Lulworth Chest of Drawers
Assembly Difficulty
one-person job
easy -
medium
- hard
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone's
favourite way to spend their time, so we've tried to make assembling
this item as quick and painless as possible.
A few important pointers before you start:
Please read the instructions right through before you start, and
check that all the components have been included in the pack;
we find separating all the hardware into piles makes it easier to
be sure that everything is present and correct.
Make sure you have the right tools. Allen keys are provided
if required, but screw drivers and other tools are not. You'll
find details of the tools you need at the beginning of the
instructions.
It's a good idea to build the unit in the room where you are
going to be using it, to avoid the need to move it after it's been
assembled.
Do not throw away any packing materials until assembly is
complete, just in case you accidentally discard smaller parts or
hardware.
V1
12/07/2021
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lulworth and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Great Little Trading Lulworth

  • Page 1 We know assembling furniture, toys or accessories is not everyone’s favourite way to spend their time, so we’ve tried to make assembling this item as quick and painless as possible. Lulworth Chest of Drawers A few important pointers before you start: •...
  • Page 2: Safety Warnings

    Safety Warnings: Customer Service: • PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. • If you find that any components are missing or damaged, please do not begin assembly and do not use the item. Please contact GLTC • Adult assembly required. Customer Services on 0344 848 6000 immediately.
  • Page 3: Component Checklist

    Component Check List Component Check List 1x Top Drawer Divider Panel 1x Horizontal Divider Panel 4x Drawer RH Sides 2x Large Drawer Back Panels 1x LH Side Panel 1x RH Side Panel 2x Large Drawer Base Panels 1x RH Small Drawer Front 1x Base Panel 1x Top Panel 1x LH Small Drawer Front...
  • Page 4: Hardware Check List

    Hardware Check List Hardware Check List 12x Screws 48x Screws 4x Flat Runners 4x Flat Runners (16mm) (12mm) 4x Flat Runners 4x Flat Runners 6x Flat-Ended Screws 6x Handles 4x Cross-Head Bolts 16x Wooden Dowels 18x Screws 4x Barrel Nuts (47mm) (20mm) (25mm)
  • Page 5 STEP 2: Hardware for Step 1: Note: You will be building this unit with the back facing up. POSITION 1 POSITION 2 Align horizontal divider panel (B) so that the countersunk holes in the 1x #1 Flat Runner middle of the panel are facing outwards and the 2x small pilot holes on the long thin edge are facing up.
  • Page 6 STEP 3: STEP 4: Hardware for Step 4: Hardware for Step 3: Take the LH side panel (C) and attach 3x Insert 2x wooden dowels (#5) into side flat runners (#1) with 3x screws (#12) for panel (C) in the inner holes next to the 3x #1 Flat Runners each runner.
  • Page 7 STEP 5: STEP 6: Hardware for Step 5: Hardware for Step 6: Take the RH side panel (D) and attach 3x flat Insert 2x wooden dowels (#5) into side panel runners (#2) with 3x screws (#12) for each (D) in the inner holes next to the cam dowels 3x #2 Flat Runners runner.
  • Page 8 STEP 8: STEP 7: Attach base panel (E). Hardware for Step 7: Hardware for Step 8: Take top panel (F) and insert 6x cam dowels Insert 4x wooden dowels (#5) to the inner (#7) as shown. holes in the ends of the side panels (C) and (D) 4x #5 Wooden Dowels (20mm) as shown.
  • Page 9 STEP 9: STEP 10: Attach the feet. Hardware for Step 9: Hardware for Step 10: Insert 6x wooden dowels (#5) into the Insert 4x wooden dowels (#10) into each remaining holes in top panel (F). Position top corner of base panel (E) where indicated. panel (F) onto the unit, aligning the hardware 6x #5 Wooden Dowels (20mm) Push the 4x feet (H) into position and, using...
  • Page 10 STEP 11: STEP 13: Take the 2x back panels Take 1x LH drawer side panel (J) and attach 1x runner (#4) with 3x (G) and place them within screws (#12) ensuring that you are positioning all screws through the the recessed groove of the indicated holes.
  • Page 11 STEP 15: STEP 16: Hardware for Step 15: Hardware for Step 16: Build the 2x large drawers. Prepare the front panels of the 2x small drawers. Attach side panels (J & K) to the large 8x #6 Screws (25mm) 8x #7 Cam Locks drawer back panel (L) as shown with 4x Insert 4x cam dowels (#7) to EACH of the screws (#6).
  • Page 12 STEP 17: STEP 18: Hardware for Step 17: Hardware for Step 18: Construct the first small drawer attaching Repeat step 17 to assemble the second side panels (J & K) to back panel (Q) as small drawer this time attaching drawer 4x #6 Screws (25mm) 4x #6 Screws (25mm) shown with 4x screws (#6).
  • Page 13 Please refer to the instructions in the kit provided for further guidance. Your unit is now ready to use. Copyright© 2021 G.L.T.C. Ltd. All rights reserved. Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
