- Page 1 aaxa TECHNOLOGIES Pico Projector P2jr User Guide...
- Page 2 Caution! WARNING: Please use this product as instructed. Misuse may cause injury or death. DO NOT use while driving Caution for Battery Use • Do not pierce or puncture the battery with sharp objects DO NOT expose to water or wet •...
-
Page 3: Table Of Contents
Table of Contents Chapter 1: P2jr at a glance Connecting to a USB drive Chapter 3: Menu Screens Main Unit Keypad Main menu Accessories File Menu System Chapter 2: Getting Started Video Player Menu Powering On / OFF Photo Viewer Menu Focus Adjustment / Throw Music Player Menu Distance... -
Page 4: Chapter 1: P2Jr At A Glance
Chapter 1 P2jr at a Glance Main Unit Back Button Directional Pad Cooling Fan Confirm Selection Power Button Speaker Projection Lens Charge Indicator Power Input Focus Adjustment USB Port Mini HDMI MicroSD Card Slot Mini A/V / VGA Input... -
Page 5: Keypad
Keypad Exit/Back Power ON / OFF This key allows you to return to Holding down the power the previous menu or exit from button for 3 seconds will the media player option. either turn the P2Jr ON or OFF. Directional Keypad Confirm Selection Use these keys in highlight the Use this key to select the... -
Page 6: Accessories
Accessories Standard Accessories Sold Separately Power Adapter Mini-Full HDMI VGA Cable Composite A/V Cable *Under various circumstances, the actual accessories may be different from those shown in the pictures above. -
Page 7: Chapter 2: Getting Started
Chapter 2 Getting Started Powering ON the projector Connect the power cord to the P2jr. Connect the wall plug into the wall power source. Press the POWER button and hold for 2-3 seconds to switch on or switch off the power •... -
Page 8: Focus Adjustment / Throw
Focus Adjusment / Throw Distance Focus Adjustment Spin the focus wheel up or down until the image becomes clear. The recommended focus distance for this projector is 12” to infinity. Throw Distance Chart Distance inch (“) Diagonal Inch (“) 4:3 Aspect Ratio Throw Ratio 1.25:1 *minimum throw distance: 10 inches... - Page 9 External Inputs/Outputs Composite Cable Micro SD Card HDMI Cable Laptop Desktop USB Stick...
- Page 10 Connecting to a Computer via VGA Step 1: Connect the large end of the to your computer’s VGA Cord VGA Adapter Step 2: to your P2jr’s Connect the small end of the VGA Adapter VGA Cord Step 3: In the Main Menu Select “VGA”...
-
Page 11: Connecting To A Computer
Connecting to a Computer Cont. Step 4: Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your computer most computers require “turning on” the video output feature. Each computer is different. Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are standard instructions for a Windows XP computer –... -
Page 12: Connecting To A Computer Via Hdmi
Connecting to a Computer via HDMI Step 1: Connect the large end of the to your computer’s HDMI Cord HDMI Adapter Step 2: to your P2jr’s Connect the small end of the HDMI Adapter HDMI Cord Step 3: In the Main Menu Select “HDMI”... - Page 13 Connecting to a Computer Cont. Step 4: Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your computer most computers require “turning on” the video output feature. Each computer is different. Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are standard instructions for a Windows XP computer –...
-
Page 14: Connecting To Composite Video
Connecting to Composite Video Step 1: Connect one end of the to your P2jr’s Composite A/V Cord A/V Adapter Step 2: to your devices Connect opposite end of Composite A/V Cord Composite A/V Cord... - Page 15 Connecting to Composite Video Cont. Step 3: In the Main Menu Select “A/V” icon Step 4: Turn on your multimedia device. Connectivity with multimedia devices The P2jr can connect to many media devices including: iPod, iPhone, iPad, VHS players, DVD players, smart phones, cameras, video game consoles and other peripherals with ease.
-
Page 16: Connecting To Hdmi Video
Connecting to HDMI Video Step 1: Connect one end of the to your P2jr’s HDMI Adapter Mini-HDMI Step 2: to your devices Connect opposite end of HDMI HDMI Adapter... - Page 17 Connecting to HDMI Video Cont. Step 3: In the Main Menu Select “HDMI” icon Step 4: Turn on your multimedia device. Connectivity with multimedia devices The P2jr can connect to many media devices including: iPod, iPhone, iPad, VHS players, DVD players, smart phones, cameras, video game consoles and other peripherals with ease.
- Page 18 MicroSD Card How to insert your MicroSD Card • Slide in your SD card into the SD card slot on the side of the P2jr. (as shown in picture) • Gently slide the SD card until it *clicks* into place. How to access your MicroSD Card •...
- Page 19 MicroSD Card Cont. Select the “MicroSD” icon File Menu System • The P2jr will show all folders and files you have on your SD Card. Media Player menu • Use the directional buttons to navigate • In the Media Player selection you can to different folders or files.
