AAXA Technologies P7 User Manual

Mini led projector
Hide thumbs
Table of Contents

Advertisement

Quick Links

aaxa
TECHNOLOGIES
User Guide

Advertisement

Table of Contents
loading

Related Manuals for AAXA Technologies P7

Summary of Contents for AAXA Technologies P7

  • Page 1 aaxa TECHNOLOGIES User Guide...
  • Page 2 Caution! WARNING: Please use this product as instructed. Misuse may cause injury or death. DO NOT use while driving Caution for Battery Use • Do not pierce or puncture the battery DO NOT expose to water or wet with sharp objects surfaces.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: P7 at a Glance Connecting to Device via Digital P7 Introduction Input Remote & Keypad Connecting to Computer via Accessories Chapter 2: Getting Started Connecting to Composite Video Powering On / Off Music Player Menu...

  • Page 4: Chapter 1: P7 At A Glance

    Chapter 1 P7 at a Glance Main Unit Front/Back Power Button AV Port Power Switch Headphone Out Focus Adjustment DC Port Infrared Receiver Digital Input mini-VGA Port (Remote Control) TF Card USB Port...

  • Page 5: Remote & Keypad

    Both the keypad and remote can be used to navigate through the menus. The Main Menu Navigation on the remote functions exactly the same as the directional pad on the P7 unit. NOTE: Pressing power on the remote will only put the projector in STANDBY mode.

  • Page 6: Accessories

    Accessories A/V Cable Power Adapter Remote VGA Adapter Cable Internal Battery (Sold Separately) (Sold Separately) *Under various circumstances, the actual accessories may be different from those shown in the pictures above. Additional accessories are available for purchase at www.aaxatech.com...

  • Page 7: Chapter 2: Getting Started

    Getting Started Powering ON the projector Connect the power cord to the P7. Connect the other end of the power cord into the wall power source. Toggle the On / Off switch on the side of the projector to the “ON” position -- the projector should automatically turn on.

  • Page 8: Focus Adjustment / Throw Distance

    Focus Adjusment / Throw Distance Focus Adjustment • Spin the focus wheel up or down until the image becomes clear. Throw Distance Chart Throw Distance Diagonal Size Units: Inches Units: Inches 16:9 Aspect Ratio Throw Ratio 1.20 Projection Angle: 100% Offset *minimum throw distance: 16 inches...

  • Page 9: Headphones

    Connecting Speakers / Headphones Step 1: Connect your speakers/headphones to the projector’s audio port. Step 2: Ensure that the projector and/or the headphones are powered on. Step 3: Place the headphones on and enjoy! *CAUTION Prolonged use of headphones at a high volume may impair hearing.

  • Page 10: Loading External Content

    Loading External Content The P7 can read files directly from both a TF Card and USB Drive. Supported file types include: MP3 / WMA / OGG / WAV AVI / JPG / GIF/ BMP (up to 32 GB) (up to 32 GB)
  • Page 11 Loading External Content Cont. How to insert your TF Card • Slide in your TF card into the TF card slot on the side of the P7 (as shown in picture). • Gently slide the TF card until it clicks into place.
  • Page 12 Loading External Content Cont. How to insert your USB Drive • Slide your USB Drive into the USB port. • Gently slide the drive until it cannot go in any further. (up to 32 GB)
  • Page 13 Loading External Content Cont. Once your TF Card or USB Drive is inserted into the projector, the TF Card or USB Drive Storage will be loaded automatically and the content can be found through the Photos, Videos and Music icons located on the Main Menu, depend- ing on the file type you wish to play.

  • Page 14: Chapter 3: Menu Screens

    Chapter 3 Menu Screens Main Menu The P7 features a built in PMP (Portable Media Player) function. This function allows the projector to play videos, pictures, and music files directly from your connected devices. LED Lights Direction Pad Input On / Off Exit/Back •...

