Summary of Contents for Lumiax Smart-DC Series
- Page 1 Smart -DC series Solar charge controller Suitable for Lithium batter y (Constant Current, Boost) 15/25A, 20W User Manual User Manual_Smart-DC series_MA CE, Rohs, ISO9001:2015 Subject to change without notice!
-
Page 2: Description Of Function
Solar charge controller Smart-DC series User Manual Dear Clients, Thanks for selecting the Smart -DC series solar controller. Please take the time to read this user manual, this will help you to take advantage of controller’s new features. This manual gives important recommendations for installing, programming, using and so on. Read it carefully in your own interest please. -
Page 3: Installation
Solar charge controller Smart-DC series User Manual 5 Remote controller, Default setting 4.Installation When Smart-DC series controller is connected to the 4.1 Connection sequence system, you can set the controller with S/G- The following diagrams provide an overview of the Unit(SU/SG32) infrared remote controller, as showed connections and the proper order. -
Page 4: Starting Up The Controller
Solar charge controller Smart-DC series User Manual 6.Starting up the controller 5.2 Test function Press the“T est”key of S/G-Unit (SU/SG32) , the controller 6.1 Self Test will turn on load for 30s. During daytime, the testing As soon as the controller is connected to battery, it function can help users to verify correct installation or for starts self test. - Page 5 Solar charge controller Smart-DC series User Manual 7.3 T0T mode(Time3、T0T can induction) Warning: The combination of different error conditions may cause damage to the controller. D/N Thr D/N Thr Always remove the error before you continue connecting Sunset Sunrise the controller.
- Page 6 Solar charge controller Smart-DC series User Manual Recommended connection of LED 10.LED indications and Faults & Alarms Following connect ways is for the LED lights (Vf: 2.9V~3.4V; I: 300mA, Power: 1W ) n for number of parallel connection Green Yellow...
-
Page 7: 12.Technical Data
Solar charge controller Smart-DC series User Manual 12.Technical Data Item SMR1006-DCN3215Li SMR1006-DCN3215Li SMR1006-DCN32 5Li Max Charging Current Charging voltage target 3.0~9.0V(Programmable) Charging voltage recovery 2.9~8.9V(Programmable) Battery Parame- Low voltage disconnect 2.4~7.2V(Programmable) ters Low voltage reconnect 2.6~7.4V(Programmable) Battery Type Lithium 0℃ Charging protection Yes、No、Slow(Programmable) - Page 8 Solar charge controller Smart-DC series User Manual Item SMR1006-DCN3215LiG SMR1006-DCN32 5LiGP Max Charging Current Charging voltage target 3.0~9.0V(Programmable) Charging voltage recovery 2.9~8.9V(Programmable) Batter y Parame- Low voltage disconnect 2.4 ~ 7.2V(Programmable) ters Low voltage reconnect 2.6~ 7.4V(Programmable) Battery Type Lithium 0℃...
