Velleman HQ-Power VDL500SM Manual

1. Introduction & Features
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the VDL500SM! It is a time controlled smoke machine for creating thick smoke from a special
smoke liquid. Please read the manual thoroughly before bringing this device into service. Make sure that the device was
not damaged in transit. If the device is damaged, contact your dealer and postpone installation of this device.
2. Safety Instructions
Be very careful during the installation: touching live wires can cause life-threatening electroshocks.
Do not touch the device during operation as the housing heats up.
Keep this device away from rain and moisture.
Unplug the mains lead before opening the housing.
• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer
will not accept responsibility for any ensuing defects or problems.
• A qualified technician should install and service this device.
• Do not switch the device on immediately after it has been exposed to changes in temperature. Protect the device
against damage by leaving it switched off until it has reached room temperature.
• This device falls under protection class I. It is therefore essential that the device be earthed. Have a qualified
person carry out the electric connection.
• Make sure that the available voltage does not exceed the voltage stated in the specifications of this manual.
• Do not crimp the power cord and protect it against damage. Have an authorised dealer replace it when damaged.
• Disconnect the device from the mains to clean it or when it is not in use. Handle the power cord by the plug only.
• Note that damage caused by user modifications to the device are not covered by the warranty.
• Keep the device away from children and unauthorised users.
• Do not aim the device at anyone.
• Use adapted smoke liquid only and don't pour hot liquid into the tank.
• Make sure there is always enough liquid in the tank to keep the device from overheating.
3. General Guidelines
• This device is designed for professional use on stage, in discos, theatres, etc. The VDL500SM should only be
used indoors with an alternating current of max. 230V AC/50Hz.
• Smoke machines are not designed for permanent operation: regular operation breaks will prolong their lives.
• Do not shake the device. Avoid brute force when installing or operating the device.
• Select a location where the device is protected against extreme heat (see "8. Technical Specifications", p.3), dust
and moisture. Ensure a minimum distance of 0.5m between the device and any nearby surface or passer-by.
• Use an appropriate safety cable to fix the device (e.g. VDLSC7 or VDLSC8) with the safety ring at the back.
VDL500SM
VDL500SM – SMOKE MACHINE
1 VELLEMAN