  • Page 15: Brightness Menu

    Brightness Menu To change the brightness on your P7: • Select the “Brightness” icon (Fig. 3.1) • Select the brightness you wish (Fig. 3.2). Please note that “Boost” brightness is the only setting available when the projector is plugged into power.

  • Page 16: Video Player Menu

    From the submenu (Fig. 3.4), select the storage media with the stored files. • Choose which file you wish to play. Fig. 3.3 Fig. 3.4 The P7 will show all folders and files you have on your USB or TF drive. Use the navigation buttons to select folders or files.
  • Page 17 Video Player Menu While Playing Videos While playing videos, the volume and keystone are adjustable. Further controls are available in the video player submenu - which is accessed through the “OK” button. Volume Down Positive Keystone Adjustment Volume Up Negative Keystone Adjustment Enter Video Player Submenu •...
  • Page 18 Video Player Submenu Playing Videos The Video Player Submenu can be accessed by pressing “OK” during video playback. To exit the Video Player Submenu, press the “Back” button or wait 5 seconds. To navigate the Playback Menu, use the directional buttons on the navigation pad or remote to highlight the option you wish to choose (Fig.
  • Page 19 Video Playback FAQ How do I loop a video? How do I preview a video? 1. Choose either USB or TF Card 1. Choose the “video” option from for playback the main menu 2. Navigate using either remote or onboard buttons to the file you wish to preview.

  • Page 20: Photo Menu

    Choose which file you wish to play Fig. 3.6 Fig. 3.7 The P7 will show all folders and files you have on your USB or TF Card drive. Use the navigation buttons to select folders or files. Previewing Files: •...
  • Page 21 Photo Menu While Viewing Pictures While viewing pictures, further controls are available in the Photo Submenu - which is accessed through the “OK” button. Keystone adjustment is also available. Previous Picture Positive Keystone Adjustment Next Picture Negative Keystone Adjustment Enter Photo Player Submenu •...
  • Page 22 Photo Submenu Viewing Pictures: The Photo Submenu can be accessed by pressing “OK” during picture slide-show playback. To exit the Photo Submenu, press the “Back” button or wait 5 seconds. To navigate the playback menu, use the directional buttons on the navigation pad or remote to highlight the option you wish to choose (Fig 3.8).
  • Page 23 Photo Slideshow FAQ How do I play a slideshow? How do I manually control the slideshow? 1. Choose either USB or TF Card for playback 1. After selecting the photo you wish to be displayed, you can press “play” to start the slideshow (as outlined in the previous FAQ).

  • Page 24: Connecting To Device Via Digital Input

    The P7 can connect to many media devices including: computers, laptops, iPhones, iPads, DVD players, smart phones, cameras, video game consoles and other peripherals with ease. *Some smartphones require video out capabilities to be displayed with the P7. Check with your phone manufacturer.
  • Page 25 Connect the other end of the Digital Input Cable to your P7’s Digital Input port. Step 3: In the Main Menu, select the “Digital Video” Icon. Your P7 should now be mirroring the content from your device. Note: If you’re connecting to a computer or laptop and the projector does not...
  • Page 26 Connecting to a Computer via Digital Input Step 4: After connecting your projector to your computer or laptop via a digital input cable, you may need to enabe Digital Video output on your computer. To enable Digital Video output on your computer most computers require “turning on”...

  • Page 27: Connecting To Computer Via Vga

    Connecting to a Computer via VGA First, a VGA adapter cable is required from your P7 to your computer. This can be purchased on the AAXA website at www.aaxatech.com Step 1: Connect one end of the VGA adapter cable to your computer’s VGA port.
  • Page 28 Connecting to a Computer via VGA Cont. Step 4: Enabling VGA output on your Computer – To enable VGA output on your computer most com- puters require “turning on” the video output feature. Each computer is different. Please consult your owner’s manual for instructions to enable VGA output. Below are standard instructions for a Windows 10 computer –...

