Muratec F-560 Specifications page 2

Features & Benefits
80-sheet automatic document feeder
> Enables faxing, copying or scanning of large jobs without
having to separate them into multiple sets
Intuitive touchscreen operation
> A first in this segment!
> Large, back-lit touchscreen is easy to operate and
significantly reduces the learning curve
Flexible paper capacity
> Standard 500-sheet front loading tray is accessible and user
adjustable
> Optional second 500-sheet cassette allows for the
simultaneous use of letter and legal-size papers
Easy network installation
> DHCP compliant
> Print drivers can be installed via the server or individual client
Duplex printing
> Reduce paper consumption and day-to-day operational costs
by utilizing duplex print, copy and fax reception capabilities
Refined print engine
> 20-ppm print engine provides superior quality and clarity
> Redesigned paper path reduces jam frequency
33.6 Kbps modem
> Standard fax modem transmits documents at the highest
regulated speeds
> JBIG compression reduces the transmission packet allowing
for shorter connection times
> Transmissions at up to 2 seconds per page
300 entry address book
> Each location can house a fax number, e-mail address and
group location
SPECIFICATIONS F-560
—
GENERAL
Classification "Plain Paper Fax"
Recording Method LED
Print Speed 20 pages per minute
User Interface Touchscreen
Document Feeder 80 sheets
Standard Paper Capacity 550-sheets (includes
50-sheet bypass tray)
Max. Paper Capacity 1,050 sheets
Cassette Paper Weight 20-24 lb.
Duplex Printing 1:2, 2:2, 2:1
Duplex Scanning Manual
Jam Access Side Cover
Dimensions (H x W x D) 20.5" x 19.3" x 17.5"
Weight 44.75 lbs.
Department Codes 100 (Copy/Fax)
Toner Yield 15,000 @ 4%
Drum Yield 20,000
DHCP Compliant Yes (Default On)
Ethernet Connection Standard 10/100 BaseT,
RJ-45 connection
Network Protocol TCP/IP
Local Connection Standard USB 2.0
As an ENERGY STAR ®
these products meet the ENERGY STAR
Muratec, the Muratec logo and all Muratec product and feature names are
trademarks of Muratec America, Inc. Energy Star is a registered trademark of
the U.S. Environmental Protection Agency.
All specifications subject to change.
MK3143
SCAN
Resolution
Grayscale
Interface
Scan to e-mail
File Formats
Scan to FTP
Scan to folder
TWAIN Compliant
Scan Boxes (Local)
Default Color Scan Speed
Default Monochrome
Scan Speed
PRINT
Resolution
Page Description
Language
OS Support
Print Alignment
Duplex Print Speed
Job Cancel
FAX
Modem Speed
partner, Muratec America, Inc. has determined that
® ®
guidelines for energy efficiency.
> 330 number broadcast capabilities (fax and e-mail
addresses can be mixed)
> OfficeBridge Expansion Kit enables both personal &
shared address books for enhanced security and contact
management
> OfficeBridge Expansion Kit increases the internal address
book to 2000 locations (w/ optional 512 MB memory)
> Supports vCard import from Microsoft Outlook
LDAP search capabilities
> Quickly and easily locate contacts on a corporate server
(Active Directory, OpenLDAP, etc.)
Scan to network folder
> Surf corporate networks with ease, delivering documents
directly into network folders
> Create up to 20 folder shortcuts
Scan to e-mail
> Intuitive QWERTY keypad allows you to add a customized
file name, subject line and text message to each
transmission
> Send documents in TIFF, PDF or JPEG format
> Attach any document stored on the network to an
outgoing transmission
Scan to FTP
> Upload documents to an FTP server for sharing or storage
> Create up to 20 FTP shortcuts for one-touch scan initiation
Standard GDI-based network printing
> High-speed 10/100 BaseT Ethernet connection offers the
perfect print solution for a small to midsize workgroup
Max. Compression
Max. Transmission Speed
600 x 600 dpi
Default Scan Speed
256 levels
Std. Image Memory
Standard USB / Ethernet
(Page Capacity)
Direct or Shortcut
Max. Image Memory
PDF, TIFF, JPEG
(Page Capacity)
Direct or Shortcut
Document Back-up
Direct or Shortcut
Address Book
Yes
20 boxes
Broadcasting
9 seconds
Group Dialing
4.1 seconds
Fax / E-Mail Mixed
Transmission
600 x 600 dpi
LDAP Directory Support
Standard Windows GDI,
Optional PCL 5e & 6
Block Junk Fax
Win 98SE, Me, NT 4.0,
Security Reception
2000, XP, 2003
Fax Forwarding
Upper Left Corner
5 ppm
Batch Transmission
Machine / Browser
Automatic Redial
Confirmation Report
33.6 Kbps
Max. Scan Width
Muratec America, Inc.
3301 East Plano Parkway, Suite 100, Plano, Texas 75074
For more information on Muratec products or services,
call (469) 429-3300 or visit our web site at www.muratec.com
JBIG
2 seconds per page
1.8 seconds per page
8 MB (650 pages)
40 MB (3370 pages)
72 hours
300 locations
(Expandable to 2000)
330 locations
(up to 30 direct dial)
32 groups
(Expandable to 200)
Yes
Yes – Active Directory
2000& 2003, Open LDAP
50 locations
Yes
Yes (via machine or
browser)
5 locations
2-15 attempts
Yes
8.2"
