L2985 Northcote
Tall Open Base & Shelf Unit
Assembly Difficulty
one-person job
easy -
medium
- hard
Thank you for shopping with GLTC, we hope you enjoy having this
product in your home.
We know assembling furniture, toys or accessories is not everyone's favourite
way to spend their time, so we've tried to make assembling this item as quick and
painless as possible.
Hopefully our efforts will have been worthwhile and you'll sail through the
whole process. But if it all feels a bit too much like hard work, then we do have
an assembly company we can recommend: the Flatpack Construction Company
offers a nationwide service and can be contacted on 0843 289 4951 or www.
flatpackconstruction.co.uk.
Good luck!
A few important pointers before you start:
•
Please read the instructions right through before you start, and check that all the
components have been included in the pack; we find separating all the hardware
into piles makes it easier to be sure that everything is present and correct.
•
Make sure you have the right tools. Allen keys are provided if required, but screw
drivers and other tools are not. You'll find details of the tools you need at the
beginning of the instructions.
•
It's a good idea to build the unit in the room where you are going to be using it, to
avoid the need to move it after it's been assembled.
•
Do not throw away any packing materials until assembly is complete, just in case
you accidentally discard smaller parts and hardware.
V2
22/09/2017
1
Advertisement
Related Manuals for Great Little Trading L2985 Northcote
Summary of Contents for Great Little Trading L2985 Northcote
- Page 1 Hopefully our efforts will have been worthwhile and you’ll sail through the L2985 Northcote whole process. But if it all feels a bit too much like hard work, then we do have Tall Open Base & Shelf Unit an assembly company we can recommend: the Flatpack Construction Company offers a nationwide service and can be contacted on 0843 289 4951 or www.
- Page 2 Safety Warnings: Customer Service: • Adult assembly required. • If you find that any components are missing or damaged, please do not begin assembly and do not use the item. Please contact GLTC Customer Services on • Unassembled product contains small parts which may present a choking hazard. 0344 848 6000 immediately.
- Page 3 Component Check List: Top Shelf Unit Component Check List: Open Base Unit Sides (x2) Shelf - Sides (x2) Shelf - Base Large Back Panel left & right left & right Small Back Panel Shelf - Back recessed groove at top Shelf Panel Component Check List: All Hardware You will need:...
- Page 4 Assembly: Open Base Unit left right Ensure that each cam lock’s arrow is pointing towards the drill hole on the Hardware for Step 2: side edge of the component. STEP 2: STEP 1: Lay the top panel (B) and base panel (C) on a clean, flat 12x #1 Cam Dowels Hardware for Step 1: Lay the 2x side panels (A) on a clean flat surface with the...
- Page 5 Assembly: Open Base Unit Ensure that each cam lock’s arrow is pointing towards the drill hole on the STEP 4: side edge of the Hardware for Step 4: component. STEP 3: Turn over shelf panel (G) and insert 2x wooden dowels (#3) into the larger drillholes.
- Page 6 Assembly: Open Base Unit left left When panel is in position, When panel is in position, secure by turning the two secure by turning the two bottom cam locks (#2) bottom cam locks (#2) clockwise. clockwise. STEP 5: STEP 6: Take the left hand side panel (A) and position base panel (C) over it as shown, so that Take the shelf panel (G) and position over left hand side panel (A) as shown, so that the recessed grooves on each panel are aligned.
- Page 7 Assembly: Open Base Unit When panel is in position, secure by turning the two bottom cam locks (#2) clockwise. left left STEP 8: Carefully turn the unit to its upright position. Take the divider panel (H) and guide the drillholes on its edge over the cam dowels and wooden dowels on shelf panel (G).
- Page 8 Assembly: Open Base Unit When panel is in position, secure by turning the two bottom cam locks (#2) clockwise. left STEP 9: Take top panel (B), with its hardware facing down, and position it so that the drillholes on its far-side edge are guided over the cam dowels and wooden dowels on side panel (A).
- Page 9 Assembly: Open Base Unit left left STEP 11: STEP 12: Gently slide small back panel (F) into the recessed groove of the shelf panel (G) and Gently slide front panel (D) so that the drillholes on its end are guided over the top panel (B), ensuring it is pushed all the way in to the groove on the left side panel wooden dowels on left side panel (A).
- Page 10 Assembly: Open Base Unit right right When panel is in position, secure by turning the two bottom cam locks (#2) clockwise. STEP 13: STEP 14: Position right side panel (A) and guide the hardware into the drillholes on the edges Once right hand panel (A) is attached, secure by tightening 6x cam locks (#2) by of panel B, G, C and D.
- Page 11 Assembly: Top Shelf Unit STEP 16: Lay the shelf base panel (K) on a clean flat surface with the large circular drill holes facing up. Insert 4x cam locks (#2) in the drill holes, with the arrows facing towards the smaller drill holes on the sides of the panels.
- Page 12 Assembly: Top Shelf Unit Please ensure that the 2x pilot holes to attach the anti-tip straps are on this side. Secure by turning the two bottom cam lock (#2) clockwise. left left Tighten the cam lock (#2) by turning clockwise on the back of panel J.
- Page 13 Assembly: Top Shelf Unit Please ensure that the 2x pilot holes to Please ensure that the 2x pilot holes to attach the anti-tip straps are on this side. attach the anti-tip straps are on this side. right Tighten the cam locks (#2) by turning clockwise on the back of panels J &...