  • Page 29: Connecting To Composite Video

    Connecting to Composite Video Step 1: Connect the 3.5mm Composite AV Cable to the back of the P7. Step 2: Connect the composite end of the AV Cable (Red, White,Yellow) to your device.
  • Page 30 Connecting to Composite Video Cont. Step 3: In the Main Menu Select “INPUT” icon Select “RCA” Step 4: Turn on your multimedia device.

  • Page 31: Music Player Menu

    Choose which file you wish to play. Fig. 3.5 Fig. 3.6 The P7 will show all folders and files you have on your USB or TF Card drive. Use the navigation buttons to select folders or files. Previewing Files: •...
  • Page 32 Music Player Menu Listening To Audio: To adjust the volume, use the left and right button on the projector or the volumes keys on the remote. To navigate the playback menu, push the “OK” button to open the menu and use the directional buttons on the navigation pad or remote to highlight the option you wish to choose (Fig 3.7).
  • Page 33 Music Playback FAQ How do I loop a song? How do I create a song playlist? Insert your media device (either TF 1. Choose either USB or TF Card card or USB) into computer. for playback Make a new folder on media device (folder name will be the name of the playlist).

  • Page 34: E-Book Viewer Menu

    Viewing Text Files: The P7 allows you to view .txt files only. Select the file you want to view in the file menu for the particular storage device on which the file is stored. You can press the up and down arrow buttons on the remote to flip through the pages you have in the present folder.

  • Page 35: Chapter 4: Settings Menu

    Restore Factory Default • Software Version Within the settings menu, there are Picture four more submenus that allow you • Picture Mode to customize your P7 to the settings • Brightness you want: • Color Temperature • Aspect Ratio •...

  • Page 36: Brightness Settings

    Brightness Settings There are 2 different power modes for the P7: Standard and Boost** • Standard: A normal mode. Available while plugged in and defaulted to while on battery. • Boost: The brightest mode. Only available while plugged in. **Boost mode should only be used in low temperature environments with adequate clear- ance of exhaust / intake vents.

  • Page 37: Sound Settings

    Sound Settings Sound Mode • Changes the sound mode depend- ing on what is currently playing Balance • Adjusts the sound balance manu- ally Auto Volume • With the Auto Volume On, the video can be opened with volume automatically Surround Sound •...

  • Page 38: Option Settings

    Option Settings Language Selection • Changes the language of the device. Options include English, Spanish, Chinese, German, French, Korean, Japanese Restore Factory Default • Restores the projector to factory settings Software Version • Displays the current software ver- sion on the projector...

  • Page 39: Picture Settings

    Picture Settings Picture Mode • Changes the picture mode to different settings depending on your usage Brightness • Changes the brightness setting Color Temperature • Adjusts the color temperature from warm to cool (red to blue) Aspect Ratio *Caution: Some pictures may be cut off when aspect ratio is set incorrectly •...

  • Page 40: Chapter 5: Technical Details

    Be sure to setup the computer to enable a video signal output. On some lap- tops this is done by pressing and holding Function F5 key. If using the P7 as an external monitor on Windows based systems, this can be done by selecting “extend my desktop to this monitor”.
  • Page 41 Technical Details Troubleshooting THE PROJECTOR DOES NOT TURN ON Possible Causes Solution There is no power Check to ensure the power outlet source is good. Check the power adapter to ensure a proper con- nection with the wall outlet as well as the projector. Confirm that the unit is charged and has enough power (if battery is installed).

  • Page 42: Specifications

    (32GB maximum) Dimensions: 4.7” x 4.4” x 2.7” Weight: 1.2 lbs Supported File Formats: MP3, WMA, OGG, WAV, JPG AVI, BMP, GIF, TXT *HDMI™ is a registered trademark of HDMI Licensing LLC. AAXA Technologies is not affiliated with HDMI Licensing LLC.

  • Page 43: Notes

    Notes...
  • Page 44 Please direct all customer service inquiries to: AAXA Technologies, Inc. 17691 Mitchell N., Unit #B Irvine, CA 92614 (714) 957-1999 info@aaxatech.com...
