Chapter 1 – Product Description

Product Description

The Multi-Tech MultiModem CDMA USB is an external data/fax/voice wireless modem. It also supports mobile
originated short message service (SMS) and mobile-terminated SMS. It offers standards-based multi-band CDMA
2000 1xRTT performance. This ready-to-deploy, standalone modem allows developers to add wireless
communication to products with a minimum of development time and expense. The MultiModem CDMA USB
Wireless modem is based on industry-standard open interfaces, is fully approved, and can be desktop or panel
mounted.
Models:
MTCBA-C-U-N1 is a generic 800/1900 MHz CDMA USB modem that must be programmed with Provisioning
Information (PRI) and a Preferred Roaming List (PRL). (A-key = Random). Recommended for
developers.
MTCBA-C-U-N2 is an 800/1900 MHz CDMA USB modem provisioned for Sprint networks. USA
MTCBA-C-U-N3 is an 800/1900 MHz CDMA USB modem provisioned for Verizon networks. USA
MTCBA-C-U-N4 is an 800 MHz CDMA USB modem for regions that use R-UIM cards. (R-UIM).
MTCBA-C-U-N9 is a generic 800/1900 MHz CDMA USB modem must be programmed with Provisioning Information
(PRI) and a Preferred Roaming List (PRL). (A-key = 0). Recommended for developers.
MTCBA-C-U-N12 is an 800/1900 MHz CDMA USB modem provisioned for Bell Mobility. Canada.
MTCBA-C-U-N14 is an 800/1900 MHz CDMA USB modem provisioned for Alltel networks. USA.
Other Product Codes:
NAM is the model for US and Canada
E/U is the model for Europe and the rest of the world
A Note About Documentation:
Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the
content hereof without obligation of Multi-Tech Systems, Inc., to notify any person or organization of such revisions or
changes. Check Multi-Tech's Web site for current versions of our product documentation.

Features

•
CDMA2000 1xRTT operation
•
Dual-band 800/1900 CDMA
•
800 MHz with R-UIM support
•
Class 2.0 Group 3 FAX
•
Desktop or panel mounting
•
Short Message Service features including SMS mobile originated, SMS mobile
terminated, cell broadcast, Over the Air Activation (OTA), OTASP, OTAPA
•
Voice features include DTMF, telephony, OCELP 13K, echo cancellation
•
SMA antenna connector
•
Serial interface supports DTE speeds to 230K
•
AT command compatible
•
CDMA IS-95-A, IS-95B; backwards compatible
•
Packet data up to 153K bps forward and reverse
•
Circuit-switched data up to 14.4K bps
•
Phone book management and Personal Information Management (PIM)
•
Fixed dialing number
•
Supplementary services including call forwarding, call barring, multiparty, call
waiting and call hold, calling line identification, closed user group, call transfer
•
Numerous LEDs present operational status
•
Real time clock
•
Alarm management
