content in the Main Menu.
  • Page 24 USB Drive Cont. File Menu System • The LED Pico+ will show all folders and files you have on your USB Drive. • Use the keypad to navigate to different Media Player menu folders or files. • In the Main Menu, select the type of file you wish to play.

  • Page 25: Chapter 3: Menu Screens

    Chapter 3 Menu Screens Main Menu The LED Pico+ features a built-in PMP (Portable Media Player) function. This function allows the projector to play videos and pictures directly from your connected devices. • Press the left and right directional buttons on the keypad to choose an icon from the Main Menu.

  • Page 26: Video Player Menu

    Video Player Menu Opening a file: • Select the “Video” icon. • From the sub menu, select the storage media with the stored files. • Choose which file you wish to play. The LED Pico+ will show all folders and files you have on your USB or TF card. Use the keypad to select folders or files.
  • Page 27 Video Player Menu While Playing Videos While playing videos, you can adjust the volume by pressing the right and left buttons on the keypad. Other video playback controls are available in the video player submenu - which is accessible by pressing the “OK” button. Volume Down Volume Up Enter Video Player Submenu...
  • Page 28 Video Player Sub-Menu Playing Videos The Video Player Sub-Menu can be accessed by pressing “OK” during video playback. To exit the Video Player Sub-Menu, press the “Back” button or wait 10 seconds. To navigate the Playback Menu, use the directional buttons on the keypad to highlight the option you wish to choose.
  • Page 29 Video Playback FAQ How do I loop a video? 1. Choose either USB or TF Card for playback 2. Navigate the folders until you reach the file you wish to play. 3. Choose the file you want to play. 4. Press “OK” when video is playing, then move selection left on video player menu to “Repeat A”...

  • Page 30: Photo Menu

    Photo Menu Opening A File: • Select the “Photo” icon. • From the sub menu, select the storage media with the stored files. • Choose the file you wish to play. The LED Pico+ will show all folders and files you have on your USB Drive or TF Card.
  • Page 31 Photo Menu While Viewing Pictures While viewing pictures, you can simply navigate through all images by pressing the left and right buttons on the keypad. Further controls are available in the Photo Submenu - which is accessed through the “OK” button. Previous Picture Next Picture...
  • Page 32 Photo Sub-Menu Viewing Pictures: After pressing “OK” during picture slide-show playback, the Photo Sub-Menu appears. To exit the Photo Sub-Menu, press the “Back” button or wait for 10 seconds. Pictures can be rotated and zoom in/out based on the option you choose on the Sub-Menu.
  • Page 33 Photo Slideshow FAQ How do I convert PPT to JPG? Open your presentation on your PC or Mac. Go to “Save As” and save your pre- sentation as .JPG files. Choose “All slides”. *If you have more than 10 slides, you must rename Slides 1-9 with a “0”...
  • Page 34 Photo Slideshow FAQ Cont. How do I manually control the How do I play a slideshow? slideshow? Choose either USB or TF Card for playback. After selecting the photo you wish to Navigate to the folder that contains display, you can press “play” to start the pictures you wish to see in the the slideshow in the photo submenu slideshow.

  • Page 35: Chapter 4: Settings Menu

    Chapter 4 Settings Menu The Settings Menu can be accessed by selecting “SETTINGS” on the main menu Picture • Picture Mode • Contrast • Brightness • Color • Sharpness • Color Temperature • Noise Reduction Sound • Sound Mode • Treble •...

  • Page 36: Picture Settings

    Picture Settings Picture Mode • Changes the picture mode to dif- ferent settings depending on your usage. Contrast • Adjusts the contrats of the image. Brightness • Adjusts the brightness of the image. Color • Adjusts the color of the image. Color Temperature •...

  • Page 37: Sound Settings

    Sound Settings Sound Mode • Changes the sound mode depending on what is currently playing (Standard, Movie, Music, Sports, User). Treble • Adjusts the treble of the sound. Bass • Adjusts the bass of the sound. Balance • Adjusts the balance of the sound, from left to right.

  • Page 38: Option Settings

    Option Settings OSD Language • Adjusts the language. Aspect Ratio • Changes the aspect ratio of the projection image. Screen Mode • Sets the screen mode to Auto, PC or Video. Reset • Resets the projector. Software Update (USB) • Updates the software of the projector.

  • Page 39: Brightness

    Brightness • Sets the brightness of the projector to “eco” Standard • Sets the brightness of the projector to “standard”...

  • Page 40: Chapter 5: Technical Details

    Chapter 5 Technical Details FAQs QUESTIONS ANSWERS Does this unit have an audio output connection Yes, the LED Pico+ has a headphones out jack or not? (3.5 mini jack). Is there a tripod in the box? Yes, the LED Pico+ comes with a mini tripod. How long should I charge this projector? 5-6 hours should be sufficient, the led light next to the charging port will change to green when fully...

  • Page 41: Troubleshooting

    Technical Details Troubleshooting IMAGE IS BLURRED Possible Causes Solution The Projector is not in focus. Adjust the focus with the focus adjustment dial until the image comes into focus. The Projector is offset from plane / angle of opera- Move the projector so that it is both 180 degrees tion.
  • Page 42 Technical Details Troubleshooting THE PROJECTOR DOES NOT TURN ON Possible Causes Solution Low battery Charge the projector until the battery is fully charged (LED indicator on botton of unit show a green light). Projector must be turned off while charging. There is no power.
  • Page 43 Technical Details Troubleshooting THE PROJECTOR SHUTS OFF WHILE IN USE Possible Causes Solution Incorrect power output used For continuous operation, a USB Charger with 5V/2A output is required. Laptop USB port or 5V/1A output USB chargers does not support continuous operation and will cause unit to shut off when battery is being used up.

  • Page 44: Specifications

    Specifications Brightness: 30 Lumens Native Resolution: 1280x720 (720p) Contrast Ratio: 1000:1 Aspect Ratio: 16:9 Projection Lens: Manual Focus Image Size: 10~60 inches Lamp: Triple RGB LEDs with Vibrant Color Technology Life 20,000hrs Video in: Composite A/V Mini-Digital AV Audio Output: 3.5 mm audio jack TF Card: TF Card Slot...

  • Page 45: Notes

    Notes...
  • Page 46 Please direct all customer service inquiries to: AAXA Technologies, Inc. 17781 Sky Park Cir., Suite F Irvine, CA 92614 (714) 957-1999 info@aaxatech.com...