-
Page 20: Usb Reader
USB Reader How to insert your USB Drive • Slide your USB Drive into P2jr. (as shown in picture) • Gently slide the drive until it cannot go in any further How to access your USB Drive • Once your USB Drive has been inserted, you can navigate to the USB icon in the main menu. - Page 21 USB Reader Cont. File Menu System Select the “USB” icon • The P2jr will show all folders and files you have on your USB Drive. • Use the directional buttons to navigate Media Player menu to different folders or files. •...
-
Page 22: Chapter 3: Menu Screens
Chapter 3 Menu Screens Main Menu To access the main menu simply turn on the projector by pressing and holding the Power button for 3 seconds. • Scroll Left/Right by pressing buttons on the keypad. • To select a submenu, highlight the desired submenu and press the button located in the middle of the keypad. -
Page 23: File Menu System
File Menu System The P2jr will show all folders and files you have on your USB or MicroSD Drives. Use the directional buttons to navigate to different folders or files. Opening a file: • Choose Movie, Music, Photo or Text •... -
Page 24: Video Player Menu
Video Player Menu Viewing Videos To adjust the volume simply press the keys on the projector. For more options, press the to reveal more options. • To open the video player menu, Move selection left press “OK” on projector. Move selection right •... -
Page 25: Video Playback Faq
Video Playback FAQ How do I loop a video? How do I preview a video? 1. Choose either USB or SD Card Choose the “video” option from the main menu for playback Navigate using onboard buttons to the file you wish to preview. Highlight the file. -
Page 26: Photo Viewer Menu
Photo Menu Viewing Pictures To use the photo controls, use the directional keys to highlight the option you wish to choose. • To open the photo player menu, Move selection left press “OK” on projector. Move selection right • To close the photo player menu, hit “back”... - Page 27 Photo Slideshow FAQ How do I play a slideshow? How do I manually control the 1. Choose either USB or SD Card slideshow? After selecting the photo you wish to for playback be displayed, you can press “play” to start the slideshow (as outlined in the previous FAQ).
-
Page 28: Music Player Menu
Music Player Menu Listening to Audio To adjust the volume simply press the keys on the projector. For more options, press the to reveal more options. Move selection left • To open the music menu, press “OK” on projector. Move selection right •... - Page 29 Music Playback FAQ How do I loop a song? How do I create a song playlist? Insert your media device (either MicroSD 1. Choose either USB or SD Card card or USB) into computer. for playback Make a new folder on media device (folder name will be the name of the playlist).
-
Page 30: Text Viewer Menu
Wait 2-3 seconds and a preview of the song will show on the screen Viewing text files The P2jr Pico Projector allows you to view text files. Select the file you want to view in the file menu for the particular storage device on which the file is stored. -
Page 31: Setup Menu
Setup Menu The Settings Menu can be accessed by selecting “Settings”on the main Within the Setting Options, there are a few sets of submenus including: Picture • Picture mode Adjusts Contrast, Brightness, Color, Sharpness & Tint • Color Temperature Adjusts Color ratio of red, green, and blue •... - Page 32 Setup Menu Cont. Sound • Sound Mode Adjust Treble and Bass levels Time • Clock Adjust current time • Off timer Adjust time when P2jr will turn off after being idle • Sleep timer Set timer for P2 to automatically turn...
- Page 33 Setup Menu Cont. Option • OSD Language Change Language to English, French, Dutch, Spanish, Portuguese or Chinese • Restore Factory Default Reset P2jr back to default settings • Blending Adjust the blending option • OSD Duration Adjust automatic timer to return to main screen when idle.
-
Page 34: Chapter 4: Technical Details
Chapter 4 Technical Details Troubleshooting IMAGE IS BLURRED Possible Causes Solution The Projector is not in focus Adjust the focus with the focus adjustment dial until the image comes into focus The Projector is offset from plane / angle of Move the projector so that it is both 180 degrees operation and on an even plane with the screen. - Page 35 Technical Details Troubleshooting THE PROJECTOR DOES NOT TURN ON Possible Causes Solution There is no power Check to ensure the power outlet or battery source is good. Check the power adapter to ensure a proper connection with the wall outlet as well as the projector.
-
Page 36: Specifications
Specifications Brightness 55 Lumens Maximum Resolution WXGA(1920x1080) Contrast Ratio 1000:1 Projection Lens: Manual Focus Battery life: up to 120 minutes Image Size: 10~60 inches Lamp: 15,000 hour RGB Triple LEDs Video in: Composite A/V VGA(mini-VGA) HDMI(mini-HDMI) Audio Output: 1.0 W stereo speaker MicroSD Card: MicroSD Card Slot (16 GB maximum) - Page 38 Please direct all customer service inquiries to: AAXA Technologies, Inc. 1541 Parkway Loop Suite F Tustin, CA 92780 (714) 957-1999 info@aaxatech.com...
